- Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for...
- Page 3 IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands Model No. : PLTF1534, PLTF1734, PLTF1934 We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of diff...
-
Page 4: Table Of Contents
SCREEN ADJUSTMENTS ............18 POWER MANAGEMENT FEATURE ..........21 TROUBLE SHOOTING ..............22 RECYCLING INFORMATION .............23 APPENDIX ..................24 SPECIFICATIONS : ProLite TF1534MC-B6X .......24 SPECIFICATIONS : ProLite TF1734MC-B6X .......25 SPECIFICATIONS : ProLite TF1934MC-B6X .......26 DIMENSIONS : ProLite TF1534MC ..........27 DIMENSIONS : ProLite TF1734MC ..........27 DIMENSIONS : ProLite TF1934MC ..........27... -
Page 5: For Your Safety
CORRECT USE OF THE AC ADAPTER Use only the AC Adapter provided by iiyama. Any deviation from this by using another type of adapter may result in damage to the accessory and the monitor by fi re or electric shock. - Page 6 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 7: Special Notes On Lcd Monitors
If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center. To protect the Touch screen surface, do not scratch or rub the screen with a hard NOTE object. -
Page 8: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce. -
Page 9: Wall Mounting
WALL MOUNTING When you use with the wall mounting, in consideration of thickness of the mounting WARNING stage, tighten the M4 Screw with washer which “L” length is 8mm to fasten the monitor. Using the screw longer than this may cause electric shock or damage because it may contact with the electrical parts inside the monitor. -
Page 10: Controls And Connectors
CONTROLS AND CONNECTORS Remote Control Touch V01* <Front> <Back> Menu Button (MENU)* Scroll Up / Brightness Button ( Scroll Down / Contrast Button ( Select Button (SELECT)* Power Switch ( Power Indicator NOTE Green: Normal operation Orange: Power Management USB Connector (USB) Remote Control Touch V01 Connector (RJ11) VGA Connector (VGA) HDMI Connector (HDMI) -
Page 11: Special Notes
SPECIAL NOTES L-Brackets and screws are necessary to install an open frame monitor. The L-Brackets are designed to be mounted to specific wall types and CAUTION hardware, in accordance with the installation instructions supplied with the Mounting Kit. Using L-Bracket or screws other than those specified in the installation instructions may damage the monitor. - Page 12 L-Brackets and screws are necessary to install an open frame monitor. For details regarding open frame monitor temperature and humidity operating conditions, see the User Manual on IIYAMA website. http://www.iiyama.com. <ProLite TF1534MC-B6X> The position of the L-bracket can be either 1.3 mm or 40.7 mm from the front of the monitor depending on which screw holes you choose for mounting it.
-
Page 13: Connecting Your Monitor
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. - Page 14 [Fitting and Removal of Cable Cover] Step 1 Put a piece of soft cloth on the table beforehand to prevent the monitor from being scratched. Lay the monitor flat on a table with front face down. < Removal > Cable Cover Remove the cable cover as shown in Step1.
-
Page 15: Computer Setting
Change to the desired signal timing listed on page 28: COMPLIANT TIMING. Windows XP/Vista/7/8/8.1/10 Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows XP/Vista/7/8/8.1/10 by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 16: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 28. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 18 for SCREEN ADJUSTMENTS. - Page 17 Direct LOCK MODE: Simultaneously press the MENU button and the button when an image is displayed through VGA, HDMI or DisplayPort. * The OSD menu is not displayed when the OSD is locked. Press the MENU button and the button simultaneously again.
-
Page 18: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Picture Option Picture Advanced Contrast Brightness H-Position V-Position Phase Clock Auto Adjust Adjustment Item Problem / Option Button to Press Too dull Contrast Direct Too intense Too dark Brightness* Direct Too bright Too left H-Position* Too right Too low V-Position* Too high... - Page 19 Press the Button to change the Sharpness picture quality in reverse numerical order. Adjust the picture quality at resolutions of less 1024 x 768(ProLite TF1534MC) / 1280 x 1024(ProLite TF1734MC/ProLite TF1934MC). You can change the picture quality. OPERATING THE MONITOR 15...
- Page 20 Picture Advanced Option OSD Timeout OSD Position User OSD H-Position OSD V-Position Adjustment Item Problem / Option Button to Press You can set the OSD display duration time OSD Timeout between 5 and 60 seconds. You can set the OSD position. OSD Position User (Upper left / Lower left / Upper right / Lower right / Center)
- Page 21 Option Picture Advanced Option Reset Language English Source Select DisplayMode Factory Adjustment Item Problem / Option Button to Press Return to Menu. Reset Factory-preset data is restored. English English Español Spanish Japanese Français French Language Traditional Chinese Deutsch German 繁中 Italiano Italian Simplifi...
-
Page 22: Screen Adjustments
fl icker or blur for the particular computer in use. ProLite TF1534MC is designed to provide the best performance at resolution of 1024 × 768, but can not provide the best at resolutions of less than 1024 × 768 because the picture is automatically stretched to fi... - Page 23 Press the SELECT Button. (Auto Adjust) Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust. Adjust the V-Position so that the top and bottom of the picture frame will fi t to the display area.
- Page 24 Adjust the Phase to correct horizontal wavy noise, fl icker or blur in the zebra pattern. In case the strong fl icker or blurs remain on a part of the screen, repeat steps NOTE because the Clock may not be adjusted correctly. If the fl icker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from again.
-
Page 25: Power Management Feature
POWER MANAGEMENT FEATURE When your computer is not in use, the power management feature will automatically reduce the power consumption of your monitor. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below. The power management function, including any timer settings is confi... -
Page 26: Trouble Shooting
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... -
Page 27: Recycling Information
RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com for monitor recycling. RECYCLING INFORMATION 23... -
Page 28: Appendix
APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS : ProLite TF1534MC-B6X Technology Projected capacitive 10pt touch Light transmission Touch Screen Communication system Surface fi nish Anti fi ngerprint coating Size Category 15" Panel technology Size Diagonal: 15"... -
Page 29: Specifications : Prolite Tf1734Mc-B6X
SPECIFICATIONS : ProLite TF1734MC-B6X Technology Projected capacitive 10pt touch Light transmission Touch Screen Communication system Surface fi nish Anti fi ngerprint coating Size Category 17" Panel technology Size Diagonal: 17" (43cm) Pixel pitch 0.264mm H × 0.264mm V 350cd/m (Typical: without Touch panel), Brightness Panel 300cd/m... -
Page 30: Specifications : Prolite Tf1934Mc-B6X
SPECIFICATIONS : ProLite TF1934MC-B6X Technology Projected capacitive 10pt touch Light transmission Touch Screen Communication system Surface fi nish Anti fi ngerprint coating Size Category 19" Panel technology Size Diagonal: 19" (48cm) Pixel pitch 0.294mm H × 0.294mm V 350cd/m (Typical: without Touch panel), Brightness Panel 300cd/m... -
Page 31: Dimensions : Prolite Tf1534Mc
DIMENSIONS : ProLite TF1534MC 337.5mm/13.3” 44.5mm/1.7” 305.0mm/12.0” DIMENSIONS : ProLite TF1734MC 369.0mm/14.5” 47.5mm/1.9” 339.0mm/13.3” DIMENSIONS : ProLite TF1934MC 416.0mm/16.4” 46.5mm/1.8” 377.5mm/14.9” APPENDIX 27... -
Page 32: Dimensions : L-Bracket
800 × 600 46.875kHz 75.000Hz 49.500MHz 48.077kHz 72.188Hz 50.000MHz 48.363kHz 60.004Hz 65.000MHz 1024 × 768 56.476kHz 70.069Hz 75.000MHz 60.023kHz 75.029Hz 78.750MHz 63.981kHz 60.020Hz 108.000MHz 1280 × 1024 79.976kHz 75.025Hz 135.000MHz NOTE * Not compliant to ProLite TF1534MC. 28 APPENDIX M134A23...
