Dispensers
Water & Ice Dispenser
(See Controls)
Press the glass gently against the dispenser cradle.
The spill shelf is not self-draining. To reduce water
spotting, the shelf should be cleaned regularly.
If no water is dispensed when the refrigerator is first
installed, there may be air in the water line system. Press
the dispenser paddle for at least five minutes to remove
trapped air from the water line and to fill the water system.
To flush out impurities in the water line, throw away the
first six full glasses of water.
Automatic Icemaker
Icemaker Kit IM4D is available for models that are icemaker-ready. For installation instructions see IM4D owner's manual
Ice maker
Green
Power Light

Shelves and Bins

Not all features are on all models
Lift up on the front and
then up on the back to
remove shelf.
Ice Bucket and Dispenser (on some models)
• Open the ice box door on inside of the left door.
• Pull up and out on the ice bucket in the left hand door to remove it from the compartment .
• To replace the ice bucket, set it on the guide brackets and push until the ice bucket seats properly.
49-60803
(on some models)
Dispenser
Tray
(on some models)
begin making ice.
The ice maker will produce
seven cubes per cycle
cubes in a 24-hour period,
compartment temperature,
room temperature, number of
door openings and other use
conditions.
Quick Space Shelf (on some models) can retract to half its
out and up, slide shelf back until it stops to create half-
shelf. Pull up and forward , then down to return to full shelf.
Internal Water Dispenser
(on some models)
The water dispenser is located on the left wall inside the
refrigerator compartment.
To dispense water:
1. Hold the glass against the recess.
2. Push the water dispenser button.
releasing the dispenser button. Water
may continue to dispense after the
button is released.
If no water is dispensed when the
refrigerator is first installed, there may
be air in the water line system. Press the dispenser button
for at least 5 minutes to remove trapped air from the water
line and to fill the water system. During this process, the
dispenser noise may be loud as the air is purged from the
water line system. To flush out impurities in the water line,
throw away the first 6 glassfuls of water.
NOTE: To avoid water deposits, the dispenser should be
cleaned periodically by wiping with a clean cloth or sponge.
Throw away the first few batches of ice to allow the water
line to clear.
CAUTION
injury, avoid contact with the moving parts of the ejector
mechanism, or with the heating element that releases the
cubes. Do not place fingers or hands on the automatic ice
making mechanism while the refrigerator is plugged in.
5
can be removed for
cleaning.
Ice bucket
