SMC Networks SMCGS805 User Manual

Ez switchtm 10/100/1000 8-port gigabit ethernet switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

USER GUIDE

TM
EZ Switch
10/100/1000

8-Port Gigabit Ethernet Switch
SMCGS805

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMCGS805 and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks SMCGS805

Summary of Contents for SMC Networks SMCGS805

  • Page 1: User Guide

    USER GUIDE EZ Switch 10/100/1000   8-Port Gigabit Ethernet Switch SMCGS805...
  • Page 2 EZ Switch 10/100/1000 User Guide From SMC’s EZ line of low-cost workgroup LAN solutions No. 1, Creation Road III, Hsinchu Science Park, 30077, Taiwan, R.O.C. March 2014 E032014-AP-R01 TEL: +886 3 5638888 Fax: +886 3 6686111...
  • Page 3 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.

  • Page 4: Warranty And Product Registration

    ARRANTY AND RODUCT EGISTRATION To register SMC products and to review the detailed warranty statement, please refer to the Support Section of the SMC Website at http://www.smc.com. – 4 –...

  • Page 5: Compliances And Safety Statements

    OMPLIANCES AND AFETY TATEMENTS EDERAL OMMUNICATION OMMISSION NTERFERENCE TATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 6 OMPLIANCES AND AFETY TATEMENTS This information technology equipment complies with the requirements of the Council Directive 2004/108/EC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 2006/95/EC for electrical equipment used within certain voltage limits and the Amendment Directive 2006/95/EC.
  • Page 7 OMPLIANCES AND AFETY TATEMENTS LVD: EN 60950-1:2006+A11:2009+A1:2010 + A12:2011 ◆ CE M ARNING This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022 class A for ITE, the essential protection requirement of Council Directive 2004/108/EC on the approximation of the laws of the Member States relating to electromagnetic compatibility.
  • Page 8 OMPLIANCES AND AFETY TATEMENTS ◆ 為避免發生電氣短路情形，請務必將所有沒用到的螺絲、迴紋針及其他零件收好，不要 遺留在主機板上或產品主機中。 ◆ 灰塵、溼氣以及劇烈的溫度變化都會影響主機板的使用壽命，因此請盡量避免放置在這 些地方。 ◆ 請勿將產品主機放置在容易搖晃的地方。 ◆ 若在本產品的使用上有任何的技術性問題，請和經過檢定或有經驗的技術人員聯絡。 使用注意事項 ◆ 在您開始操作本系統之前，請務必詳閱以下注意事項，以避免因為人為的疏失造成系統 損傷甚至人體本身的安全。 ◆ 使用前，請檢查產品各部份組件是否正常，以及電源線是否有任破損，或是連接不正確 的情形發生。 ◆ 如果有任何破損情形，請盡速與您的授權經銷商連絡，更換良好的線路。 ◆ 產品放置的位置請遠離灰塵過多，溫度過高，太陽直射的地方。 ◆ 保持機器在乾燥的環境下使用，雨水、溼氣、液體等含有礦物質將會腐蝕電子線路。 ◆ 使用時，請務必保持周遭散熱空間，以利散熱。 ◆ 使用前，請檢查各項周邊設備是否都已經連接妥當再開機。 ◆ 避免邊吃東西邊使用，以免污染機件造成故障。 ◆ 請避免讓紙張碎片、螺絲及線頭等小東西靠近產品之連接器、插槽、孔位等處，避免短 路及接觸不良等情況發生。 ◆ 請勿將任何物品塞入產品內，以避免引起機件短路或電路損毀。 ◆ 產品開機一段時間之後，散熱片及部份 IC 表面可能會發熱、發燙，請勿用手觸摸，並 請檢查系統是否散熱不良。...
  • Page 9 OMPLIANCES AND AFETY TATEMENTS ◆ 產品的機殼、鐵片大部份都經過防割傷處理，但是您仍必須注意避免被某些細部鐵片尖 端及邊緣割傷，拆裝機殼時最好能夠戴上手套。 當你有一陣子不使用產品時，休假或是颱風天，請關閉電源之後將電源線拔掉。 – 9 –...

  • Page 10: About This Guide

    BOUT UIDE URPOSE This guide details the hardware features of the switch, including the physical and performance-related characteristics, and how to install the switch. UDIENCE The guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks).

  • Page 11: Table Of Contents

    ONTENTS ARRANTY AND RODUCT EGISTRATION OMPLIANCES AND AFETY TATEMENTS BOUT UIDE ONTENTS NTRODUCTION Overview Package Contents Features IEEE 802.1p QoS Loopback Detection and Prevention Private VLAN Support ARDWARE ESCRIPTION Port and System Status LEDs Installation PC Connections Switch Connections ROUBLESHOOTING Diagnosing Switch Indicators The PWR LED is Off The Link/Act LED is Off when a Device is Connected to the Corre-...
  • Page 12 ONTENTS Physical Characteristics – 12 –...

  • Page 13: Introduction

    NTRODUCTION VERVIEW The EZ Switch 10/100/1000, SMCGS805, is a powerful, high-performance Gigabit Ethernet switch with eight RJ-45 ports. The switch supports auto- negotiation on all ports, which means they automatically negotiate with connected partners to determine the network speed (10/100/1000 Mbps) and duplex mode (full or half duplex).

  • Page 14: Features

    | Introduction HAPTER Package Contents SMC Warranty Card ◆ EATURES Complies with 10BASE-T specifications of the IEEE 802.3 standard ◆ Complies with 100BASE-TX specifications of the IEEE 802.3u standard ◆ Complies with 1000BASE-T specifications of the IEEE 802.3ab standard ◆ 8 10/100/1000 Mbps RJ-45 ports ◆...

  • Page 15: Ieee 802.1P Qos

    Package Contents IEEE 802.1 The SMCGS805 switch supports 802.1p priority queuing Quality of Service, which is an implementation of the IEEE 802.1p standard. With the 802.1p QoS function, you can reserve bandwidth for important functions that require a lot of bandwidth or have a high priority, such as VoIP (Voice-over Internet Protocol), web browsing applications, or video conferencing.

  • Page 16: Loopback Detection And Prevention

    | Introduction HAPTER Package Contents OOPBACK ETECTION AND REVENTION When a loop occurs at a port, the switch will Block the loop port, automatically protecting the switch. ■ Flash the port LED twice every second. ■ Turn the Loop LED on red. ■...

  • Page 17: Private Vlan Support

    | Introduction HAPTER Package Contents VLAN S RIVATE UPPORT The switch is designed for Internet access deployment where subscriber end nodes are connected to an Internet Service Provider network through the switch. In this application, each port is isolated in its own private VLAN to provide security for each end user, only the uplink port (Port 1) can communicate with all other ports.
  • Page 18 ARDWARE ESCRIPTION ORT AND YSTEM TATUS The switch contains one power LED, one loop LED for the device, and Link/Act LEDs for each port. Refer to the following table for LED definitions: Figure 4: Front Panels Table 1: System and Port Status LEDs Condition Status On Green...

  • Page 19: Hardware Description

    | Hardware Description HAPTER Installation Table 1: System and Port Status LEDs (Continued) Condition Status Link/Act On Amber Port has established a valid 1000 Mbps network (1000M) connection. Flashing indicates activity. Flashing Amber Flashing indicates activity. There is no valid link on the port. NSTALLATION When installing the switch, follow these guidelines: Place the switch in an appropriate ventilated environment.
  • Page 20 | Hardware Description HAPTER Installation For cable selection, refer to the following table. Table 2: Cable Types Network Speed Cable Type Max. Length 10 Mbps Cat. 3, 4, 5 UTP/STP 100 meters 100 Mbps Cat. 5 UTP/STP 100 meters 1000 Mbps Cat.

  • Page 21: A Troubleshooting

    ROUBLESHOOTING IAGNOSING WITCH NDICATORS PWR LED Make sure the AC power cord is connected to the switch and power source ◆ properly. Make sure the power source is ON. ◆ FF WHEN A EVICE IS ONNECTED TO THE ORRESPONDING Make sure that the cable connectors are firmly plugged into the switch and ◆...

  • Page 22: Installation

    | Troubleshooting PPENDIX Installation NSTALLATION Verify that all system components have been properly installed. If one or more components appear to be malfunctioning (such as the power cord or network cabling), test them in an alternate environment where you are sure that all the other components are functioning properly.

  • Page 23: Specifications

    PECIFICATIONS HYSICAL HARACTERISTICS TANDARDS IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3x full-duplex flow control IEEE 802.3az Energy-Efficient Ethernet IEEE 802.1p QoS NTERFACE 8 10/100/1000BASE-T RJ-45 ports ETWORK 10/100/1000 Mbps Auto-negotiating RANSMISSION 10/100 Mbps: Full-duplex, Half-duplex 1000 Mbps: Full-duplex WITCHING APACITY 16 Gbps...
  • Page 24 | Specifications PPENDIX Physical Characteristics OWER AVING Up to 75% power paving UFFER EMORY 128K bytes MAC A DDRESS ABLE UMBO RAME 9K bytes EMPERATURE Operating: 0 °C to 45 °C (32 °F to 112 °F) UMIDITY Operating: 10% to 90% (non-condensing) LED I NDICATIONS System: PWR/LOOP...
  • Page 25 | Specifications PPENDIX Physical Characteristics MISSIONS FCC, CE – 25 –...
  • Page 28 #10-04, Realty Centre Singapore 079716 Tel: +65-63387667 Fax: +65-63387767 www.smc-asis.com www.smcnetworks.co.kr Declaration of Conformity (DoC) can be obtained from www.smc.com -> support -> download SMCGS805 www.smc.com 150200062800A R02 20 Mason • Irvine, CA 92618 • Phn: 949-679-8000 • www.smc.com...
