Summary of Contents for Smeg SCB80GX

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR SAFE AND PROPER USE _______________________________4 INSTALLATION OF THE APPLIANCE ________________________________________6 ADAPTATION TO DIFFERENT TYPES OF GAS ________________________________8 FINAL OPERATIONS ____________________________________________________11 DESCRIPTION OF FRONT PANEL CONTROLS _______________________________13 USE OF THE COOKING HOB______________________________________________15 USE OF THE OVEN _____________________________________________________16 ELECTRONIC PROGRAMMER (ONLY ON EQUIPPED MODELS) _________________20 DIGITAL TIMER (CERTAIN MODELS ONLY)__________________________________22 ANALOGUE CLOCK (ONLY ON EQUIPPED MODELS) _________________________22 CLEANING AND MAINTENANCE ___________________________________________23...

  • Page 2: Instructions For Safe And Proper Use

    Introduction 1 INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKER. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE COOKER.
  • Page 3 Introduction LOWER THE GLASS COVER SLOWLY AND BY HAND. WARNING: THE GLASS COVER MAY SHATTER IF IT OVERHEATS. SWITCH OFF ALL RINGS AND WAIT FOR THEM TO COOL DOWN BEFORE CLOSING THE COVER. DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH THE HEATING ELEMENTS INSIDE THE OVEN.

  • Page 4: Instruction For The Installer

    2 INSTALLATION OF THE APPLIANCE It is the law that all gas appliances are installed by competent persons. Depending on the type of installation, it is in class 1 (Fig. A) or class 2 - sub-class 1 (Fig. B-C). Corgi gas installers are approved to work to safe and satisfactory standards. All gas installation, servicing and repair work must be in accordance with the gas safety regulations 1984 (installation and use) as amended 1990.

  • Page 5: Connecting To Natural And Lpg Gas

    Instruction for the installer If the power cable is replaced, the wire section on the new cable must not be less than 1.5 mm (3 x 1.5 cable), keeping in mind that the end to be connected to the hob must have the ground wire (yellow-green) longer by at least 20 mm.

  • Page 6: Adaptation To Different Types Of Gas

    Instruction for the installer 3 ADAPTATION TO DIFFERENT TYPES OF GAS Before performing any cleaning or maintenance work, detach the appliance from the electrical socket. The cooker hob is set for natural gas G20 (2H) at a pressure of 20 mbar for cookers with maxi oven, and for LPG G30/G31 (3+) at a pressure of 28/37 mbar for cookers with gas-bottle compartments.

  • Page 7: Instruction For The Installer

    3.2 Burner and nozzle characteristics table Rated heating Burner capacity (kW) Auxiliary Semi-rapid 1.75 Rapid Triple crown Oven Maxi Oven Grill Rated heating Burner capacity (kW) Auxiliary Semirapido 1.75 Rapido Triple crown Oven Maxi Oven Grill 3.3 Arrangement of burners on cooking hob Instruction for the installer LPG –...
  • Page 8 3.4 Adjustment of the oven burner (only for gas oven models) To adjust the oven burners follow the procedure described below from inside the oven: • Open the oven door; • Remove the oven dish and shelf. • Lift up the oven floor and remove. 3.4.1 Replacement of the oven burner nozzle •...

  • Page 9: Final Operations

    Instruction for the installer 4 FINAL OPERATIONS After replacing the nozzles, reposition the flame-spreader crowns, the burner caps and the grids. Following adjustment to a gas other than the preset one, replace the gas adjustment label fixed to the appliance with the one corresponding to the new gas. This label is in the packet together with the nozzles.

  • Page 10: Mounting The Rear Top Skirtboard (Where Applicable)

    4.4 Mounting the rear top skirtboard (where applicable) • Loosen nuts B. • Position the skirt above the top, taking care to align pins C with holes D. • Secure the skirt to the top by tightening screws A. 4.5 Wall fixing •...

  • Page 11: Description Of Front Panel Controls

    Instruction for the user 5 DESCRIPTION OF FRONT PANEL CONTROLS All the oven controls are grouped together on the front panel. The table below provides a description of the symbols used. FRONT RIGHT BURNER BACK RIGHT BURNER BACK LEFT BURNER FRONT LEFT BURNER CENTRAL BURNER If the cooker is equipped with an electronic programmer, before using the oven make sure...
  • Page 12 STATIC ELECTRIC OVEN CONTROL KNOB The various electric oven functions are suitable for different cooking modes. After selecting the function required, set the cooking temperature using the thermostat knob. OVEN LIGHT STATIC OVEN FUNCTION LOWER RESISTANCE FUNCTION VENTILATED ELECTRIC OVEN FUNCTION KNOB The various electric oven functions are suitable for different cooking modes.

  • Page 13: Use Of The Cooking Hob

    Instruction for the user 6 USE OF THE COOKING HOB 6.1 Lighting of the cooking hob burners Before lighting the hob burners check that the flame caps are in the correct position and that their burner caps are in place, making sure that the holes A in the flame caps correspond to the spark plugs and thermocouples.

  • Page 14: Use Of The Oven

    7 USE OF THE OVEN For those models with electronic programmer, before using the oven make sure that the display shows the symbol For those models with analogue clock and timer, place on the symbol 7.1 Warnings and general advice Using the oven and the grill for the first time, heat them to the maximum temperature (260°C for electric oven and 275°C for gas oven) for as long as it takes to burn off any production oil residues which could give a nasty flavour to the food.

  • Page 15: Use Of The Electric Grill

    Instruction for the user 7.4 Use of the electric grill 7.4.1 Using the grill in cookers with electric oven For short cooking procedures, such as the final crisping of meat which is already cooked, select the static grill function and turn the thermostat knob to the maximum temperature. The fan grill function (certain models only) allows actual cooking procedures to be carried out, thanks to the fan function which ensures that the heat penetrates into the food.
  • Page 16 How to use the grill Once the grill is lit, the red warning light will come on. Leave the oven to heat up for five minutes before placing the food inside. Food should be flavoured and basted with oil or melted butter before cooking. An oven dish should be used to contain the sauces.

  • Page 17: Storage Compartment

    Instruction for the user 7.6 Storage compartment A storage compartment, accessible by pulling on the top edge of the door, is located beneath the oven. Never store flammable materials such as rags, paper or the like. The compartment is intended only for holding the metal accessories of the range.

  • Page 18: Electronic Programmer (Only On Equipped Models)

    8 ELECTRONIC PROGRAMMER (ONLY ON EQUIPPED MODELS) LIST OF FUNCTIONS MINUTE-COUNTER KEY COOKING TIME KEY END-OF-COOKING KEY DECREASE TIME KEY INCREASE TIME KEY 8.1 Clock adjustment When using the oven for the first time, or after a power failure, the display flashes regularly and indicates .
  • Page 19 Instruction for the user 8.4 End of cooking When cooking is over, the oven will automatically switch off and, at the same time, an intermittent alarm will sound. After switching off the alarm, the display will once again show the right time together with the symbol , indicating that the oven has returned to manual operation mode.

  • Page 20: Digital Timer (Certain Models Only)

    9 DIGITAL TIMER (CERTAIN MODELS ONLY) This component allows an on-off beeper to be set to indicate the end of the cooking time. It is therefore just a timer, with no programming functions. LIST OF FUNCTIONS TIME-SETTING BUTTON VALUE DECREASE BUTTON VALUE INCREASE BUTTON 9.1.1 Setting the time...

  • Page 21: Cleaning And Maintenance

    Instruction for the user 11 CLEANING AND MAINTENANCE 11.1 Cleaning stainless steel and enamelled versions To maintain stainless steel in good condition it must be cleaned regularly after each use, once it has cooled down. 11.1.1 Ordinary Daily Cleaning To clean and preserve the stainless steel surfaces, always use only specific products that do not contain abrasives or chlorine-based acids.

  • Page 22: Cleaning Of Oven

    Instruction for the user 11.2.2 Grids Remove the grids and clean them in warm water with a non-abrasive detergent, taking care to remove any incrustations. Replace them on the cooking hob. Continuous contact of the grids with the flame can cause the paint near the hot areas to be altered. This is completely natural and does not compromise the functionality of the component.

  • Page 23: Extraordinary Maintenance

    Instruction for the user 12 EXTRAORDINARY MAINTENANCE The oven may require extraordinary maintenance or replacement of parts subject to wear such as seals, bulbs, and so on. The following instructions describe how to carry out these minor maintenance operations. Before any intervention, disconnect the power supply of the device. 12.1 Lubrication of the taps and gas oven thermostat In time the taps and gas oven thermostat may be difficult to turn or may be blocked.
  • Page 24 914772242/ A...
