Summary of Contents for BLAUBERG Freshbox 100 WiFi
- Page 1 Heat recovery air Handling unit Freshbox 100 WiFi USER’S MANUAL...
-
Page 2: Table Of Contents
Warranty card ....................................25 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the Freshbox 100 WiFi unit and all its modifications. - Page 3 Freshbox 100 WiFi www.blaubergventilatoren.de • Do not change the power cable length at your own discretion. Do not bend the • Do not lay the power cable of the unit in power cable. Avoid damaging the power close proximity to heating equipment.
-
Page 4: Purpose
Freshbox 100 WiFi www.blaubergventilatoren.de PURPOSE Due to the ability to save heating energy by means of energy recovery, the unit is an important element of energy-efficient premises. The unit is a component part and is not designed for stand-alone operation. -
Page 5: Technical Data
Freshbox 100 WiFi www.blaubergventilatoren.de TECHNICAL DATA The unit is designed for indoor application with the ambient temperature ranging from +1 °C up to +40 °C and relative humidity up to 80 %. The unit is rated as a Class I electrical appliance. -
Page 6: Design And Operating Principle
Freshbox 100 WiFi www.blaubergventilatoren.de DESIGN AND OPERATING PRINCIPLE Control panel Extract grille Extract spigot for a bathroom (optional)* Supply fan Supply air temperature sensor (Freshbox E1(E2)...) Limit switch G4 extract filter F8 supply filter (Freshbox ... / Freshbox E...) Counter-flow heat exchanger Reheater (Freshbox E1(E2)...) -
Page 7: Installation And Set-Up
The reheater is switched on and off by means of a button on a sensor control panel, a remote control or via mobile application. The heat exchanger freeze protection in Freshbox 100 WiFi and Freshbox E1-100 WiFi unit models without a preheater is achieved by automatic supply fan speed reduction according to extract air sensor readings. - Page 8 Freshbox 100 WiFi www.blaubergventilatoren.de Hole spacing template ADDITIONAL HOLE! DRILL UPON CUSTOMER’S REQUEST ONLY! ADDITIONAL HOLE! DRILL UPON CUSTOMER’S REQUEST ONLY! Ø 120 mm hole for Ø 100 mm air duct Ø 120 mm hole for Ø 100 mm air duct...
- Page 9 Freshbox 100 WiFi www.blaubergventilatoren.de 2.1. Remove the mounting template and drill two through holes Ø 120 mm for round air ducts. When mounting the unit with an additional extract spigot prepare a hole in the wall for a connecting bend and for laying of a rectangular air duct.
- Page 10 Freshbox 100 WiFi www.blaubergventilatoren.de To install an additional extract spigot, remove the plug on the rear part of the unit. Undo the screws, remove the plug and fix a spigot on its place using screws. Fix the unit on the wall: •...
-
Page 11: Connection To Power Mains
Freshbox 100 WiFi www.blaubergventilatoren.de CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL. -
Page 12: Control
Freshbox 100 WiFi www.blaubergventilatoren.de CONTROL The unit is controlled by means of a control panel on the unit casing, a remote control or via mobile application. Control panel 1. The unit is switched on/off using 2. Ventilation modes can be controlled by the buttons. - Page 13 Timer on/off Week-scheduled operation on/off operation on/off Unit control via the application on the mobile device The application Blauberg Freshbox is available for download at App Store //itunes.apple.com/us/app/blauberg-freshbox/id1402506523 or Play Market https://play.google.com/store/apps/details?id=com.embarcadero.BlaubergFRESHBOX or via QR codes. App Store download link...
- Page 14 Freshbox 100 WiFi www.blaubergventilatoren.de Following message is displayed if launching an application without connection to the unit: (FAN: + 16 characters of the ID number) After installing the application, connect the mobile device to the unit as to a Wi-Fi access point indicated on the control board and on the unit casing.
- Page 15 Freshbox 100 WiFi www.blaubergventilatoren.de Unit password change Go to Menu ( ) - Connection - At home. • • Choose the connection and press • Enter and confirm the password. Characters allowed: 0…9, a…z, A…Z. Press the “Change Password” button.
- Page 16 Freshbox 100 WiFi www.blaubergventilatoren.de Client – the unit operates on the home router network. Client Enter the home router details and the IP address type for the mode: • Enter the name of the Wi-Fi home router access point. •...
- Page 17 Freshbox 100 WiFi www.blaubergventilatoren.de MENU CONNECTION THROUGH CLOUD SERVER: Open the mobile app and go to -> -> Press the ADD NEW ACCOUNT button. • • Enter a login, a password and an e-mail address for password recovery. Confirm the updated details by pressing •...
- Page 18 Freshbox 100 WiFi www.blaubergventilatoren.de Control buttons: — Unit on/Standby. — Selection of pre-set speed. the Basic Settings Timers menu. — Timer activation. Timer settings are made in the Basic — Week-scheduled operation mode activation. The settings of this mode are made in...
- Page 19 Freshbox 100 WiFi www.blaubergventilatoren.de Date and time Current time and date are displayed and adjusted in this menu. Time display format: hh:mm:ss. Date format: dd.mm.yyyy. — To enter the time and date manually. — The same time as in the mobile device will be automatically set.
- Page 20 Freshbox 100 WiFi www.blaubergventilatoren.de Engineering menu Air flow rate Air flow rate, preset speed 1-5 and Boost mode are set in this section. Sensors This section displays the current status of all sensors: — outdoor air temperature. — supply air temperature.
- Page 21 Freshbox 100 WiFi www.blaubergventilatoren.de Factory settings In this section you can reset your settings to the factory settings. Communication with the unit may be lost after restoration. If necessary, reset your Wi-Fi connection. Alarms This section displays alarms and warnings.
-
Page 22: Technical Maintenance
Freshbox 100 WiFi www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! Maintenance operations of the unit are required 3-4 times per year. Maintenance includes periodic dust removal from surfaces, cleaning and replacement of filters and dry cleaning of fans. -
Page 23: Troubleshooting
Freshbox 100 WiFi www.blaubergventilatoren.de 3. Fan maintenance (once a year). Even in case of regular maintenance of the filters, some dust may accumulate inside the fans and reduce the fan performance and supply air flow. Clean the fan with a cloth or a soft brush. -
Page 24: Manufacturer's Warranty
Freshbox 100 WiFi www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Council Directive 2014/30/EU, Low Voltage Directive 2014/35/ EU and CE-marking Directive 93/68/EEC. -
Page 25: Certificate Of Acceptance
Freshbox 100 WiFi www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Heat recovery air handling unit Model Freshbox_____100_____WiFi Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 26 Freshbox 100 WiFi www.blaubergventilatoren.de...
- Page 27 Freshbox 100 WiFi www.blaubergventilatoren.de...
- Page 28 www.blaubergventilatoren.de B73-9EN-03...
