SMC Networks SMC6924MT Specifications page 2

Layer 2 Stackable 24-Port Fiber Managed Switch with
SMC6924MT
Ports
•24 100BASE-FX MT-RJ MMF ports
•2 slots for expansion modules
Network Interface
•10BASE-T: RJ-45 UTP Cat. 3,4,5
•100BASE-TX: RJ-45 UTP Cat. 5
•1000BASE-T: RJ-45 UTP Cat. 5
•100BASE-FX: MT-45/SC/ST connector
•1000BASE-SX: SC connector
•1000BASE-LX: SC connector
Buffer Architecture
•32Kbps per 100Mbps
•2Mbps per 1000Mbps port
Aggregated Bandwidth
•8.8 Gbps, non-blocking
Switching Database
•8K MAC address entries
LEDs
•System: (power, RPU, Mgmt.)
•Port: (mode flow control, full duplex,
activity)
•Link: (speed, link, disable/partition)
Weight
•10.63 lbs (4.82 Kg.)
Size
•17.37" x 1.22" x 2.53"
Temperature
•Operating: 32 – 122 o F
•Storage: -40 – 158 o F
Humidity
•Operating 5% to 95% (non-condensing)
AC Input
•100 to 240V , 47-63 Hz
Power Supply
•Internal, auto-ranging transformer:
100 to 240VAC, 47-63 Hz
•Redundant DC input
Power Consumption
•<70W
Maximum Current
•SMC6924MT: 0.80A @ 110VAC, 0.50A
@ 240VAC
Product Description
SMC6924MT Stackable 24-Port Managed MT-RJ MMF switch with optional Gigabit Uplinks
(at least one SMC6924MTNMM is required for each standalone or stack)
SMC6924MTNMM TigerStack 100 Switch Management Module
SMC6900S TigerSwitch 10/100 Stacking Module with stacking cable
SMC6900G TigerSwitch 10/100 1-port 1000BASE-SX Expansion Module
SMC6900GLSC TigerSwitch 10/100 1-port 1000BASE-LX Expansion Module
SMC6900GT TigerSwitch 10/100 1-port 10/100/1000BASE-T Expansion Module
SMC6900FSC TigerSwitch 10/100 2-Port 100Base-FX MMF SC Fiber Module
SMC6900FSSC TigerSwitch 10/100 1-Port 100Base-FX SMF SC fiber Module
SMC6900FST TigerSwitch 10/100 100Base-FX MMF SC Fiber Module with SC-ST converters
SMCRPU150W Redundant Power Supply
TigerStack
Optional Gigabit Uplinks
MTBF
•6 years (estimated)
Switch Features
•Spanning Tree Protocol
Forwarding Mode
•Store-and-forward
Flow Control
•Full-duplex: IEEE 802.3x
•Half-duplex: back pressure
VLAN Support
•Up to 256 groups, port-based or with
802.1Q VLAN tagging, GVRP for auto-
matic VLAN learning
Quality of Service
•Supports two levels of priority and
weighted Fair Queuing
•Broadcast Storm Control
•MultiLink Trunking
•Port Mirroring
Management Features
In-Band Management
• Telnet, SLIP, Web-based HTTP or SNMP
Manager
Out-of-Band Management
• RS-232 DB-9 console port
Software Loading
• TFTP in-band or Xmodem out-of-band
MIB Support
•MIB II (RFC 1213), Bridge MIB (RFC 1493)
•Ethernet-like MIB (RFC 1643), RMON
MIB (RFC 1757), SMC proprietary MIB
RMON Support
•Groups 1, 2, 3, 9 (Statistics, History,
Alarm, Event)
Standards
•IEEE 802.3 Ethernet
•IEEE 803.3u Fast Ethernet
•IEEE 803.3z Gigabit Ethernet
•IEEE 802.1D Spanning Tree Protocol
and traffic priorities
•IEEE 802.1P Priority Tags
•IEEE 802.1Q VLAN
•IEEE 802.3ac VLAN Tagging
•IEEE 802.3x Full-duplex flow control;
100
TM
Switches/Hubs
ISO IEC 8802-3
•SNMP (RFC 1157), RMON (RFC 1757), ARP
(RFC 826), IGMP (RFC 1112), MIB II (RFC
1213), Ethernet-like MIB (RFC 1643),
Bridge MIB (RFC 1493)
Compliances
•CE Mark
•Emissions
• FCC Class A
• Industry Canada Class A
• EN55022 (CISPR 22) Class A
• VCCI Class A
• C-Tick – AS/NZS 3548 (1995) Class A
•Immunity
• IEC 1000 – 4 – 2/3//4/6
•Safety
• CSA/NRTL (CSA22.2.950 & UL 1950),
EN60950 (TUV/GS)
Warranty
•Limited lifetime
Slide-In Modules
•100Base-FX Extender Module
Models
•SMC6900FSC, SMC6900FST
•SMC6900FSSC
Ports
•2 – 100Base-FX MMF or
•1 – 100Base-FX SMF
Model
•SMC6900G
•SMC6900GLSC
Ports
•(1) 1000Base-SX
•(1) 1000Base-LX
Model
•SMC6900GT
Ports
•(1) 10/100/1000Base-T
Model
•SMCRPU150W
Function
•Redundant DC-Power Unit with cables;
supports one device
