Onbon BX-YQ3 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

BX-YQ3/YQ4/YQ2E
User Manuel
2017-1-12
1
Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BX-YQ3 and is the answer not in the manual?

Questions and answers

Related Manuals for Onbon BX-YQ3

Summary of Contents for Onbon BX-YQ3

  • Page 1 BX-YQ3/YQ4/YQ2E User Manuel 2017-1-12 Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 2 Copyright All rights reserved. No part of this publication may be reproduced in any form by print, photo print, microfilm or any other means without written permission by ONBON. ©2010-2011Onbon Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 3 UM12070901 Version Date Author Description 2017-1-12 Chen Min BX-YQ3/YQ4/YQ2E user manual Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 4: Table Of Contents

    7. Use remote control to select programs..................26 7.1. Specification of remote control....................26 7.2. Main function of remote control....................29 8. Factory reset............................36 9. Test led display screen........................37 10. Trouble shooting..........................38 10.1. Indicator light......................... 38 Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 5 UM12070901 10.2. FAQ............................38 12. Contact us............................40 Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 6: Product Description

    BX-YQ3/YQ4/YQ2E user manual 1. Product Description BX-YQ3/YQ4/YQ2E Control cards can support video, graphic, text, etc; Support multi programs, multi areas; Support remote managing programs; Support Ethernet communication cluster management; Support uploading programs by flash/U disk, support playing programs by USB, SD card; Support -40℃～80℃ wide environment temperature.

  • Page 7: Screen Specification

    Work together with BX-V75 BX-YQ4 Maximum pixels in width =1920， receiving card Maximum pixels in height =1024 800×600 Work together with BX-V75 BX-YQ2E Maximum pixels in width=1920， receiving card Maximum pixels in height=1024 Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 8: Interface Definition

    UM12070901 2. Interface Definition BX-YQ3/YQ4/YQ2E interface definition 2.1. Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 9 Wide voltage input, support 4.5V ~ 5.5V SD card interface SD card interface ; prohibit plug-in SD card with power Remote control interface Infrared receiver interface Ok button Interactive menu confirmation button; also is the shortcut Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 10: Ethernet Interface Specification

    Ethernet port of router & switchboard). There are two lines of Ethernet line: Direct connection and Cross connection, the controller supports both of them. Making method: From right to left From left to right Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 11: Controller Specification

    UM12070901 From right to left From left to right 3. Controller specification BX-YQ2E/BX-YQ3/BX-YQ4 specification 3.1. Unit: Millimeter Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 12: Dc Characteristic

    UM12070901 DC characteristic Input voltage: 4.5V~7V, suggest you give power supply singly. Working electric current: ≤1360 mA Power: ≤4W Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 13: Steps For Use

    5. Steps for use BX-YQ3/YQ4/YQ2E install 5.1. Setup controller IP address 5.2. Open “LedshowYQ 2016”, click “ setup” -- “set screen parameters”, input “ 888 “ as to setup the screen parameters. Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 14 UM12070901 Click setting when finished setting IP details Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 15 IP of controller and PC should be on the same network, or it will be failed. And if it’s failed because of the IP setting, then reset IP address, it will get OK. Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 16: Set Screen Parameters

    UM12070901 Set Screen Parameters 5.3. Open “ LedshowYQ 2016”, click “ setup” -- “ set screen parameters”, input “ 888”. The following is the steps for setting parameters: Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 17 Step 1: Select the correct controller model, usually, if your connection is right, the PC software could identify the controller model automatically, under this circumstance, you do not need to select manually.please choice BX-YQ3 if you are using BX-YQ3 Step 2: Input the correct height and width pixels according to your screen.

  • Page 18: Scan Configuration

    Click “ Smart scan”, enter” Smart setup wizard-1”, check the picture below. You could set module width, driver chip, scan point outlet, with or without138, cascade direction, etc. You need to set it according to your modules. Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 19 Click “ next step”, enter into “ Smart setup wizard-2”, check the picture below: Select the correct display status, click “ next step “, enter into “ Smart setup wizard-3”, check the picture below: Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 20 Select the correct display status, click “ next step “, enter into “ Smart setup wizard- 4”, check the picture below: Select the correct display status, click “ next step “, enter into “ Smart setup wizard- 5”, check the picture below: Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 21 Select the correct display status, click “ next step “, enter into “ Smart setup wizard- 6”, check the picture below: Select the correct display status, click “ next step “, enter into “ Smart setup wizard- 7”, check the picture below: Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 22: Bx-Yq3/Yq4/Yq2E Receiving Card Setup

    BX-YQ3/YQ4/YQ2E receiving card setup 5.6. BX-YQ3/YQ4/YQ2E need to work together with full color receiving card such asBX- V75/BX_V/BX_V75L， please set the receiving card as the following steps Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 23 Step 2: Select the right location of receiving cards according to the order of receiving card, and single click; Step 3: Set the height and width pixels of your receiving card; Step 4: Click “ Send to receiver”. Finished all the configurations of receiving card. Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 24: Edit And Send Programs

    Open “ LedshowYQ 2016”, choose “ program 1” on the left side, --- click “ graphic “ button on the tool bar as to add a graphic area,--- click “video” button as to add an “video”area. Import the picture or video you want. Check the below: Click “send” as to send the present programs Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 25 UM12070901 For more details please refer to the contents under the help menu. Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 26: Use Remote Control To Select Programs

    UM12070901 7. Use remote control to select programs Specification of remote control 7.1. Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 27 UM12070901 ZTE Set-top box remote controller,the buttons marked in red can be used for ONBON controllers； Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 28 Return Lock/Unlock current program Information Controller information Volume+/- volume+/- Channel +/- Lock +/- program In setting interface, the Number Key Enter number digital key is used for digital Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 29: Main Function Of Remote Control

    2. Volume:volume +, -button can adjust volume ,the step length is 1;◄► button will adjust the volume rapidly , the step length is 5; the maximum volume is 100%, the minimum value is0%. , The mute button will mute the volume Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 30 10. The maximum brightness is 255, the minimum is 20. 4.Controller information:Click Information button will show the basic information of current controller, including controller type ,firmware version , FPGA version, RTC state, SD storage states Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 31 Press channel +/-button ,it could switch the current program quickly ,after stop the press for 3 seconds, it will lock the corresponding programs Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 32 4. Menu button: Press menu button to display the controller menu options, since different screen parameters may be different, please press "on demand" key to adjust the menu button, move the display order as following: Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 33 5.The first level of the menu interface is the language setting , it can support for Chinese and English (The follo samples are in Chinese): 6.The second level of the menu interface allows you to set the IP configuration, set the time and date, and the controller information. Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 34 7. Test mode: Press application button ,enter into test mode, check if the modules on the screen are working normally, use these buttons to ▲▼◄► switch the first and next test mode,it will also switch automatically every 10 seconds. Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 35 UM12070901 Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 36: Factory Reset

    UM12070901 8. Factory reset BX-YQ3 / BX_YQ4 / BX_YQ2E series controllers support reset to factory firmware. If the user finds that the current firmware is running abnormally, or after updated new version but found that some of the original features are lost.

  • Page 37: Test Led Display Screen

    You could enter into test display screen mode by pressing OK button. Then, there will be kinds of testing window on the screen. Under the testing mode, click “▲”、“▼”could switch the testing window; long press OK button exit this testing mode. You can also use remote control enter test mode; Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

  • Page 38: Trouble Shooting

    Communicate with software software,check the communication line, and failed check the communication interface on PC. Controller time error Open software, correction time again Cannot save the time after Change RTC button battery. correction time Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 39  BX-YQ series, used together with 5V power supply, do not mix the positive and negative side  When plug SD card ,please turn off power first  Please avoid crash the controller  Put the controller to dry and cold place Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...
  • Page 40 Address：Floor 7, Tower 88, 1199#, North Qinzhou Road,Xuhui District, Shanghai ,China Website：http://www.onbonbx.com Onbon （Jiangsu） photoelectric industrial Co., Ltd. Address：No 1299 Fuchunjiang road ,kunshan city , Jiangsu province , China Tel：00-86 15921814956 Email： onbon@onbonbx.com Shanghai ONBON Technology Co.,Ltd BX-YQ3/YQ4/YQ2E controller User Manuel...

This manual is also suitable for:

Bx-yq4Bx-yq2e
