- Page 1 FILE NO.SVM-18044-3 SERVICE MANUAL AIR-CONDITIONER (SPLIT TYPE) OUTDOOR UNIT DIGITAL INVERTER> RAV-GM1101AT8P-E (TR) RAV-GM1401AT8P-E (TR) RAV-GM1101AT8JP-E RAV-GM1401AT8JP-E Revised on June, 2018...
-
Page 2: Table Of Contents
SETUP AT LOCAL SITE AND OTHERS ................ 64 9-1. Calling of Error History ......................... 64 9-2. Others..............................66 DETACHMENTS ......................67 10-1. RAV-GM1101AT8 , GM1401AT8 ..................... 67 11. EXPLODED VIEWS AND PARTS LIST ................79 11-1. RAV-GM1101AT8P-E, GM1101AT8JP-E, GM1101AT8P-TR RAV-GM1401AT8P-E, GM1401AT8JP-E, GM1401AT8P-TR ............79 - 2 -... -
Page 3: Safety Caution
Toshiba Carrier Corporation or, alternatively, he or she has been instructed in such matters by an individual or individuals who have been trained and is thus thoroughly acquainted with the knowledge related to this work. - Page 4 FILE NO.SVM-18044-3 Definition of Protective Gear When the air conditioner is to be transported, installed, maintained, repaired or removed, wear protective gloves and “safety” work clothing. In addition to such normal protective gear, wear the protective gear described below when undertaking the special work detailed in the table below.
- Page 5 FILE NO.SVM-18044-3 Warning Indications on the Air Conditioner Unit [Confirmation of warning label on the main unit] Confirm that labels are indicated on the specified positions If removing the label during parts replace, stick it as the original. Meaning of symbols displayed on the unit This mark is for R32 refrigerant only.
- Page 6 FILE NO.SVM-18044-3 CAUTION CAUTION Do not touch the aluminum fins of Do not touch the aluminum fins of the unit. the unit. Doing so may result in Doing so may result in injury. injury. CAUTION CAUTION BURST HAZARD BURST HAZARD Open the service valves before the Open the service valves before operation, otherwise there might be the burst.
- Page 7 FILE NO.SVM-18044-3 Precaution for Safety The appliance shall be installed in accordance with national wiring regulations. Capacity shortages of the power circuit or an incomplete installation may cause an electric shock or fire. DANGER Before carrying out the installation, maintenance, repair or removal work, be sure to set the circuit breaker to the OFF position.
- Page 8 FILE NO.SVM-18044-3 When you access inside of the electric cover to repair electric parts, wait for about five minutes after turning off the breaker. Do not start repairing immediately. Otherwise you may get electric shock by touching terminals of high-voltage capacitors. Natural discharge of the capacitor takes Electric about five minutes.
- Page 9 FILE NO.SVM-18044-3 When performing repairs using a gas burner, replace the refrigerant with nitrogen gas because the oil that coats the pipes may otherwise burn. When repairing the refrigerating cycle, take the following measures. 1) Be attentive to fire around the cycle. When using a gas stove, etc., be sure to put out fire before work;...
- Page 10 FILE NO.SVM-18044 When the refrigerant gas leaks, find up the leaked position and repair it surely. If the leaked position cannot be found up and the repair work is interrupted, pump-down and tighten the service valve, otherwise the refrigerant gas may leak into the room. When gas touches to fire such as fan heater, stove or cocking stove, it may generate noxious gases, causing a fire though the refrigerant gas itself is innocuous.
- Page 11 FILE NO.SVM-18044-3 Only a qualified installer ( 1) or qualified service person ( 1) is allowed to install the air co nditioner. If the air conditioner is installed by an unqualified individual, a fire, electric shocks, injury, water leakage, noise and/or vibration may result. Before starting to install the air conditioner, read carefully through the Installation Manual, and follow its instructions to install the air conditioner.
- Page 12 1) Refer to the “Definition of Qualified Installer or Qualified Service Person.” Declaration of Conformity Manufacturer: TOSHIBA CARRIER (THAILAND) CO., LTD. 144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road, Tambol Bangkadi, Amphur Muang, Pathumthani 12000, Thailand TOSHIBA CARRIER EUROPE S.A.S...
- Page 13 FILE NO.SVM-18044-3 Specifications Sound power level (dBA) Model Weight (kg) Cooling Heating RAV-GM1101AT8P-E RAV-GM1101AT8JP-E RAV-GM1401AT8P-E RAV-GM1401AT8JP-E RAV-GM1101AT8P-TR RAV-GM1401AT8P-TR : Under 70 dBA - 13 -...
- Page 14 FILE NO.SVM-18044-3 Refrigerant R32 This air conditioner adopts a new HFC type refrigerant (R32) which does not deplete the ozone layer. 1. Safety Caution Concerned to Refrigerant R32 Be sure that water, dust, the former refrigerant or the former refrigerating oil is not mixed into the refrigerating cycle of the air conditioner with refrigerant R32 during installation work or service work.
- Page 15 FILE NO.SVM-18044-3 <Caution items> 1) The opposite side dimension of the air-conditioner's flared nut using R32 and the shape of the charge port are the same as those of R410A. 2) Be careful not to charge refrigerant by mistake. Should the different type of refrigerant mix in, be sure to recharge the refrigerant 3) Do not mix the other refrigerant or refrigerating oil with the refrigerant.
- Page 16 FILE NO.SVM-18044-3 4. Tools Tools exclusive for R410A (The following tools for R410A are required.) : R410A tools available : Partly unavailable, : R410A tools unavailable Installation/service tools Applicability to R32 air Applicability to R22 air conditioner or not conditioner or not Tools / Equipment specification 1 Flare tool...
-
Page 17: Specifications
FILE NO.SVM-18044-3 1. SPECIFICATIONS 1-1. Outdoor Unit <Digital Inverter> Model name Outdoor unit RAV-GM 1101AT8 1401AT8 3 phase 380-415V, 50Hz Power supply 3 phase 380V, 60Hz (Power exclusive to outdoor is required.) Type Hermetic compressor Compressor Motor (kW) Pole Refrigerant charged (kg) Refrigerant control Pulse motor valve... -
Page 18: Operation Characteristic Curve
FILE NO.SVM-18044-3 1-2. Operation Characteristic Curve RAV-GM1101AT8 P , GM1401AT8 P <Cooling> <Heating> GM140 GM140 GM110 GM110 90 100 110 120 Compressor Speed (RPS) Compressor Speed (RPS) Capacity variation ratio according to temperature <Cooling> <Heating> GM110 GM140 Outdoor temp. (°C) 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 - 18 -... -
Page 19: Construction Views (External Views)
FILE NO.SVM-18044 2. CONSTRUCTION VIEWS (EXTERNAL VIEWS) 2-1. RAV-GM1101AT8 , GM1401AT8 - 19 -... - Page 20 FILE NO.SVM-18044 RAV-TWP30E2, RAV-TWP50E2 (Simultaneous Twin) Inner diameter Ø C Inner Inner diameter Ø D diameter Ø D Model (RBC-) Liquid side Ø9.5 Ø6.4 TWP30E2 Gas side Ø15.9 Ø12.7 Liquid side Ø9.5 Ø9.5 TWP50E2 Gas side Ø15.9 Ø15.9 - 20 -...
-
Page 21: Systematic Refrigerating Cycle Diagram
FILE NO.SVM-18044 3. SYSTEMATIC REFRIGERATING CYCLE DIAGRAM 3-1. Indoor Unit Single type (Combination of 1 indoor unit and 1 outdoor unit) (Indoor unit) Distributor (Strainer incorporated) TCJ sensor Strainer Air heat exchanger TC sensor Heating Cooling Refrigerant pipe Refrigerant pipe at liquid side at gas side (Outer dia : ØB) -
Page 22: Outdoor Unit
FILE NO.SVM-18044 3-2. Outdoor Unit RAV-GM1101AT8 P , GM1401AT8 P Ball valve Packed valve Outer dia. Ø15.88 Outer dia. Ø9.52 Pressure Strainer switch TS sensor (Pulse Motor Valve) (CAM-BD25TCTH-1) TL sensor TD sensor Strainer 4-way valve (STF-H0218) sensor Heat exchanger Muffler Ø8, 2 rows, 40 steps FP1.3 flat fin... - Page 23 FILE NO.SVM-18044 RAV-GM1101AT8 Pressure Pipe surface temperature (°C) Temp Comp. (MPa) (kg/cm (TD) (TS) (TC) (TE) Standard 31.6 HIGH 27/19 35/- 3.01 0.85 Cooling Overload 3.72 1.10 36.7 11.5 HIGH 32/24 46/- Low load 2.03 0.82 20.7 18/15.5 -15/- Standard 2.51 0.63 26.2...
-
Page 24: Wiring Diagram
FILE NO.SVM-18044 4. WIRING DIAGRAM 4-1. RAV-GM1101AT8 , GM1401AT8 D805 D804 D803 D802 D801 D800 - 24 -... -
Page 25: Specifications Of Electrical Parts
FILE NO.SVM-18044 5. SPECIFICATIONS OF ELECTRICAL PARTS Outdoor Unit Parts name Type Specifications Output 3000W Compressor RX330A2T-20M Outdoor fan motor WDF-340-A100-1 Output 100W High pressure switch ACB-4UB83W ON : 3.2MPa, OFF : 4.15MPa PMV-Coil CAM-MD12TCTH-7 DC12V Coil-value-4way STF-H01AJ1872A1 AC220V ~ 240V Reactor CH-55-2Z-T 5.4~6.14mH, 14A... -
Page 26: Refrigerant R32
FILE NO.SVM-18044 6. . REFRIGERANT R 6. When an air conditioning system charged with a This air conditioner adopted the R32 refrigerant which does not damage the ozone layer. large volume of refrigerant is installed in a small room, it is necessary to exercise care so that, The working pressure of the refrigerant R32 is even when refrigerant leaks, its concentration 1.6 times higher than conventional refrigerant... - Page 27 FILE NO.SVM-18044 Table 6-2-1 Thicknesses of annealed copper pipes Thickness (mm) Nominal diameter Outer diameter (mm) 0.80 0.80 0.80 0.80 12.7 0.80 0.80 15.9 1.00 1.00 1. Join For copper pipes, flare joints or socket joints are used. Prior to use, be sure to remove all contaminants. a) Flare Joints Flare joints used to connect the copper pipes cannot be used for pipings whose outer diameter exceeds 20 mm.
- Page 28 FILE NO.SVM-18044 c) Insertion of Flare Nut d) Flare Processing ØD Make certain that a clamp bar and copper pipe have been cleaned. By means of the clamp bar, perform the flare processing correctly. Use either a flare tool for R410A/R32 or conventional flare tool.
- Page 29 FILE NO.SVM-18044 Fig. 6-2-2 Relations between flare nut and flare seal surface 2. Flare Connecting Procedures and Precautions a) Make sure that the flare and union portions do not have any scar or dust, etc. b) Correctly align the processed flare surface with the union axis. c) Tighten the flare with designated torque by means of a torque wrench.
-
Page 30: Tools
FILE NO.SVM-18044 6-3. Tools 6-3-1. Required Tools Refer to the “4. Tools” (Page 14) 6-4. Recharging of Refrigerant When it is necessary to recharge refrigerant, charge the specified amount of new refrigerant according to the following steps. Recover the refrigerant, and check no refrigerant remains in the equipment. -
Page 31: Brazing Of Pipes
FILE NO.SVM-18044 1) Be sure to make setting so that liquid can be charged. 2) When using a cylinder equipped with a siphon, liquid can be charged without turning it upside down. R32 refrigerant is a Single-component refrigerant that does not change its composition. Although it is possible to charge the refrigerant with either liquid or gas, charge it with liquid. - Page 32 FILE NO.SVM-18044 2. Characteristics required for flux 6-5-3. Brazing • Activated temperature of flux coincides with the As brazing work requires sophisticated techniques, brazing temperature. experiences based upon a theoretical knowledge, it must be performed by a person qualified. • Due to a wide effective temperature range, flux is In order to prevent the oxide film from occurring in hard to carbonize.
-
Page 33: Instructions For Re-Use Piping Of R22 Or R407C
6-6-3 Branching pipe for simultaneous operation system * Pipe diameter and thickness (mm) Reference Wall In the concurrent twin system, when TOSHIBA has outside thickness Material specified that branching pipe is to be used, it can be diameter (mm) (mm) reused. - Page 34 FILE NO.SVM-18044 Placement Term Curing manner location 1 month or more Pinching Outdoors Less than Pinching or 1 month Taping Indoors Every time 6-6-5 Final Installation Checks Existing pipes: Cannot be used. Are there scratches or dents on the existing pipes? •...
-
Page 35: Replenishing Refrigerant
FILE NO.SVM-18044 • (Airtight test), Vacuum dry, Refrigerant charge, Gas 6-6-7. Recovering Refrigerant leak check Use the refrigerant recovery equipment to recover the refrigerant. 6-7 Charging additional refrigerant Test run Amount of additional refrigerant shall be restricted by the following explanation to ensure the reliability. Miss-charging leads to the abnormal high pressure in the refrigerant cycle, causing a rupture, a injury and 6-6-6. -
Page 36: General Safety Precautions For Using R32 Refrigerant
FILE NO.SVM-18044 6-8 General safety precautions for using R32 refrigerant 6-8-1 Recovery 6-8-2 Decommissioning • When removing refrigerant from a system, either • Before carrying out this procedure, it is essential that for servicing or decommissioning, it is recommended the technician is completely familiar with the good practice that all refrigerants are removed safely. -
Page 37: Outdoor Control Circuit
FILE NO.SVM-18044 7. OUTDOOR CONTROL CIRCUIT 7-1. Outdoor unit control 7-1-1. P.C.board for Control and fan drive (MCC-1626) - 37 -... - Page 38 FILE NO.SVM-18044 7-1-2. P.C. board for compressor drive (MCC-1627) - 38 -...
-
Page 39: Outline Of Main Controls
FILE NO.SVM-18044-1 7-2. Outline of Main Controls 1. Pulse Modulating Valve (PMV) control 1) For PMV with GM110, 140 : 30 to 500 pulses during operation, respectively. 2) In cooling operation, PMV is controlled with the temperature difference between TS sensor and TC sensor. - Page 40 FILE NO.SVM-18044-1 3. Current release control The output frequency and the output voltage are controlled by AC current value detected by current transformer on the outdoor P.C. board so that input current of the inverter does not exceed the specified value. Current [A] Frequency down GM110...
- Page 41 FILE NO.SVM-18044-1 4-2. Heating fan control 1) An outdoor fan is controlled by TE sensor, TO sensor and compressor frequency. (It is controlled with W1 for minimum and the maximum is controlled according to the following table.) 2) At the start time, the fan is fixed for 3 minutes only with the maximum fan tap corresponded to the zone in the following table but it is controlled with TE sensor temperature after then.
- Page 42 FILE NO.SVM-18044-1 0˚C No power -1˚C Intermittent power-ON • Power-ON 10 minutes: ON / condition -2˚C 5 minutes: OFF TD < 30˚C -3˚C Continuous power-ON GM110, 140 Output power REQUIREMENT While heating the coil, the power sound may be heard. However it is not a trouble. 6.
- Page 43 FILE NO.SVM-18044-1 10. Defrost control 1 In heating operation, defrost operation is performed when TE sensor temperature satisfies any condition in A zone to D zone. 2 The defrost operation is immediately finished if TE sensor temperature has become 12°C continuing for 3 seconds or more, or it also is finished when condition of 7°C <...
-
Page 44: Troubleshooting
FILE NO.SVM-18044-1 8. TROUBLESHOOTING 8-1. Summary of Troubleshooting <Wired remote controller type> 1. Before troubleshooting 1) Required tools/instruments • screwdrivers, spanners, radio cutting pliers, nippers, push pins for reset switch • Tester, thermometer, pressure gauge, etc. 2) Confirmation points before check a) The following operations are normal. - Page 45 FILE NO.SVM-18044-1 <Wireless remote controller type> 1. Before troubleshooting 1) Required tools/instruments • screwdrivers, spanners, radio cutting pliers, nippers, etc. • Tester, thermometer, pressure gauge, etc. 2) Confirmation points before check a) The following operations are normal. 1. Compressor does not operate. •...
-
Page 46: Troubleshooting
FILE NO.SVM-18044-1 8-2. Troubleshooting 8-2-1. Outline of judgment The primary judgment to check whether a trouble occurred in the indoor unit or outdoor unit is carried out with the following method. Method to judge the erroneous position by flashing indication on the display part of the indoor unit (sensors of the receiving part) The indoor unit monitors the operating status of the air conditioner, and the blocked contents of self-diagnosis are displayed restricted to the following cases if a protective circuit works. - Page 47 FILE NO.SVM-18044-1 Check code Cause of trouble occurrence Lamp indication Operation Timer Ready Heat exchanger sensor (TCJ) error Heat exchanger sensor (TC) error Indoor unit sensor error Alternate flash Heat exchanger sensor (TA) error Discharge temp. sensor (TD) error Heat exchanger temp. sensor (TE) error Heat exchanger temp.
- Page 48 FILE NO.SVM-18044-1 - 48 -...
- Page 49 FILE NO.SVM-18044-1 Error mode detected by outdoor unit Operation of diagnostic function Judgment and measures Check Status of air Cause of operation Condition code conditioner Disconnection, short of discharge Displayed when 1. Check discharge temp. sensor (TD). Stop temp. sensor (TD) error is detected 2.
- Page 50 FILE NO.SVM-18044-1 Operation of diagnostic function Judgment and measures Check Status of air Cause of operation Condition code conditioner Discharge temp. error 1. Check refrigerating cycle (Gas leak). Displayed when * Discharge temp. (TD) over Stop 2. Trouble of PMV (Pulse Motor Value). error is detected specified value was detected.
- Page 51 FILE NO.SVM-18044-1 Contents Error Display * When fixations of the errors were overlapped, the latest error is displayed. LED Display Check code ITEM [Wired remote D800 D801 D802 D803 D804 D805 controller] (Yellow) (Yellow) (Yellow) (Yellow) (Yellow) (Green) Normal Discharge temperature sensor (TD) error Heat exchanger temperature sensor (TE) error Heat exchanger temperature sensor (TL) error Outside air temperature sensor (TO) error...
- Page 52 FILE NO.SVM-18044-1 8-2-4. Diagnostic Procedure for Each Check Code (Outdoor Unit) 1) This section describes the diagnostic method for each check code displayed on the wired remote controller. 2) In some cases, a check code indicates multiple symptoms. In this case, confirm LED display on the outdoor P.C. board to narrow the contents to be confirmed. 3) The check code on the wired remote controller is displayed only when the same error occurred continuously by multiple times while LED of the outdoor P.C.
- Page 53 FILE NO.SVM-18044-1 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) – [E04] [Indoor/Outdoor communication error] Is setting of group address Check CODE No. [14]. of remote controller correct? Are inner wiring and indoor/outdoor Correct wiring indoor/outdoor control wires (1, 2, 3) correct? control wires...
- Page 54 FILE NO.SVM-18044-1 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [F08] [Outside air temp. sensor (TO) error] Is connection of CN602 correct? Correct connector. Sensor error → Replace Is resistance value of TO sensor correct? Check outdoor P.C.
- Page 55 FILE NO.SVM-18044-1 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [F31] [EEPROM error] Check outdoor P.C. board. Defect → Replace [H01] [Compressor break down] Is power supply voltage Correct power supply line. correct?AC342 to 457V Is wire connection correct? Compressor lead...
- Page 56 FILE NO.SVM-18044-1 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [H03] [Current detection circuit error] Check outdoor P.C. board. Defect → Replace [H04] [Case thermostat operation] Correct connector. Are CN500 connection and case thermostat correct? Case thermostat error →...
- Page 57 FILE NO.SVM-18044-1 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [P04] [High pressure SW system error] Does high pressure switch Wiring check, Is circuit wiring correct? operate? Correct. Are parts of Parts check high pressure switch correct? Defective →...
- Page 58 FILE NO.SVM-18044-1 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [P05] [Power supply error] Is there no open phase of Correct wiring the power supply? Is there no down or up of power supply voltage? Confirm electric construction, etc.
- Page 59 FILE NO.SVM-18044-2 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [4-way valve inverse error] [P19] Is the 4-way valve Is operation of 4-way valve coil is normal? correct? Replace coil (Check the resistance value (Check pipe temp.
- Page 60 FILE NO.SVM-18044-2 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [P22] [Fan system error] Is AC mains voltage Check wiring construction. correct?(AC342 to 457V) Ask repair of power supply. Rotate shaft of the fan motor by hands during power-OFF.
- Page 61 FILE NO.SVM-18044-2 Check Outdoor Check and troubleshooting code LED display (Item without special mention Indicates part of outdoor unit.) [P26] [Short-circuit of compressor drive element] Are connections of compressor lead and reactor correct? Correct wiring. (Check referring to the Wiring diagram.) Does the same error occur in Replace outdoor P.C.
- Page 62 FILE NO.SVM-18044-2 Temperature – Resistance value characteristic table Temperature sensor TD, TL sensors TE, TS, TO sensors Representative value Representative value Temperature Resistance value (kΩ) Temperature Resistance value (kΩ) (°C) (°C) (Minimum value) (Standard value) (Maximum value) (Minimum value) (Standard value) (Maximum value) 32.33 33.80 35.30...
-
Page 63: Table Inspection Of Outdoor Unit Main Parts
FILE NO.SVM-18044-2 8-3. Table Inspection of outdoor unit main parts Parts name Checking procedure Compressor Measure the resistance value of each winding by using the tester. (Model : RX330A2T-20M) Position Resistance value Red – White White – Black 1.20 Ω White Black Black –... -
Page 64: Setup At Local Site And Others
FILE NO.SVM-18044-2 9. SETUP AT LOCAL SITE AND OTHERS 9-1. Calling of error history <Contents> The error contents in the past can be called. <Procedure> Push buttons simultaneously for 4 seconds or more to call the service check mode. Service Check goes on, the item code 01 is displayed, and then the content of the latest alarm is displayed. - Page 65 FILE NO.SVM-18044-2 ■ Indoor unit power-ON sequence Power ON • The unit without power feed waits entirely → Waiting status is released by system start • Reboot when power is fed on the way <By feed unit> <Automatic address judgment> Not normal 3 minutes elapse Gr construction check...
-
Page 66: Others
FILE NO.SVM-18044-2 9-2. Others Recovering the refrigerant WARNING Don't admit air into refrigerant during recovery. Otherwise, the pressure in the freezing cycle might increase abnormally. Serious injury could occur if it bursts. [Recovering the refrigerant] • You need to recover the refrigerant when moving or repairing the indoor and/or outdoor units. You cannot do this while the air conditioner is running in cooling mode because a protective device will be tripped. -
Page 67: Detachments
FILE NO.SVM-18044-2 10. DETACHMENTS 10-1. RAV-GM1101AT8 , GM1401AT8 Part name Procedure Remarks Common procedure CAUTION Be sure to put on the gloves at working time; otherwise an injury may be caused by a part, etc. 1. Detachment 1) Stop operation of the air conditioner and then turn off switch of the breaker. - Page 68 FILE NO.SVM-18044-2 Part name Procedure Remarks Discharge 1. Detachment port cabinet Heat exchanger Discharge port cabinet 1) Carry out work of 1 of Motor base Partition plate 2) Remove screws for the discharge port cabinet and the partition plate. (ST1T Ø4 × 8, 3 pcs.) 3) Remove screws for the discharge port cabinet and the bottom plate.
- Page 69 FILE NO.SVM-18044-2 Part name Procedure Remarks P.C.board 1. Detachment (for control Inverter cover 1) Carry out work of 1 of 1. and fan motor drive) WARNING MCC-1626 Never disassemble the inverter for 3 minutes after power has been turned off because an electric shock may be caused.
- Page 70 FILE NO.SVM-18044-2 Part name Procedure Remarks P.C.board 1. Detachment (for 1) Carry out work of 4. compressor drive) WARNING P.C.board (MCC-1626) assembly Never disassemble the inverter for 3 P.C.board (MCC-1626) MCC-1627 minutes after power has been turned off banding band because an electric shock may be caused.
- Page 71 FILE NO.SVM-18044-2 Part name Procedure Remarks Exchange of 2. Reactor Reactor relay connector electric parts 1) Carry out works of 1 of (Connected to lead wire (Continued) (White) at P.C. board side) 2) Remove the relay connector connected to the control P .C. board. 3) Remove each reactor.
- Page 72 FILE NO.SVM-18044-2 No. Part name Procedure Remarks Fan motor 1) Carry out works of 1 of 1 and 2 . Loosened by turning clockwise Propeller fan 2) Remove the flange nut fixing the fan motor and the propeller fan. ∗ The flange nut is loosened by turning clockwise. (To tighten it, turn it counterclockwise.) 3) Remove the propeller fan.
- Page 73 FILE NO.SVM-18044-2 Part name Procedure Remarks Compressor 1. Removal of broken compressor Compressor lead 1) Recover the refrigerant gas. 2) Carry out works of 1 of 3) Remove the piping panel (Front). Remove screws of the piping panel (Front) and the bottom plate. (Hexagonal screw Ø4 ×...
- Page 74 FILE NO.SVM-18044-2 Part name Procedure Remarks Compressor 10) Using a burner, remove the discharge Remove Remove Compressor lead pipe and the suction pipe connected to (Discharge pipe) (Suction pipe) (Continued) the compressor. WARNING In case of removing the piping by broiling the welded part with a burner, if the piping includes oil, it may burst into flames at the moment when wax melted, so take...
- Page 75 FILE NO.SVM-18044-2 Part name Procedure Remarks Compressor 2. Mounting of compressor Suction pipe Compressor lead Header pipe 1) Mount the compressor in the reverse Accumulator (Continued) procedure of removal. Discharge pipe NOTES: ∗ After exchange of the compressor, be sure to exchange the compressor lead.
- Page 76 FILE NO.SVM-18044-2 Part name Procedure Remarks Compressor 3. Vacuuming Compressor lead 1) Connect the vacuum pump to the charge (Continued) port of the gas pipe valve and then drive the vacuum pump. 2) Carry out vacuuming until the vacuum low pressure gauge indicates 1 (mmHg). NOTE: Before vacuuming, open PMV fully.
- Page 77 FILE NO.SVM-18044-2 Part name Procedure Remarks High 1. Detachment pressure High pressure switch connector 1) Recover the refrigerant gas. switch 2) Carry out works of 1 of 1. Cut the bundling band 3) Remove the inverter cover. Remove screws between the inverter cover and the inverter box.
- Page 78 FILE NO.SVM-18044-2 Part name Procedure Remarks Fan guard 3. Detachment Bell mouth Discharge port cabinet 1) Carry out works of 1 of CAUTION To prevent scratching on the product, handle the product on a cardboard or cloth. 2) Remove the discharge port cabinet and then put on it so that the fan guard side directs downward.
-
Page 79: Exploded Views And Parts List
FILE NO.SVM-18044 11. EXPLODED VIEWS AND PARTS LIST 11-1. RAV-GM1101AT8P-E, GM1101AT8JP-E, GM1101AT8P-TR RAV-GM1401AT8P-E, GM1401AT8JP-E, GM1401AT8P-TR - 79 -... - Page 80 VALVE;PACKED 9.52 DIA 43T43589 CONDENSER ASSEMBLY 43T43590 CONDENSER ASSEMBLY 43T47372 STRAINER 43T47396 STRAINER 43T60478 ASM-SERV-MOT 43T20352 FAN-PR ( PB522 ) 43T19372 FAN GUARD (TOSHIBA) 43T22313 BELLMOUTH 43T19345 FIN GUARD 43T71302 HANDLE 43T54319 BIMETAL-THERMO 43T50307 HOLDER-THERMO 43T19333 HOLDER SENSOR 43T49346 RUBBER CUSHION 43T47410 BONNET ( 15.9D )
- Page 81 Inverter assembly (TS) (TL) (TO) (TD) - 81 -...
- Page 82 RAV- Location Part No. Description GM1101AT8P-E GM1401AT8P-E GM1101AT8JP-E GM1401AT8JP-E GM1101AT8JP-TR GM1401AT8JP-TR 43T50335 TEMPERATURE SENSOR 43T50336 TEMPERATURE SENSOR 43T50338 TEMPERATURE SENSOR 43T50337 TEMPERATURE SENSOR 43T50346 TEMPERATURE SENSOR 43T63335 SENSOR HOLDER 43T63317 HOLDER,SENSOR 43T63316 HOLDER,SENSOR 43T6W329 PC BOARD ASSY CDB (MCC-1626) 43T6W330 PC BOARD ASSY CDB (MCC-1626) 43T6W331 PC BOARD ASSY IPDU (MCC-1627) 43T60413 FUSE 43T95301 SUPPORT, SPACER...
- Page 83 WARNINGS ON REFRIGERANT LEAKAGE Check of Concentration Limit The room in which the air conditioner is to be installed requires a design that in the event of refrigerant gas leaking out, its concentration will not exceed a set limit. The refrigerant R32 which is used in the air conditioner is safe, without the toxicity or combustibility of ammonia, and is not restricted by laws to be imposed which protect the ozone layer.
- Page 84 144/9 MOO 5, BANGKADI INDUSTRIAL PARK, TIVANON ROAD, TAMBOL BANGKADI, AMPHUR MUANG, PATHUMTHANI 12000, THAILAND.
