Appendix B:
System specifications
Item
Monitor
Scanner
Operating power
Operating temperature
Storage/Transportation temperature
Operating pressure & altitude
Storage/Transportation pressure & altitude
Relative humidity
Dimensions
Net weight
Shipping weight
17
iTero Element 5D laptop configuration operation manual
Description
Laptop monitor
Scanner emits red laser light (680nm Class 1) as well as white LED emissions.
100-240VAC- 50/60 Hz – 40VA (max)
18°C to 26°C / 64.4°F to 78.8°F
-5°to 50°C 23° to 122°F
Pressure: 520 mmHg to 760 mmHg (~69 kPa to ~101 kPa)
Altitude: 0 feet to 10,000 feet
Pressure: 430 mmHg to 760 mmHg (~57 kPa to ~101 kPa)
Altitude: 0 feet to 15,000 feet
Operating: 40% to 70%; Storage: 30% to 90%
iTero Element 5D laptop
iTero Element 5D
configuration hub:
wand unit:
Length: 206 mm (~8 in)
Length: 346 mm (13.3 in)
Width: 94 mm (~3.7 in)
Width: 50 mm (2.0 in)
Depth: 36.5 mm (~1.4 in)
Depth: 68 mm (2.7 in)
iTero Element 5D laptop configuration hub: ~0.5 kg (~1 lbs)
Scanning Unit: 0.47 kg (~1 lbs)
Empty Case: ~2 kg (~4.5 lbs)
~8 kg (~17.6 lbs)
Cradle:
Case:
Length: 262 mm (~10 in)
Height: 326.5 mm (~13 in)
Width: 89 mm (~3.5 in)
Width: 455 mm (~18 in)
Depth: 52 mm (~2 in)
Depth: 184 mm (~7 in)
