Figure 1-2
CHALLENGE Vault L (Drive Door Open)
The following components are located on the front of the Vault L storage
box:
Drive door
opens and closes using two quarter turns. Open the drive
door by pushing the knob in and turning it counter-
clockwise to open. Close the door by pushing the knob in
and turning it clockwise.
Front View Components
Power switch
Drive tray
3
