REV Robotics Expansion Hub Manual page 25

Rev 0 6/1/2017
Rev 1 6/22/2017
Rev 2 8/29/2017
Rev 3 9/29/2017
Rev 4 11/13/2017
Expansion Hub Guide – Rev 4
Revisions
Initial Release
• Overall Improved Wording for Clarity
Corrected the motor connector polarity in the Section 1.2 diagram
•
Corrected JST to APP (REV-31-1381) Cable Length
•
• Added 4-pin JST PH Extension Board Part Number
Corrected Wire Gauge for JST PH Contacts
•
Updated miniBot image in Figure 4
•
Updated sensor cable drawing to fix wire color error.
•
Added an improved version of Figure 6.
•
Added Adafruit Color Sensor to sensor compatibility table
•
• Updated the FTC Control System Guide link to the current wiki
Fixed spelling error
•
Added instructions for Hub Address Change
•
• Noted that custom wiring harness is needed for all compatible sensors
which do not require a level shifter
Corrected Hub Dimensions
•
• Fixed broken reference
Revision to fix revision number on all document sections (meta)
•
Added LED Status Colors
•
• Added compatibility details on REV motors
Added IMU Location and orientation to the dimension drawing
•
Added LED color code table for firmware 1_07_00
•
© REV R obotics, LLC 2017 23
