Cable Specifications

Cable
10BASE-T
100BASE-TX

Twisted-Pair Cable and Pin Assignments

Caution: DO-NOT plug a phone jack connector into any RJ-45
For 10BASE-T/100BASE-TX connections, a twisted-pair cable must
have two pairs of wires. Each wire pair is identified by two
different colors. For example, one wire might be red and the other,
red with white stripes. Also, an RJ-45 connector must be attached
to both ends of the cable.
Caution: Each wire pair must be attached to the RJ-45 connectors
Cable Types and Specifications
Type
Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft)
Cat. 5 100-ohm UTP
port. Use only twisted-pair cables with RJ-45 connectors
that conform with FCC standards.
in a specific orientation.
C
Max. Length
100 m (328 ft)
C
ABLES
ABLES
Connector
RJ-45
RJ-45
9
