Chapter 1 : INTRODUCTION (continued)
1-2. GENERAL INFORMATION (continued)
Optimizer HD large front panel shows many direct access image adjustments with a bright easy to read fluorescent
display and a convenient control knob. It offers many useful features such as an adjustable zoom from 25 to 400%. The
standard RS232 connection and provided software allow a full remote control of the device and also upgrade capability
to maintain the high value of your equipment. Optional RJ45 is available for IP control.
Optimizer HD provides real time TV to HDTV stunning conversion.
1-3. DEVICES & OPTIONS REFERENCES
REFERENCE
OHD888
OHD888-AG
OPT-OHD-DATA Option Input & Output computer format
OPT-LAN

1-4. INSTALLATION

IMPORTANT:
• Table Top Mounting The device can be used directly on a table: the unit is equipped with 4 plastic feet.
• Rack Mounting:
IMPORTANT:
PAGE 8
Optimizer HD
Optimizer HD with Analog Genlock.
Optional IP/LAN communication port.
Please read all the safety instructions (pages 2 to 4) before starting.
The device is compatible with a 19" enclosure (height = 2 units). To install the device into a
19" rack: Attach the rack mount brackets to the side of the device with the 6 supplied screws.
Then attach the device to the rack by using 4 screws in the front panel holes (screws are not
included). Connect all of the cables to the device and attach them to the rack with some tie
wraps.
• The openings in the rear and side panels are for cooling. Do not cover these openings.
• Be sure that no weight is added onto the device in excess of 2 kg (4.4 lbs.).
• The maximum ambient operating temperature must not exceed 40°C (104°F).
• The rack and all mounted equipment in it must be reliably grounded to national and
local electrical codes.
DESIGNATION
OPTIMIZER HD
