C 5
HAPTER
C
ONFIGURING AND
M
ONITORING
The Console Interface . . . . . . . . . . . . . . . . . . 5-3
Using the Console Interface . . . . . . . . . . . . 5-3
Main Menu . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Switch Configuration Menu . . . . . . . . . . . . 5-5
Configuration Display Screen . . . . . . . . . . . 5-7
IP Configuration Menu . . . . . . . . . . . . . . . 5-9
SNMP Configuration Menu . . . . . . . . . . . . . 5-11
Spanning Tree Configuration Menu . . . . . . 5-12
Address Aging Configuration Menu . . . . . . 5-13
Port Mirroring Configuration Menu . . . . . . . 5-14
Port Configuration Menu . . . . . . . . . . . . . . 5-15
Port Summary Display Screen . . . . . . . . . . 5-16
Port Summary Configuration Menu . . . . . . 5-17
Port [x] Configuration Menu . . . . . . . . . . . . 5-18
Statistics Menu . . . . . . . . . . . . . . . . . . . . . . 5-19
Utilities Menu . . . . . . . . . . . . . . . . . . . . . . 5-20
Console Configuration Menu . . . . . . . . . . . 5-22
Boot Menu . . . . . . . . . . . . . . . . . . . . . . . . 5-23
5-1
