Initial Setup & Basic Operations
14. After the test pattern has printed,
navigate the control panel / screen until it does (refer toFigure 3-11 Adjustment Menu Flow
page 62). Press the [Enter] key to display the current offset position, and to be able to adjust
it. The figures shown here are examples only, the offset values shown for each printer will
differ:
15. Press ENTER to set the new offset value.
NOTE
To shift the centre vertical bar in a left direction (as per Figure 3 –
Desired Alignment, above), decrease the offset value. In the example
above, the value of -22 might be decreased to -30 initially. To shift
the centre vertical bar to the right, increase the offset value.
16. Repeat the process of Printing the Bi-D Adjustment Pattern and Effecting the Bi-D Adjustment
until the desired alignment is achieved. This can take many, many iterations.
BiD Hi VSDxx:Setup should display on screen – if it does not,
69
Compress iUV600s Series User Guide
The printer will
automatically align the
successive prints
correctly progressively
down the page.
