Instruction Manual
Digital Coating Thickness Gauge
SAUTER TB
Version 1.3
08/2017
GB
Sauter GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: info@sauter.eu
Tel: +49-[0]7433- 9933-199
Fax: +49-[0]7433-9933-149
Internet: www.sauter.eu
PROFESSIONAL MEASURING
TB-BA-e-1713
Advertisement
Table of Contents
Related Manuals for sauter TB
Summary of Contents for sauter TB
- Page 1 Sauter GmbH Ziegelei 1 Tel: +49-[0]7433- 9933-199 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@sauter.eu Internet: www.sauter.eu Instruction Manual Digital Coating Thickness Gauge SAUTER TB Version 1.3 08/2017 PROFESSIONAL MEASURING TB-BA-e-1713...
- Page 2 Instruction Manual Digital Coating Thickness Gauge Thank you for buying a SAUTER digital Coating Thickness Gauge. We hope you are pleased with your high quality Thickness Gauge with its big functional range. If you have any queries, wishes or helpful suggestions, do not hesitate to call our service number.
- Page 3 Measurement range: 1000 μm and 2000µm Resolution: 0,1 µm (0 bis 99,9 µm), 1 µm (100 µm bis 1000µm bzw. 2000µm beim TB 2000-0.1F) Accuracy: Following accuracy is given for the models TB 1000-0.1F, TB 1000-0.1N as well as TB 1000-0.1FN: TB-BA-e-1713...
-
Page 4: Front Panel Description
Is valid within a tolerance range of ± 100 μm around the individually measured range, if a two-point calibration has been performed within this tolerance range. For model TB 2000-0.1F accuracy is: - Standard: 5% of the measured value or min. ± 2.5 µm Is valid within a tolerance range of ±... -
Page 5: Measuring Procedure
6.1 Zero calibration for „Fe“ and „NFe“ should be done separately. If you take the iron base plate, you will have to insert the F-sensor and „Fe“will be displayed. Or you take the base plate of aluminium; then you will have to insert the FN-sensor and "NFe"“will be displayed. TB-BA-e-1713... - Page 6 9 Correct handling at coating thickness measurement with exter- nal sensors Sensor (orange=F, black=N) Spring shaft for handling Sensor tip The sensor has to be touched at the lower shaft (pole) segment and it has to be pressed slightly onto the test object. TB-BA-e-1713...
- Page 7 Otherwise, measurement accuracy may be affected or the gauge could become damaged, in the way that it can no longer be used. Annotation: To have a look at the CE Declaration of Conformity, please click onto the following link: https://www.kern-sohn.com/shop/de/DOWNLOADS/ TB-BA-e-1713...
