C
ONFIGURING THE
Menu
Broadcast Control
Port Mirroring
TRUNKS
Membership
Settings
Rate Limiting
VLANS
VLAN Settings
QOS
Settings
LOGOUT

Web Configuration

Displaying Status Overview

You can easily identify the system by displaying the device name, location
and contact information.
Field Attributes
System Information
• System Name – Name assigned to the switch system.
• Number of Ports – Number of built-in ports.
• Hardware Version – Hardware version of the main board.
• Code Version – Version number of the code.
• Serial Number – The serial number of the switch.
8
S
WITCH
Table 2-1 Switch Main Menu (Continued)
Description
Sets the broadcast storm control parameters
for every port on the Switch.
Sets up the port mirroring features of the
switch to enable traffic monitoring.
Specifies ports to group into static trunks
Configures trunk connection settings
Sets the rate limiting parameters for each
Trunk configured on the Switch.
Configures the VLANs on the switch for both
Ports and Trunks
Sets the priority of packets within the switch.
Quits to the Login page.
Page
21
22
23
24
24
25
26
26
29
29
