ABQ Industrial TotalCheck Owner's Manual

Moisture meter/thermo-hygrometer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TotalCheck
MOISTURE METER/THERMO-HYGROMETER
Owner's Manual
Version 3.02
For Total Check Meters starting with Serial #12468
Distributed by: ABQ Industrial LP USA
Tel: +1 (281) 516-9292 / (888) 275-5772 eFax: +1 (866) 234-0451
Web: https://www.abqindustrial.net E-mail: info@abqindustrial.net
Delmhorst Instrument Co.
Rev 13
June 11, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TotalCheck and is the answer not in the manual?

Questions and answers

Related Manuals for ABQ Industrial TotalCheck

Summary of Contents for ABQ Industrial TotalCheck

  • Page 1 MOISTURE METER/THERMO-HYGROMETER Owner’s Manual Version 3.02 For Total Check Meters starting with Serial #12468 Distributed by: ABQ Industrial LP USA Tel: +1 (281) 516-9292 / (888) 275-5772 eFax: +1 (866) 234-0451 Web: https://www.abqindustrial.net E-mail: info@abqindustrial.net Delmhorst Instrument Co. Rev 13...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE GENERAL DESCRIPTION & FEATURES OPERATING INSTRUCTIONS NAVIGATION INSTALLING THE BATTERY TO POWER THE METER ON METER USE BASIC & ENHANCED MODES USING THE METER IN BASIC MODE To Take Pins Readings in Basic Mode To Set the Alarm in Basic Pin Mode To Change the Temperature Correction To Take Scan Readings in Basic Mode To Set the Alarm in Basic Scan Mode...
  • Page 3 TAKING A READING – PRACTICAL APPLICATIONS Testing Wood Paint Failure & Moisture EIFS Using the 0-100 Numerical Reference Scale Testing Concrete Slabs for Flooring Applications Measuring RH in Concrete Slabs Testing Insulation Testing Drywall Care of Your Meter Service for Your Meter Warranty Species List Copyright ...

  • Page 4: General Description/Features

    Even with its wide range of functions, TotalCheck is intuitive and easy to operate. We recommend that you read the following pages in detail to take full advantage of all that TotalCheck has to offer.

  • Page 5: Operating Instructions

    OPERATING INSTRUCTIONS -USER GUIDE- This guide provides step-by-step instructions on powering up, using and powering down the meter. NAVIGATION: The meter uses an on-screen, menu-driven approach to navigate through the meter features, allowing for an intuitive understanding of keypad functions. Each screen presents the user with a number of selectable options.
  • Page 6 2. Ensure correct polarity, and push the battery in flush with the bottom board until the connectors snap together on both sides. Use only Duracell or Energizer alkaline 3. Replace the battery compartment lid. IMPORTANT NOTE: DO NOT REMOVE THE BATTERY WITHOUT TURNING THE METER OFF FIRST. BATTERY REMOVAL WHILE THE METER IS ON MAY CAUSE LOSS OF STORED READINGS AND MAY CORRUPT THE STORAGE MEMORY.

  • Page 7: To Power The Meter On

    ENHANCED mode to allow for on screen reading recall or download to a PC. USING THE METER IN BASIC MODE: TotalCheck is shipped from the factory set to BASIC mode. Use this option if you wish to use the meter for scan or pin readings without having to set up a job.

  • Page 8: To Set The Alarm In Basic Pin Mode

     3. Use the key to highlight the default material (Douglas Fir) if you wish to change it to a different material. Press the SELECT key to get into the SELECT MATERIAL sub menu.   4. Use the keys to highlight the material you are testing. Press the SELECT key to choose that material.

  • Page 9: To Change The Temperature Correction

    Note: The default alarm setting in scan mode is 300. TO CHANGE THE TEMPERATURE CORRECTION: TotalCheck defaults to a temperature of 70ºF. As wood temperature increases, its electrical resistance decreases and indicated moisture content rises. Lower wood temperatures result in lower indicated moisture content. A correction is necessary if the wood temperature is outside the range of 50ºF (10ºC) to 90ºF (32ºC).

  • Page 10: To Set The Alarm In Basic Scan Mode

    2. You may begin taking readings by firmly pressing the back of the meter onto the material. This will display a relative reading that ranges between 0 and 300. TO SET THE ALARM IN BASIC SCAN MODE: 1. If you wish to set the alarm to beep after a pre-selected relative value is ...

  • Page 11: To Reset The Meter To Default Settings In Basic Mode

    JOB DEFINITION: Using TotalCheck in ENHANCED mode allows you to define jobs. In this mode, TotalCheck also stores each reading and allows you to download the data to a PC or Copyright  2006, Delmhorst Instrument Co. Page 11 of 32...

  • Page 12: To Create Or Modify A Job In Pin Mode

    laptop via Infrared connection. Jobs may be defined only when using the meter in pin mode or RH-T mode. Scanned readings cannot be part of a job. TO CREATE OR MODIFY A JOB IN PIN MODE: 1. From the Enhanced Main Menu, highlight PIN MODE. ...

  • Page 13: To Set Temperature Correction

    TO SET TEMPERATURE CORRECTION TotalCheck defaults to a temperature of 70ºF. As wood temperature increases, its electrical resistance decreases and indicated moisture content rises. Lower wood temperatures result in lower indicated moisture content. A correction is necessary if the wood temperature is outside the range of 50ºF (10ºC) to 90ºF (32ºC). Set the temperature accordingly and the meter will make the correction.

  • Page 14: To Take Pin Readings In Enhanced Mode

    All wood materials: Drywall: 1.0% Concrete: 68 (on the 0-100 relative scale) TO TAKE PIN READINGS IN ENHANCED MODE:   1. From the Enhanced Main Menu, use the keys to highlight #1, PIN MODE. 2. Press the SELECT key to get into the ENHANCED READ screen. The current location will stay the same while toggling between scan and pin modes.

  • Page 15: To Set The Alarm In Enhanced Scan Mode

    1. In the MAIN Menu, highlight option #2: SCAN The screen will look as follows: 2. You may begin taking readings by firmly pressing the back of the meter onto the material. 3. This will display a relative reading that ranges between 0 and 300. TO SET THE ALARM IN ENHANCED SCAN MODE: 1.

  • Page 16: Main Menu Options

    1. From the ENHANCED Main Menu, use the   key to highlight RH-T MODE. Then, press the SELECT key to get into the RH-T mode main menu. The meter will display the main RH-T mode main menu, as shown below: 2.

  • Page 17: Stored Readings

    • The first line indicates the Moisture Content (MC) job being analyzed. • The second line shows the number of readings stored in the specific job • The third line shows the Average MC value for all stored readings in the specific job.
  • Page 18 • STORED READINGS:   1. From the storage sub menu, use the keys to highlight “STORED READINGS.” Press the SELECT key to enter the stored readings sub menu. There are two available selections from this menu, as follows:   2.

  • Page 19: Clear Memory

    A selected job containing readings offers two other selectable options: “VIEW SET” and “DONE”. VIEW SET: This option allows the user to view a specific range of readings in a particular job, as opposed to the entire set, by providing a configurable start point. It becomes useful when large numbers of readings are present in the meter.

  • Page 20: Ir Link

    Program (double click the application icon or choose the program from the Start Menu). 2. Once the TotalCheck and base unit are lined up and the base unit is connected to a USB port (a green LED should be lit), select the IR LINK option in the Main Menu.
  • Page 21 established with the base unit. The base unit will also indicate communication established by turning off the green LED and turning on a red LED. 3. Press the “MANAGE DATA” button in the Delmhorst Instrument Co. Universal Application Program. The meter will display “Data” on the screen and the base unit will alternately turn on a yellow and red LED while data transfer takes place (red indicates communication between the meter and Base Unit, while yellow indicates communication between the base unit and...

  • Page 22: Setup Menu

    NOTE: Individual records cannot be downloaded to the PC. The entire storage content is delivered to the PC during a link session. SETUP MENU: The Setup group of features allows access to the configurable parameters of the meter. They are: Date and Time, Power-off time, Backlight, and Conversions (temperature mode and electrode type).
  • Page 23 • Set Power Off time: This menu option allows the user to change the amount of time allowed to lapse between the last key press and meter shut-down. Allowable range is 1min – 9min, with a default value of 2min. •...

  • Page 24: Taking A Reading - Practical Applications

    TAKING A READING – PRACTICAL APPLICATIONS The following application notes are intended for use with the meter in PIN MODE. TESTING WOOD: Use the 26-ES electrode on hard materials, wood over 2 inches thick, or for any application where using the insulated pins are needed for best accuracy. The 2-E electrode, with pins that penetrate 5/16”...

  • Page 25: Paint Failure & Moisture

    Also look for visible signs of water damage. If you feel a problem exists, use the TotalCheck with a # 21-E electrode. This electrode includes the #608 - (4") insulated pins or #608/001 (6”) insulated pins in EIFS Package.

  • Page 26: Using The 0-100 Numerical Reference Scale

    new reading until the SELECT button is pressed and released again during the reading cycle. *If the sheathing is plywood, set the meter to the proper species if known. If the species is unknown, use Douglas Fir. If the sheathing is gypsum material, set the species to Drywall.

  • Page 27: Measuring Rh In Concrete Slabs

    SCAN mode may also be used for comparative testing on smooth slab surfaces. MEASURING RH IN CONCRETE SLABS TotalCheck can be used to measure the RH in a concrete slab in accordance with the ASTM F-2170 Standard Test Method for Determining Relative Humidity in Concrete Floor Slabs.

  • Page 28: Testing Insulation

    Take reading using the RH/TEMP mode of TotalCheck as described on pages 10 and 15. ⇒ Alternately, insert the RH probe sensor into the sleeve immediately after setting the sleeve.
  • Page 29 ⇒ To add a reading to the previously stored readings, release the SELECT button if you are in triggered mode. If you are in continuous mode, the meter will not store a new reading until the SELECT button is pressed and released again during the reading cycle.

  • Page 30: Care Of Your Meter

    CARE OF YOUR METER  Store your meter in a clean, dry place. The protective carrying case provided is an ideal storage place when the meter is not in use. If the meter has been left in a hot or cold environment overnight or for an extended period, the calibration of the pinless mode may be adversely affected.

  • Page 31: Warranty

    90 days. If, within the warranty period of the Model TotalCheck, you find any defect in material or workmanship, return the meter following the instructions in the “Service for Your Meter” section. This warranty does not cover abuse, alteration, misuse, damage during shipment, improper service, unauthorized or unreasonable use of the meter or electrodes.

  • Page 32: Species List

    Towaco, NJ 07082-1025 Tel: 973-334-2557 / 877-DELMHORST Fax: 973-334-2657 info@delmhorst.com www.delmhorst.com Distributed by: ABQ Industrial LP USA Tel: +1 (281) 516-9292 / (888) 275-5772 eFax: +1 (866) 234-0451 Web: https://www.abqindustrial.net E-mail: info@abqindustrial.net Copyright  2006, Delmhorst Instrument Co. Page 32 of 32...
