Battery Charger Fault (LED Flash)

If a fault has occurred during battery charging, the (AMBER or
RED) LED on the charger LED indicator (See Figure 3-12.) will
flash corresponding to the fault which occurred. Refer to Table
3-1 following for the charger LED flash codes and their meaning.
FLASHING LED
AMBER
AMBER
AMBER
RED
3121272
SECTION 3 - MACHINE CONTROLS, INDICATORS AND OPERATION
Table 3-1. Battery Charger Fault (LED Flash)
FAULT
Upon battery voltage >2.5V per cell @ startup, charger shall flash amber LED and not
Battery High Voltage
allow charging - Battery or System problem.
Upon battery voltage <0.17V per cell @ startup, charger shall flash amber LED and
Battery Low Voltage
not allow charging - Battery or System problem.
Should battery fail to reach 1.75V per cell charge shall flash an amber LED until char-
Failed Trickle to min V
ger is power cycled - Battery or System problem.
Charger Internal Fault Signals a hardware fault of the charger and shall indicate flashing red LED.
– JLG Lift –
If required, further general and troubleshooting information
about the battery charger can be found in the charger manufac-
turers Owner's Guide.
