Audio Mixer

9
8
7
1
Audio Mixer Board
1 I2C from Processor Board- orange/yell.
2 I2C from Processor/5Volts- Red/Blk/Gr/Blue
3 I2C
4 I2C Data to MP3 Player-Green/Blue
5 Audio from MP3 Player-Gray/Blk/White
6 Voice Audio from VR3U Receiver
7 Left Channel Audio to Amp-Blk/White
8 Right Channel Audio to Amp- Blk/White
9 Power to Board 12 V
10 jumper- Mouth triggering select
11 jumper- Music channel pass through
select
12 Level adjust for Aux. audio input to the
right of this adjustment.
2 3
1
10
11
12
49
4
5
4
6
