Port Summary Configuration Menu

The Port Summary Configuration Menu is accessed from the
Port Configuration Menu by selecting "Port Settings." In addi-
tion to displaying the settings for all ports, the menu allows you
to change the settings for a particular port (see Figure 5-12).
>>>> Port Summary Configuration Menu
Port Port State
1 [Forwarding]
2 [Forwarding]
3 [Forwarding]
4 [Forwarding]
5 [Forwarding]
6 [Forwarding]
7 [Forwarding]
8 [Forwarding]
9 [Forwarding]
10 [Forwarding]
.
.
17 [Forwarding]
18 [Forwarding]
<ESC> To Exit Menu, or Type Port Selection To Edit
Enter Selection:
___________________________________________________

Figure 5-11. Port Summary Configuration Menu

Display Fields
Port State—Displays the port Spanning Tree state (Listening,
Learning, Forwarding or Blocking).
Port Path Cost—Displays the port path cost (1 - 65535), a
Spanning Tree Protocol parameter. The default value for 10
Mbps is 100. The default value for 100 Mbps is 10.
Port Priority—Displays the priority (0 - 255) of the port relative
to other ports The default value is 128.
Speed/Dplx—Displays the speed of the port (10 or 100 Mbps)
C
Path Cost Priority
[ 100] [ 128]
[ 100] [ 128]
[ 100] [ 128]
[ 100] [ 128]
[ 100] [ 128]
[ 100] [ 128]
[ 100] [ 128]
[ 100] [ 128]
[ 100] [ 128]
[ 100] [ 128]
[ 10] [ 128]
[ 10] [ 128]
ONFIGURING AND
<<<<
Speed/Dplx MAC Address
[ 10/H] [ 00800F80003C ]
[ 10/H] [ 00800F80003D ]
[ 10/H] [ 00800F80003E ]
[ 10/H] [ 00800F80003F ]
[ 10/H] [ 00800F800040 ]
[ 10/H] [ 00800F800041 ]
[ 10/H] [ 00800F800042 ]
[ 10/H] [ 00800F800043 ]
[ 10/H] [ 00800F800044 ]
[ 10/H] [ 00800F800045 ]
[ 100/H] [ 00800F80004C ]
[ 100/H] [ 00800F80004D ]
M
ONITORING
5-17
