  • Page 2: Table Of Contents

    Checking Tire Pressures..........29 Table of Contents: Lubrication..............29 Products Covered by This Manual........3 Lubricate the Front Casters..........31 Identification Tag Location...........3 Servicing the Mower Blades...........31 Product Identification Tag (Stamped).........3 Cutting Height Adjustment..........33 Operator Safety..............4 Neutral Adjustment............34 Operating Safely...............4 Neutral Lockout and Tracking Adjustment......34 Slope Identification Guide..........6 Deck Lift Rods..............36 Safety Rules and Information...........6...

  • Page 3: Products Covered By This Manual

    Stand-On Mower. We’re pleased that you’ve placed your confidence in the Ferris brand. When operated and maintained according to the manuals, your Ferris product will provide many years of dependable service. The manuals contain safety information to make you aware of the hazards and risks associated with the unit and how to avoid them.

  • Page 4: Operator Safety

    Note: For the location of the engine identification numbers, refer Read the Manual to engine owner's manual. The Illustrated Parts List for this machine can be downloaded from ferrismowers.com. Please provide model and serial number when ordering replacement parts. Operator Safety The operator’s manual contains important safety information WARNING you need to be aware of BEFORE you operate your unit as well...
  • Page 5 not have adequate wheel traction (and control) can cause running! Keep safety devices (guards, shields, and switches) sliding, loss of steering, control, and possible rollover. in place and working. You should not operate on a slope greater than a 6.1 foot rise To help you, the operator, use this equipment safely, it is over a 20 foot length (17 degrees).

  • Page 6: Slope Identification Guide

    Enclosed Areas (also called inclinometer, protractor, angle meter, or angle gauge). Dial type (C) or digital type (D) work, others may not. Follow user instructions with the angle finder tool. 3. Place the two (2) feet long straight edge along the steepest part of the lawn slope.
  • Page 7 • Never refuel or drain the machine indoors. • Do not operate the unit while under the influence of alcohol or drugs. • Check that operator’s presence controls, safety switches and shields are attached and functioning properly. Do not • Slow down and use caution when making turns and crossing operate unless they are functioning properly.
  • Page 8 Children Tragic accidents can occur if the operator is not alert to the DANGER presence of children. Children are often attracted to the unit Wet or soft slope hazard and the mowing activity. Never assume that children will remain Wet or soft slopes can cause sliding and loss of control where you last saw them.

  • Page 9: Safety Decals

    • Use extra care in handling gasoline and other fuels. They replace with manufacturer’s recommended parts, when are flammable and vapors are explosive. necessary. • If fuel is spilled, do not attempt to start the engine but move • Check brake operation frequently. Adjust and service as the machine away from the area of spillage and avoid required.
  • Page 10 D.) Part No.: 5105095 - Decal, Dash Panel, RH, Warning/Controls * Located near the transmission fans. A.) Part No.: 7101665 - Decal, Danger B.) Part No.: 5103665 - Decal, Warning, Fire E.) Part No.: 5104636 - Decal, Danger, Stand-On F.) Part No.: 5061245 - Decal, Pinch Point C.) Part No.: 5105081 - Decal, Dash Panel, LH, Controls G.) Part No.: 5103184 - Decal, Warning, Hand in Pulley ferrismowers.com...

  • Page 11: Safety Icons

    CAUTION indicates a hazard which, if not avoided, could result in minor or moderate injury. NOTICE indicates a situation that could result in damage to the product. Safety Interlock System This unit is equipped with safety interlock switches. These safety systems are present for your safety, do not attempt to bypass safety switches, and never tamper with safety devices.
  • Page 12 To learn what combination and sequence of controls to use for various tasks see the Operation section. Cutting Height Adjustment Pin Deck Lift Lock Lever Maximum Forward Speed Bar: This unit is equipped with an adjustable Maximum Forward Speed Bar (A, Figure 6), which is located in front of the Ground Speed Control Levers (B &...
  • Page 13 See Check / Fill Transmission Oil for oil level check and fill To adjust the position of the Maximum Forward Speed Bar pull the T-handle knob (D) out to release the maximum forward procedures. speed bar, position the Maximum Forward Speed Bar in the desired location, and then release the T-handle knob.
  • Page 14 "C" - Time Display - This is the number of hours that are recorded. The default display of the hour meter is engine hours. The mode icon will display a "E" and the hour glass icon will not flash. To begin recording engine hours, start the unit's engine and release the parking brake.

  • Page 15: Operation

    Choke: Close the choke for cold starting. Open the choke WARNING once the engine starts. A warm engine may not require choking. Do NOT load this zero-turning mower on a trailer or truck Pull the knob UP to close the choke. Push the knob DOWN to using two separate ramps.

  • Page 16: Starting The Engine - Briggs & Stratton Fuel Injected Models

    a minute before engaging the PTO switch or driving the Starting the Engine - Kawasaki Fuel rider. Injected Models 5. After warming the engine always operate the unit at FULL throttle when mowing. WARNING In the event of an emergency the engine can be stopped Read the operator's manual before attempting to operate by simply turning the ignition switch to STOP.
  • Page 17 steers, before you begin mowing, is absolutely essential to Make sure that the T-handle knob locks the maximum getting the most out of the zero-turn riding mower. forward speed bar into place. Locate a smooth, flat area of your lawn, one with plenty of room to maneuver.
  • Page 18 Gradually move both ground speed control levers evenly While traveling forward allow one handle to gradually return FORWARD from neutral. Slow down and repeat. back toward neutral. Repeat several times. Note: Straight forward travel takes practice. If the unit veers to Note: To prevent pivoting directly on the tire tread, it is best to either direction while both ground speed controls levers are keep both wheels going at least slightly forward.

  • Page 19: Operating On Slopes

    • It is recommended to mow up and down slopes only when you cannot mow across slopes. • Mow up the slope and lean your body forward (towards the control panel), while keeping a firm grip on the control levers. This body position helps keep the front wheels on the ground.
  • Page 20 Letting grass grow a bit longer—especially when it is hot and When and How Often to Mow dry—reduces heat build-up, preserves needed moisture and The time of day and condition of the grass greatly affect the protects the grass from heat damage and other problems. results you’ll get when mowing.

  • Page 21: Pushing The Unit By Hand

    growth, and often wetter conditions are more suitable for broadcasting (side-discharging) or grass bagging operation. Engine Speed & Ground Speed for Mulching: Use full engine throttle matched with a slow ground speed so that clippings will be finely cut. Ground speed while mulching should be HALF of the speed that would be used when broadcasting (side discharging) under similar conditions.

  • Page 22: Storage

    WARNING Never store the unit, with gasoline in engine or fuel tank, in a heated shelter or in enclosed, poorly ventilated enclosures. Gasoline fumes may reach an open flame, spark or pilot light (such as a furnace, water heater, clothes dryer, etc.) and cause an explosion.

  • Page 23: Maintenance Schedule

    and have not drained the fuel system, follow all safety UNIT MAINTENANCE instructions and storage precautions in this manual to Clean battery and cables. prevent the possibility of fire from the ignition of gasoline Initial change of hydraulic oil. fumes. Remember, gasoline fumes can travel to distant Every 400 Hours or Yearly sources of ignition and ignite, causing risk of explosion and fire.

  • Page 24: Replacing The Fuel Filter

    Replacing the Fuel Filter WARNING Fuel and its vapors are extremely flammable and explosive. Fire or explosion can cause severe burns or death. Do NOT remove the fuel filter when the engine is hot, as spilled gasoline may ignite. Do NOT spread hose clamps further than necessary.

  • Page 25: Changing The Engine Oil And Filter (Engines With Remote Oil Tank)

    Changing the Engine Oil and Filter (Engines with Remote Oil Tank) Engine Oil Type: 15W-50 synthetic oil. (See the engine operator's manual for other oil recommendations.) Engine Oil Change Amount: 5 qt (4,73 L). Oil Change Interval: Every 500 hours. Important: Always make sure that the mower is parked on a flat, level surface when checking the engine oil level.

  • Page 26: Changing The Engine Oil And Filter (All Other Models)

    7. Remove the oil drain hose from it's storage location. 8. Remove the cap from the drain spout of the oil drain valve. 9. To operate the oil drain valve, turn counter-clockwise to open and drain the engine oil into a suitable container. 10.

  • Page 27: Engine Maintenance

    Engine Maintenance For engine maintenance schedules and procedures, please refer to the engine operator's manual. Electronic Fuel Injection (EFI) System - EFI Models EFI is an electronically-controlled fuel management system which is monitored by an Electronic Control Unit (ECU). A Malfunction Indicator Lamp (M.I.L.) will illuminate if problems or faults are detected.

  • Page 28: Fuse Location And Identification

    1. Locate the transmission oil tanks. The transmission oil tanks are located on the right side of the engine between the engine and the battery box. 2. Check the oil level when the unit is cold. The oil should be up to the “FULL COLD”...

  • Page 29: Purging The Air From The Hydraulic System

    • High operation temperature and excessive expansion of oil. Before starting, make sure the transaxles/transmissions are at the proper oil levels. If it is not, fill to the specifications outlined in the Check / Fill Transmission Oil Level procedure. Purging Air from the Hydraulic System: 1.
  • Page 30 Grease deck lift lever pivot block parking brake lever shaft lower parking brake shaft mower deck hanger linkages mower deck spindles Use grease fittings when present. Disassemble parts to apply grease to moving parts when grease fittings are not installed. Not all greases are compatible.

  • Page 31: Lubricate The Front Casters

    1. Use a block of wood to prevent the mower blade from turning as shown in Figure 37. Lubricate the Front Casters Interval: Annually 1. Remove the 1/4-28 bolt (A, Figure 36) screwed into the caster and install a 1/4-28 grease fitting. 2.
  • Page 32 4. The mower blade should have a maximum of 1/64" (0,40 mm) cutting edge (B) or less. Balancing the Mower Blades CAUTION Thrown objects hazard An unbalanced mower blade can create excessive vibration and damage the unit, or cause mower blade failure resulting in thrown debris.

  • Page 33: Cutting Height Adjustment

    2. Wedge a wooden block (D) between the mower blade and the mower deck housing to keep the mower blade from To set the cutting height at 1-3/4” (4,5 cm): turning and torque the blade mounting bolt to 120 ft. lbs (163 Nm).

  • Page 34: Neutral Adjustment

    To set the cutting height in the range of 2” (5,08 cm) and lockouts will engage the ground speed control levers as the 4-3/4” (12,1 cm): parking brake is being engaged. 1. Pull the deck lift lever back towards the operator position until it locks into the 5"...
  • Page 35 Left Hand Side Lockout Bolt Adjustment Ground Speed Control Lever Alignment Adjustment 1. Observe the left hand side lockout bolt (A, Figure 47). It should be positioned so that it is in the center of the notch 1. Observe the alignment of the right side ground speed control of the lockout plate (B) on the ground speed control lever.

  • Page 36: Deck Lift Rods

    Tracking Adjustment 4. Verify that the mower blades are flat, and not bent or broken. A bent or broken blade must be replaced. 1. Park the machine on a flat, level surface such as a concrete floor. Disengage the PTO, engage the parking brake, turn the ignition switch to OFF, and remove the key.

  • Page 37: Deck Lift Assist Springs

    3. Turn the hex adjusters on the deck linkages (C) clockwise to raise the mower deck or counter-clockwise to lower the mower deck. 4. Re-check the measurements at all four positions and adjust as necessary until the deck measures correctly. 5.

  • Page 38: Transaxle Drive Belt Replacement

    2. Use the Deck Belt Tensioning Spring Length chart to 1. Park the unit on a flat, level surface such as a concrete determine the correct spring length for your unit. floor. Disengage the PTO, engage the parking brake, turn 3.

  • Page 39: Parking Brake Adjustment

    accommodate heavier-weight operators, and provide a stiffer more rigid ride. 3. Measure the distance (B) from the top of the threaded To Adjust the Lower Mounting Position: parking brake shaft (C) to the top of the adjustment nut (D). The measurement should equal 1/4” – 5/16” (.64 cm - .79 1.

  • Page 40: Battery Service

    2. Disconnect the cables from the battery, negative [-] cable first (A, Figure 59). 1. Be aware of all the safety precautions you should observe during the charging operation. If you are unfamiliar with the use of a battery charger and hydrometer, have the battery serviced by your dealer.

  • Page 41: Troubleshooting

    remove the other end of the same cable from the booster battery. 11. Remove the other cable by disconnecting at the discharged battery first and then disconnect the opposite end from the booster battery. 12. Discard the damp cloths that were placed over the battery vent caps.
  • Page 42 Problem: Engine will not turnover or start. Problem: Engine runs but mower will not drive. Parking brake not engaged. Engage parking brake. Transmission release lever(s) in Move transmission release lever(s) to "disengaged" position. the "engaged" position. Out of fuel. If engine is hot, allow it to cool, then refill the fuel tank.

  • Page 43: Troubleshooting Common Cutting Problems

    Problem: Excessive belt wear or breakage. Problem: Stepped Cutting Cause Remedy Stepped cutting is sharp ridges or uneven levels left in the lawn surface. Stepped cutting is usually caused by mower deck damage or misadjustment, Bent or rough pulleys. Repair or replace. or damage to the mower blades.

  • Page 44: Specifications

    Specifications ZY-GKEF-3L7B-1V$B (5104581) Type ZT-3400 Transaxles Hydraulic SAE 20W-50 motor oil Specifications are correct at time of printing and are subject to Fluid change without notice. Speeds Forward 0-10 MPH (0-16.09 km/h) ENGINE Reverse 0-5 MPH (0-8.05 km/h) For complete engine specifications see the engine manufacturer's operator's manual included with your unit.
  • Page 45 ABOUT YOUR WARRANTY WARRANTY PERIOD Warranty service is available only through Ferris Authorized Covered Parts Standard Warranty Rental Warranty Period Service Dealers. This warranty only covers defects in materials Period or workmanship.
