Figure 7: Sequence (1 to 9) to Mount the Detector on the Bracket
7a
7b
4
0.00
o
7c
6
7
7d
D200-101-01
1
99 mm
41
mm
2
90 mm
5 3
329 mm
8
9

Pipe Hole Configuration

Figure 8 below shows the pipe holes available on the unit. Each unit
has 2 pipe holes per channel connected together like a T-Piece. If
using a 1 channel unit, holes 3 and 4 do not function. Use Table 1 to
locate the holes required for the installation:
1
CHANNEL 1
CHANNEL 1 (NOT
USED FOR COMMON
5
CHAMBER UNIT)
Table 1: Pipe Holes Used for Each FAAST LT-200 Model
FAAST LT MODEL INLET PIPE HOLE
FL0111E‐HS
1 and / or 2
FL0112E‐HS 1 and / or 2
FL0122E‐HS Channel 1 ‐ 1 and / or 2
Channel 2 – 3 and / or 4
Note 1: Pipe holes not used should be kept sealed.
Note 2: Do NOT glue pipes into the pipe holes.
Table 1a: Maximum Number of Pipe Holes Allowed Per Channel
All figures quoted using highest (level 1) sensitivity
CLASS PIPE LENGTH MAX No
(m) HOLES /CH
C 100
C 160 (2 x 80) 18 (9 x 2)
Using T‐Piece
B
80
A 80
Pipe Installation
1
3
2 3 4
CHANNEL 2 (ONLY FUNCTION
ON 2 CHANNEL UNITS)
Figure 8: Pipe Holes
CHANNEL 2 (ONLY
FUNCTIONS ON 2
CHANNEL AND COMMON
6
CHAMBER UNITS)
OUTLET PIPE HOLE
5
6
5
6
HOLE SIZES
18 6 x 2mm + 6 x 2.5mm + 6 x 3mm
(+ 3.5mm non sensing end hole)
2 x [3 x 2.5mm + 6 x 3mm]
(+ 3mm non sensing end hole)
6 6 x 4mm
(inc 4mm sensing end hole)
3 1 x 5mm + 1 x 6mm
(+ 6.5mm sensing end hole)
2
