HBM FS63 Installation Manual

Weldable temperature sensor
Hide thumbs Also See for FS63:
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Guide
English
FS63
Weldable Temperature Sensor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS63 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HBM FS63

Summary of Contents for HBM FS63

  • Page 1 Installation Guide English FS63 Weldable Temperature Sensor...
  • Page 2 Portugal Tel. +351 229 613 010 Fax +351 229 613 020 fibersensing@hbm.com www.hbm.com/fs Mat.: 7-2002.4262 DVS: A4262-3.2 HBM: public 05.2015 Sensor Desing Version: v1.0 E Hottinger Baldwin Messtechnik GmbH. Subject to modifications. All product descriptions are for general information only.

  • Page 3: Table Of Contents

    Temperature Computation ........FS63 A4262-3.2 HBM: public...

  • Page 4: Technical Details

    This installation guide applies to the following products: Part Number Description K-FS63-20-11-202 FS63 – Weldable Temperature Sensor • Indoor • FC/APC K-FS63-20-13-202 FS63 – Weldable Temperature Sensor • Indoor • SC/APC K-FS63-20-10-202 FS63 – Weldable Temperature Sensor • Indoor • NC K-FS63-20-11-302 FS63 –...

  • Page 5: Applications

    Based on the measurement of an absolute parameter - the Bragg wavelength - independent of power fluctua­ tions. 1.1.3 Applications HBM FiberSensing temperature sensors can be used in several temperature measuring applications. They are particularly suited for temperature mapping in large struc­ tures (SHM). : Industry...

  • Page 6: Quality

    HBM FiberSensing, S.A. concentrates all optical sensing activity of HBM and is an ISO 9001:2008 certified com­ pany. 1.1.5 Accessories The implementation of complex sensing networks in large structures is made simpler with HBM FiberSensing accessories.

  • Page 7: General Specifications

    2 m each side (±5 cm) Connectors FC/APC SC/APC NC (No Connectors) Environmental Operation temperature -20 to 80 ºC Mechanical Materials Stainless steel Dimensions 45 x 15 x 0.6 mm Weight Typical values For 1 pm resolution in wavelength measurement FS63 A4262-3.2 HBM: public...

  • Page 8: Sensor Installation

    List of Needed Equipment Spot welding Machine List of Needed Material Tape Drafting Tape Spot Welding Machine HBM FiberSensing uses a machine from Portable Welders Ltd. Our console is the B3 (http://www.­ portablewelders.com/technical-data-poke-consoles.html) and the Poke Welding Gun is the PG2 (http://www.­...
  • Page 9 Sensor Installation Fig. 2.1 Fig. 2.2 Typical settings are shown in Fig. 2.3 below. This is a starting point that should be adjusted to optimize the shot and the welding. FS63 A4262-3.2 HBM: public...
  • Page 10 Sensor Installation Fig. 2.3 Refer to section 2.4 on page 12 for welding process instructions. FS63 A4262-3.2 HBM: public...

  • Page 11: Preparing The Surface

    Sensor Installation Preparing the Surface Deburr the surface until reaching a weldable material while ensuring that there are no irregularities on the surface. Clean the surface with a tissue to remove any dust. Fig. 2.4 FS63 A4262-3.2 HBM: public...

  • Page 12: Welding The Sensor

    Fig. 2.5 Give the first set of shots with the welding machine (points 1 to 1') as shown in Fig. 2.6. Fig. 2.6 FS63 A4262-3.2 HBM: public...

  • Page 13: Protecting The Sensor

    For the weldable temperature sensor it is advisable to further protect the sensor. The following instructions are only suggestions of procedure. 2.5.1 Moisture Protection To protect the sensor from direct moisture contact, HBM FiberSensing uses a synthetic air tight rubber (Polyisobutylene rubber). FS63 A4262-3.2 HBM: public...
  • Page 14 Cut a piece of rubber tape with approximately 70x23 mm. Fig. 2.8 Remove the protection sheet from the tape and carefully place it over the sensor. Press the tape towards the sen­ sor and the surface. Fig. 2.9 FS63 A4262-3.2 HBM: public...

  • Page 15: Mechanical Protection

    Sensor Installation 2.5.2 Mechanical Protection HBM FiberSensing has a sensor cover that can be used with weldable temperature sensor. Weld the cover to the surface. Fig. 2.10 FS63 A4262-3.2 HBM: public...

  • Page 16: Sensor Configuration

    Sensor Configuration Sensor Configuration Sensor Calibration Sheet Every HBM FiberSensing sensor is provided with a cali­ bration sheet. The layout of this document is the same for all temperature sensors. Fig. 3.1 FS63 A4262-3.2 HBM: public...

  • Page 17: General Information

    + S x ) S Fig. 3.2 Where is the zero order sensitivity (reference tempera­ ture) in ºC is the first order sensitivity in ºC/nm is the second order sensitivity in ºC/nm FS63 A4262-3.2 HBM: public...
  • Page 18 S CWL is the central wavelength of the sensor at the zero moment in nm S WL is the measured wavelength in nm. Number in Fig. 3.1 represents collected data during the calibration procedure on the temperature sensors. FS63 A4262-3.2 HBM: public...
  • Page 19 Sensor Configuration FS63 A4262-3.2 HBM: public...
  • Page 20 HBM Test and Measurement Tel. +49 6151 803-0 Fax +49 6151 803-9100 info@hbm.com measure and predict with confidence...
