Base Frame – Bottom View
Front Wheel Caster
Right Drive Motor
Pulley Set Screw
Right Motor Pulley
Right Drive Belt
Right Drive Wheel
Battery Recharge
Plug
Battery Access Door
Rear Caster Wheel
Speakers
Battery Door
Wing Nut
Water Pump Switch
On/Off/Refill
Water Squirter Overflow
Nozzle
Left Drive Motor
Pulley Set Screw
Left Motor Pulley
Left Drive Belt
Left Drive Wheel
Power Switch
Forward – On
Center – Off
Back - Charge
