How to Operate the Receiver (Operator)
1. Place the headset on your head and adjust the microphone to approximately 1 inch from
your mouth. If needed, adjust the headset frame so that the earphone and the frame fit
comfortably and the earphone is against your ear.
2. Plug the headphone plug from the headset into the top of the receiver.
3. Move the slide switch to the "ON" position.
The volume is on the top of the receiver, which you may set to the desired volume.
Frequency label- Located on the back of the receiver.
Function of the LEDs
TX LED- This indicates that you are receiving a signal from the transmitter. On some units it is
a single TX light. Green indicates you are receiving a signal. Red indicates a low battery.
Tip: The operator's voice units both have metal clips that contact the posts of the
AA batteries. These must be bent out from time to time to keep this contact good.
VR-3U Receiver
