Installation Instruction - Flush Mounting
Step 1
Place the Flush Mounting Template on the desired
Ÿ
installation surface.
Mark the area along the dotted line and trace the
Ÿ
four screw holes (say A,B,C,D) on the wall as
shown in Figure7.
Now drill the dotted line area and four screw
Ÿ
holes (say A,B,C,D) on the wall as illustrated in
Figure8.
A
B
Flush Mounting
Template
C
D
Figure 7
17
Step 2
Place and fix Flush Mounting plate with the supplied screws.
Tighten the screws with screw driver.
B
A
D
C
Figure 8
Flush Mounting
Plate
18
