Portbase User Guide
[ NMS configuration]
If multiple devices are installed and managed together, integration in management is necessary. In
addition, it is often the case when the device reports an erroneous status, figuring out the reason for the
failure becomes a time-consuming job. To solve this inefficiency and provide better solution, Portbase
includes a Network Management System software, Portview.
- set nw nms snmp [ enable / disable ] (Default: disable)
Enable or disable SNMP(Simple Network Management Protocol).
MIB-II (RFC 1213):
MIB-I (RFC 1317):
- set nw nms portview ip <IP Address> (Default: 0.0.0.0)
Set the IP address of the PC where Portview in installed. For more information on Portview,
please refer to the Portview User Manual.
If IP is set to 0.0.0.0, NMS feature is disabled.
- set nw nms portview port <Socket Number>
Set the port number of the PC where Portview in installed.
- set nw nms portview group <name> (Default: none)
Set the group name for management. 32 Characters at maximum.
- set nw nms portview location <name> (Default: none)
Set the location name for management. 32 Characters at maximum.

4. Serial commands

- set serial [ all / 1 / 2 ] status [enable / disable]
Choose to use or not use this port.
- set serial [ all / 1 / 2 ] interface [rs232 / rs422ptp / rs422md / rs485ne / rs485e ] (Default:
rs232)
cele mai sensibile
Electric Film S.R.L. — Aleea Scarisoara 3, Apt.42 ▪ Cluj Napoca, Cluj ▪ 400445 ▪ www.electricfilm.eu
VÂNZĂRI ▪ 0364 710319 ▪ electricfilm.eu@gmail.com ▪ SUPORT TEHNIC ▪ 0788 250583
System, Interface, IP, ICMP, TCP, UDP
Serial Interface
You can set the communication and operation environment for the serial port.
set serial [ port number ] [ status / interface / mode / port / name /
speed / data / stop / parity / flow / signal / rport /
alive / mtu / login / username / password / reset ] <var >
ECHIPAMENTE PENTRU AUTOMATIZĂRI
(Default: 4000)
(Default: enable)
37
37/45
