- Page 1 I N ST RU CT I ON M A N UA L TT-AF 1200 Active Oscilloscope FET-Probe 1,2 GHz / 10:1...
-
Page 3: Safety Terms And Symbols
1. Safety Terms and Symbols These probe is in compliance with EN61010-031 CAT I, Pollution Degree 2 Terms appear in this manual: ___________________________________________________ WARNING. Warning statements identify conditions or practice that could result in injury or loss life. ___________________________________________________ CAUTION. Caution statements identify conditions or practice that could result in damage to this product or other property. - Page 4 2. General Safety Summary Review the following safety precautions to avoid injury and prevent damage to this probe or any products that connected to it. Observe Maximum Working Voltage To avoid any injury, do not use the probe under the condition that the voltage between either input head or earth is above ±...
-
Page 5: Installation
WARNING To protect against electric shock, use only the accessories supplied with this probe or the optional offered TESTEC accessories. Using the appropriate probe accessories, connect the inputs to the circuits under measurement. CAUTION. This probe is to carry out measurement between two points on the circuit under measurement. - Page 6 5. Appearance The active probe looks as follows. a. Input Pins the input pins of the active probe can be connected directly to the circuit under test or connected to the accessories that come with the probe. b. Output cable the BNC output connector connected to the oscilloscope c.
- Page 7 USB Power Cord, for oscilloscopes which offer USB connector. 9. Delivery Content 1 x active probe – TT-AF 1200 1 x 16pcs accessory kit – TT-AF SET1 1 x mains adapter – TT-SI NT 1 x hardcase – TT-AF HC 1 x trimming tool –...
- Page 8 10. Accessories Order- Type Description TT-SI NT 15100 Mains Adapter (included) TT-AF HC 12056 Hardcase (included) 16pcs accessory kit (included) TT-AF SET1 12055 TT-AF TOOL 12057 Trimming Tool (included) TT-AF SET2 21083 Micro IC Clips, double set Power Lead with TT-SI PROBUS 15150 PROBUS-Connector TT-SI LEMO...
- Page 9 11. Specifiations TT-AF 1200 Bandwidth DC to 1,2GHz (-3dB) Attenuation Ratio 10:1 Accuracy ±2% Rise Time 291ps 1MΩ // 3pF Input Impedance ±15V (DC+peak AC) Input Voltage ±40V (DC+peak AC) absolute maximum voltage Output Voltage ±1,5V (into 50Ω load) - Swing Output Voltage <±5mV...
-
Page 10: Derating Curve
13. Warranty TESTEC warrants its probes for normal use and operation within specification for a period of one (1) year from the date of shipment (accessories not included). In exercising its warranty, TESTEC, at its option, will either repair or replace any assembly returned within the warranty period.
