Summary of Contents for Hover-1 Fuel
- Page 1 P E D A L - A S S I S T E D B I C Y C L E O PE RAT IO N MANUA L H 1 - M E2 6...
- Page 2 @RideHover1 @RideHover1 @RideHover1 www.Hover-1.com...
- Page 3 HELMETS SAVE LIVES! Always wear a properly tted helmet that complies with CPSC or CE safety standards when you ride your bicycle. Correct Fitting: Make sure your helmet covers your forehead. Incorrect Fitting: Forehead is exposed and vulnerable to serious injury. RIDE WITH CAUTION!
- Page 4 WARNING Great care should be taken when adjusting the bike hardware on the Hover-1. Fuel If you do not understand how to adjust the bicycle hardware, please contact your local bike specialist. DO NOT RIDE YOUR HOVER-1 Fuel WITHOUT ALL...
- Page 5 • Charge Cable • Operation Manual • Wall Charger The Fuel is not a toy. Do not ride the Fuel with reckless abandon and always keep in mind the safety of you and of those around you. Your Fuel's serial number is stamped respectively on steering column and battery column.
- Page 6 • Children incapable of riding a bicycle on their own or under the age of 6 should not ride on the Fuel, unless it’s equipped with an approved Child Seat accessory.
- Page 7 • Do not over load the cargo rack. The maximum load weight for the cargo rack on the Fuel is 33.07lbs. • Double check your load for security and stability. • Make sure no straps are dangling where they could...
- Page 8 4. Be careful when transporting your Fuel. • The Fuel is heavier than a standard bicycle. If transporting on a vehicle, be aware of the maximum load capacity of the vehicle’s roof, towing hook and/or of the preferred bicycle carrier.
-
Page 9: Safety Precautions
SAFETY PRECAUTIONS • If the Fuel is not to be used for an extended period of time, you may need to recharge the battery every 2 months to maintain the battery life. • Ensure that the screws on the front and back tires are locked rmly before each ride. - Page 10 Pull the lever to ensure the brake moves freely and stops the Fuel. If the lever can be pulled at to the handlebar, the brake is too loose. Brakes will wear down over time. If the brakes do not perform well, they may need to be adjusted or to have the pads replaced.
- Page 11 The rst rule in safe riding is to use common sense. The Fuel is vulnerable; it cannot protect you in a crash, against impact, or loss of control the way driving a car can. The Fuel can tip over sideways or pitch you over the front wheel.
- Page 12 It is recommended that you do not ride your Fuel in wet weather, as there are electronic components of your Fuel that may be damaged if exposed to water. WARNING • Wet conditions will require a longer distance to stop.
- Page 13 • Do not ride with loose objects attached to the handlebars or other parts of the Fuel. • Do not ride your Fuel with any pets leashed to your bicycle. • Never carry other riders or packages as they may...
- Page 14 • When approaching a turn or descent, decrease your speed. • Do not abuse your Fuel. Always look ahead to avoid and anticipate any upcoming obstacles. The distance of any upcoming obstacles will vary according to your speed. • Use caution when you encounter road obstacles. If you are going fast, even a small obstacle can create a signi cant impact to both you and your Fuel.
-
Page 15: Care And Maintenance
• Do not dispose of the Fuel in a re as it may explode or combust. • Do not expose the Fuel to contact with sharp objects as this will cause scratches and damage. -
Page 16: Maintenance Tips
Axles Check and tighten screws Monthly on the front and rear axles Front Fork Tighten the screw on the Monthly front fork and handle bar WARNING Users who disassemble the Fuel without permission will void the warranty. -
Page 17: Battery Care
LED lights up red and beeps to alert the rider to charge the battery. • Only charge the battery pack with the charging cable provided by Hover-1. • Do not connect or attach the battery pack to a power supply plug or directly to a car’s cigarette lighter. - Page 18 • Do not allow any liquids on or inside the battery pack/charger. • Do not use your Fuel if the battery pack begins to emit odor, overheats, or begins to leak. • Do not touch any leaking materials or breathe fumes emitted.
- Page 19 • Do not use the battery/charger for any use other than its intended purpose. • Do not use any third party or unauthorized battery pack/charger on your Fuel. WARNING SEEK IMMEDIATE MEDICAL ATTENTION IF YOU ARE EXPOSED TO ANY SUBSTANCE THAT IS EMITTED FROM...
-
Page 20: Specifications
SPECIFICATIONS Model: Hover-1 Fuel (H1-ME26) Max Load: 44-220 lbs (20-100 kg) Max Speed: Up to 11.2 mph (18 km/h) Max Distance Range: Up to 18.6 miles (30 km) Max Incline Angle: 10° degrees Sensor: Magnetic speed sensor Frame: Alloy Fork:... - Page 21 HOVER-1 FUEL DIAGRAM FEATURES/PARTS 1. Handlebar 7. Battery Dock 2. Bicycle Frame 8. Front Brake & Rotor 3. Seat Quick Release 9. Pedal & Crank 4. Seat 10. Bicycle Chain 5. Front Wheel 11. Kickstand 6. Battery Pack 12. Rear Brake & Rotor HANDLEBAR DIAGRAM 1.
-
Page 22: Display Panel
DISPLAY PANEL 1. POWER BUTTON Turns Pilot on/o . 2. PEDAL-ASSIST LEVEL Increase pedal-assist INCREASE BUTTON mode up 1 level. 3. PEDAL-ASSIST LEVEL Decrease pedal-assist DECREASE BUTTON mode down 1 level. 4. ODOMETER Displays total trip distance traveled. 5. SPEEDOMETER Displays current speed in mph. - Page 23 8. CONTROLLER ERROR Indicates error with ICON controller. 9. BRAKE ERROR ICON Indicates error with braking system. 10. MOTOR ERROR ICON Indicates error with motor. 11. LOW BATTERY VOLTAGE Indicates battery voltage ICON is low.
-
Page 24: Charging Devices
To charge a mobile device or tablet, rst remove the battery pack from the Fuel’s battery dock and press the power button to turn the battery pack on. Next, insert your mobile device’s or tablet’s charging cable USB connector to the USB port on the battery pack. - Page 25 . CHARGING THE BATTERY PACK • Ensure the Fuel is turned o . • Remove the battery pack from the battery dock. • Ensure that the charging port is clean and dry.
-
Page 26: Before Riding
Fuel on public roads. PRE-RIDE Fuel CHECKLIST Ensure that your Fuel is in proper working order each and every time you ride. If a part of the Fuel does not function correctly, please contact our Customer Support Center. WARNING Do not ride a Hover-1 Fuel with a part that is damaged;... -
Page 27: Operating Conditions
OPERATING YOUR Fuel Make sure the Fuel’s battery pack is fully charged before the rst initial use. Before turning on your Fuel, sit on it like a standard bicycle to get comfortable with the device before using it with the motor. - Page 28 To turn, use the handlebar to turn in the direction you wish to turn. As you get comfortable riding the Pilot, you will notice it becomes easier to maneuver. Remember at higher speeds, it is necessary to shift your weight to overcome the centrifugal force.
- Page 29 Fuel. You will feel the motor engage and assist you while you pedal, making your ride easier. You can always ride your Fuel like a standard bike if your battery pack runs out of power. WEIGHT AND SPEED LIMITATIONS Speed and weight limits are set for your own safety.
- Page 30 • Weight: A lighter user will have further range than a heavier user. • Ambient temperature: Please ride and store the Fuel under recommended temperatures, which will maintian driving distance, battery life, and overall performance of your device.
-
Page 31: Troubleshooting
TROUBLESHOOTING The following table is only meant to act a guide to help you gure out any problems you may have with your Fuel. If you are unable to get your Fuel to operate properly, please visit www.Hover-1.com for support. - Page 32 TROUBLESHOOTING PROBLEM POSSIBLE CAUSES SOLUTION LCD Display not 1. Low battery 1. Recharge battery pack registering 2. Display is broken 2. Replace display 3. Bad battery cells 3. Replace 4. Faulty charger battery pack burns out display 4. Contact customer support Brakes squealing 1.
-
Page 33: Warranty
WARRANTY For warranty information, Please visit us at: www.hover-1.com A ix Serial Number Label Here:...
