Sper scientific AquaShock 850046K User Manual

Do kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AquaShock® DO Kit
850046K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AquaShock 850046K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sper scientific AquaShock 850046K

Summary of Contents for Sper scientific AquaShock 850046K

  • Page 1 AquaShock® DO Kit 850046K...
  • Page 2 Sper Scientific. Sper Scientific 8281 E. Evans Rd., Suite #103, Scottsdale, AZ 85260 Tel: (480) 948-4448 Fax: (480) 967-8736 Web: www.sperscientific.com...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ........4 FEATURES.

  • Page 4: Introduction

    INTRODUCTION The Sper Scientific AquaShock® DO Meter is the most waterproof, rugged and reliable DO meter on the market. It is fully waterproof, including probe connections. As with all AquaShock® meters, the DO Meter is completely shockproof, floats, and features a double...

  • Page 5: Features

    FEATURES • Floats • Shockproof • IP67 Waterproof • Protective soft grip outer layer • Rechargeable Lithium Ion battery • Multi-line display LCD screen • Reads DO (Dissolved Oxygen) • Auto Ranging • Selectable Automatic or Manual Temperature Compensation • Celsius or Fahrenheit selectable •...

  • Page 6: Lcd Display

    LCD DISPLAY Name Description 1 Ready Displayed when measuring results are stable 2 Scale Unit Current measurement scale unit 3 Measuring Results Current measurement value 4 ATC/MTC Automatic/Manual Temperature Compensation indicator 5 Temperature Scale Current temperature measurement unit 6 Temperature Value Current temperature measurement value 7 Battery Icon...

  • Page 7: Power Supply

    LCD DISPLAY Probe Life Icon: More than 90% life remaining More than 85 – 90% life remaining More than 80 - 85% life remaining Less than 80% life remaining Battery Power Icon: Battery voltage is more than 7.7V shows full. Battery voltage between 7.2V and 7.7V shows 2 cells.

  • Page 8: Keypad

    KEYPAD DO Meter Name 1st Function 2nd Function Power/Backlight/ Power on/off Backlight on/off Low Battery Setup Setting parameters Confirm setting MI↑ Store data ↑ MR↓ Recall data ↓ Max/Min/Ave Max/Min/Ave Range/Temp Switch measuring Set temperature value scale Hold/Exit Hold Exit Calibration...

  • Page 9: Setup Mode

    SETUP MODE The Setup Mode allows you to customize the following meter preferences and defaults: • Temperature Scale • Clock Setting • Restore Factory Defaults • MTC (Manual Temperature Compensation) Temperature Coefficient • View Calibration Points • View Probe Parameters •...
  • Page 10 4. Press ↑ to increase the value by 1. Hold down ↑ to continually increase the value. Press ↓ to decrease the value by 1. Hold down ↓ to continually decrease the value. Press SETUP to save and the meter automatically moves to the month setting (see Fig.
  • Page 11 Restore Factory Settings 1. Press SETUP to enter the Setup Mode. 2. Press ↑ or ↓ to select the Restore Factory Settings screen (see Fig. A). 3. Press SETUP to confirm selection. “NO” will flash on the LCD. (see Fig. B). 4.
  • Page 12 Set MTC (Manual Temperature Compensation) Temperature Coefficient Note... Only perform this setting when ATC Temperature Probe is not available. 1. Press RANGE for 2 seconds to enter the Set Temperature Mode (see Fig. A). The temperature value will flash (see Fig. B). 2.
  • Page 13 View the Probe Data 1. Press SETUP once to enter the Set up mode. 2. Press ↑ or ↓ to select the View Probe screen (see Fig. A). 3. Press SETUP once to enter the View Slope screen which shows the electrode slope (see Fig B). 4.
  • Page 14 Set Barometric Pressure Parameters 1. Press SETUP to enter the Setup Mode. 2. Press ↑ or ↓ until the Bar. Pressure screen is seen (see Fig. A). 3. SETUP to enter the Select Bar. Unit screen (see Fig. B or Fig. C). 4.
  • Page 15 Fig. E Set RH Parameters 1. Press SETUP to enter the Setup mode. 2. Press ↑ or ↓ to display the Set RH screen (see Fig. A) 3. Press SETUP to enter the Set RH screen (see Fig. B). The current set value will flash. 4.
  • Page 16 Set Salinity Compensation 1. Press RANGE to select mg/L (ppm) measurement scale. 2. Press SETUP to enter the Setup Mode. 3. Press ↑ or ↓ to display the Set Salinity screen (see Fig. A) 4. Press SETUP to enter the Set SAL. Value screen (see Fig. B). 5.

  • Page 17: Probe Setup

    Set % Offset 1. Press RANGE to select % measuring scale. 2. Press SETUP to enter the Setup Mode. 3. Press ↑ or ↓ to display Set % Offset screen (see Fig. A). 4. Press SETUP to enter the Set % Offset mode. The current value will flash (see Fig.

  • Page 18: Calibration

    4. Recalibrate the probe using a DO meter. This procedure can also be used when replacing the membrane caps. Extra caps are included with this probe because they may need to be replaced occasionally. CALIBRATION Note... While performing calibration, if the measurement value reads from 10% to 50% the display will show “Error”...
  • Page 19 100% Calibration Note... Only when the measurement value is above 50% can the meter be calibrated at 100%. All other keys except POWER ON/OFF and HOLD are inoperable while performing calibration. 1. Clean the probe thoroughly with deionized water. 2. Press RANGE to select the % saturation scale (see Fig. A). 3.
  • Page 20 0% Calibration Note... The measurement value must read below 10% to calibrate the meter at 0%. All other keys except POWER ON/OFF and HOLD are inoperable while performing calibration. 1. Clean the probe thoroughly with deionized water. 2. Press RANGE to select the % saturation scale (see Fig. A). 3.
  • Page 21 Calibrate dissolved oxygen in mg/L (ppm) mode Note... mg/L (ppm) calibration can only be performed after 100% calibration has been completed. 1. Clean the probe thoroughly with deionized water. 2. Put the probe into a sample where the oxygen content is known.
  • Page 22 View Calibration Points 1. Press RANGE chose the scale you want view. 2. Press SETUP to enter the Setup mode. 3. Press ↑ or ↓ to select the View Cal Data screen (see Fig. A). 4. Press SETUP to enter the mode. (The 100% scale will display as in Fig.

  • Page 23: Measurement Procedures

    Fig. E Fig. F Auto Ranging During measurement and calibration this meter will automatically switch to the correct range. MEASUREMENT PROCEDURES Note... Before beginning measurements, connect the probe to the meter, turn the meter on and polarize the electrode for 15 minutes. Turning the Meter On/Off 1.
  • Page 24 Backlight 1. With the meter on press POWER again to turn the backlight on/off. Scale Selection 1. Press RANGE to switch between the % of Saturation and Milligrams per Liter (mg/L) scales (see Fig. A and Fig. B). Fig. A Fig.
  • Page 25 Recall Memory 1. Press RANGE to select the scale for recall. 2. Press MR to enter the Recall mode and view the last saved reading (see Fig. A and Fig. B). The date and time are on cyclical display. If there is no saved data “- - - -” is displayed (see Fig.
  • Page 26 Hold 1. Press HOLD to hold the value (see Fig. A). 2. Press HOLD to release the hold value. Note… When in Hold Mode, all other functions will be disabled except turning the meter off, backlight function, saving and exiting Hold Mode.

  • Page 27: Specifications

    Fig. C Fig. A Fig. B Fig. D Fig. E Fig. F Fig. G Fig. H SPECIFICATIONS Mode mg/L(ppm) % Saturation Temperature Range 0.00 to 19.99 0.0 to 199.9% 32 to 122°F mg/L (ppm) (0 to 50°C) Resolution 0.01mg/L (ppm) 0.1% 0.1°F/°C Accuracy...

  • Page 28: Warranty

    WARRANTY Sper Scientific warrants this product against defects in materials and workmanship for a period of five (5) years from the date of purchase, and agrees to repair or replace any defective unit without charge. If your model has since been discontinued, an equivalent Sper Scientific product will be substituted if available.
