Technical Specifications - FONESTAR AIP-4010 Instruction Manual

TECHNICAL SPECIFICATIONS

CHARACTERISTICS
INPUTS
OUTPUTS
POWER SUPPLY
DIMENSIONS
ACCESSORIES
SOFTWARE
AIP-4010
IP audio Transmitter.
For audio transmission through streaming using multicast through the
local area network (LAN).
General purpose inputs and outputs.
Remote upgrading through software for PC or locally through SD or
USB.
1 line, 2 x RCA and 3.5 mm stereo jack
4 separate programmable inputs for events activation through contact
closure, euroblock
1 USB/SD port for firmware upgrading
1 ethernet 10/100 base T, RJ-45
4 separate programmable outputs for opening and closing contacts,
euroblock
100-240 V AC, 16 W
337 x 44.5 x 240 mm depth. 1 U 19" rack
Mounts for assembly in 19" rack
Software for PC with automatic detection of the AIP series devices
connected to the local area network
Audio channel creation
Remote selection of the audio channel in each receiver
Remote adjustment of the configuration parameters
Scheduled and real-time messages
Firmware upgrading
- 11 -
EN
