  • Page 1 Snapper SP110 Operator's manual 2-14...

  • Page 2: Table Of Contents

    Contents Introduction............... 2 Maintenance............10 Safety................4 Transportation and storage........13 Assembly..............7 Technical data............14 Operation..............8 Introduction Product description Intended use The product is a pedestrian-controlled rotary lawn Use the product to cut grass in private gardens. Do mower. Attach the grass catcher to collect the grass. not use the product for other tasks.
  • Page 3 1. Engine brake handle 8. Side discharge guard 2. Drive handles 9. Side discharge deflector 3. Handle knob 10. Engine oil cap with dipstick 4. Fuel tank cap 11. Cutting height lever 5. Air filter 12. Grass catcher 6. Spark plug 13.

  • Page 4: Safety

    and packaging must be submitted to an appropriate recycling station for the recovery of electrical and electronic Engine off equipment. Product liability As referred to in the product liability laws, we are not Engine on liable for damages that our product causes if: •...
  • Page 5 • Do not let a child operate the product. Do not let grass catcher, or remove material from the a person, without knowledge of the instructions discharge chute. operate the product. • Disengage the drive system, if installed, before • Make sure that you always monitor a person, you start the engine.
  • Page 6 If the engine does not stop in 3 • Always use approved ear protection while you seconds, let an approved Snapper service agent operate the product. Noise for a long period can adjust the engine brake. cause noise-induced hearing loss.

  • Page 7: Assembly

    Safety instructions for • Accessories and changes to the product that are not approved by the manufacturer, can cause maintenance serious injury or death. Do not change the product. Always use accessories that are WARNING: Read the warning approved by the manufacturer. instructions that follow before you use •...

  • Page 8: Operation

    Operation Introduction • Cut in different directions each time to prevent stripes in the lawn. • Regularly hose the grass catcher with water and WARNING: Before you operate the let dry before use. Pores in cloth grass catchers product, you must read and understand can become filled with dirt and dust with the safety chapter.
  • Page 9 The adjuster lever is spring loaded. 1. Squeeze the height adjuster lever in the direction of the wheel. 2. Move the wheel up or down for your cutting requirements. To use the product with the grass catcher 1. Lift the rear door and put the grass catcher on the bracket.

  • Page 10: Maintenance

    • Release the drive handles to disengage the drive, for example when you go near an obstacle. To stop the product • To stop the drive only, release the drive handles. • To stop the engine, release the engine brake handle.
  • Page 11 Daily Maintenance Before After Each Each 25 Each Before each each hours stor- hours hours Examine the blade for damage and cracks General lubrication Engine Examine engine oil level Replace engine oil Clean the air filter. Replace if necessary. Make sure the muffler is attached correctly and is not damaged.
  • Page 12 the incorrect spark plug can cause prevent this, regularly hose the grass catcher off damage to the piston/cylinder. with water and let dry before using. • Examine the grass catcher frequently for wear or Maintenance schedule on page 10 for •...

  • Page 13: Transportation And Storage

    causes the product to stop, replace the damaged 7. Make sure that the blade is aligned with the blade. Let the service center estimate if the blade center of the motor shaft. can be sharpened or must be replaced. 8. Lock the blade with a block of wood. Attach the spring washer and tighten the bolt and washer To replace the blade with a torque of 47-54 Nm.

  • Page 14: Technical Data

    Technical data Technical data Product specifications Gasoline capacity and type Unleaded regular (maximum 10% ethanol) • SAE 30 (above 0°C (32°F) Oil type (API: SG-SL) • SAE 10W30 (above 0°C (32°F) • SAE 5W30 (below 0°C (32°F) Oil capacity See the engine manufacturer's manual for more information. Spark plug See the engine manufacturer's manual for more information.
  • Page 15 912 - 001 -...
  • Page 16 Original instructions 596659501 2018-10-10...
