Summary of Contents for Ferris Simplicity FAST-Vac

  • Page 1 • Pages labeled with the text “THIS PAGE INTENTIONALLY BLANK” are placement pages ONLY, and should NOT be printed. If you have any further questions regarding this manual, please contact Ken Cehonski in Ferris Industries Engineering Department at (315) 495-0100 ext. 249.
  • Page 2 THIS PAGE INTENTIONALLY BLANK...
  • Page 3 61” Bag Collection Systems Part Number: Description: Fits: Part Number: Description: Fits: 46764 48” 2-Bag System Ferris 48” 1000Z 46766 61” 3-Bag System Ferris IS3000Z Series Derby Colt ZT2148 (23hp - S/N 101-425) (25hp - S/N 101-1525) 47605 48” 2-Bag System Ferris 48” IS1000Z...
  • Page 4 Ferris’ election, without charge and at the place of business of a dealer authorized to handle Ferris mowers, any part or parts of the machine which, in the judgment of Ferris, prove to be defective.
  • Page 5 Hardware Identification & Torque Specifications Common Hardware Types Torque Specification Chart Hex Head Capscrew FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%) Washer Hardware Lockwasher Marks Grade Carriage Bolt SAE Grade 2 SAE Grade 5 SAE Grade 8 Hex Nut in/lbs Size Of in/lbs in/lbs...
  • Page 6 If the grass collection system will only be used 25% or less of the total operating time, Ferris Industries does not recommend replacing the suspension springs due to the change in the stiffness of the ride.
  • Page 7: Table Of Contents

    Assemble Hood & Mount Frame ......11 Install Hose..............12 Torque Specification Chart....Inside Back Cover NOTE: In these instructions, “left” and “right” are referred to as seen from the operating position. © Copyright 2003 Ferris Industries, Inc. All Rights Reserved. Printed in USA. TP 100-7047-04-AT-FD...
  • Page 8: Safety Rules & Information

    Safety Rules & Information Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of unit, severe personal injury or death to you, or bystanders, or damage to property or equipment. The tri- angle in text signifies important cautions or warnings which must be followed.
  • Page 9: General Operating Instructions

    General Operating Instructions BEFORE OPERATION Clear the lawn of all sticks, stones, wire and other debris which may be caught or thrown by the mower blades. Check grass condition. If wet, wait until later in the day. If grass is wet, the grass catcher is likely to become plugged.
  • Page 10: Remove Discharge Chute

    1. Raise the floor pan and loosen the spring compres- sion nut (A, Figure 2) to release the belt tension. NOTE: The floor pan on the Ferris IS1000Z Series is not hinged and must be removed completely to gain access to the belt tension spring.
  • Page 11: Select Proper Spindle Pulley

    48” & 52” Blower Mount & Drive Installation Select Proper Spindle Pulley NOTE: There are two spindle pulleys supplied with the system. To determine which pulley is required, compare the height of the old spindle pulley with the new spindle pul- leys supplied.
  • Page 12: Install Blower & Belt Guard

    48” & 52” Blower Mount & Drive Installation 2. While holding the blower against the deck and chute mount tabs, place the spacers on the mower deck in the recesses of the mount plate. Make sure they are at the bottom of the recess (see Figure 8). Mark their location with a paint pen or prick punch.
  • Page 13: Remove Discharge Chute

    61” Blower Mount & Drive Installation Remove Discharge Chute 1. Park machine on a flat, level surface and apply the parking brake. 2. Remove the discharge chute and save. Save springs and spacer (Derby Stallion only). Figure 11. Chute Removal Release Mower Drive Belt Tension 1.
  • Page 14: Install Spindle Pulley

    61” Blower Mount & Drive Installation Install Spindle Pulley 1. Apply an anti-seize compound to the spindle shaft. Install the new, double spindle pulley (C, Figure 14) on the shaft with the smaller pulley facing up with the 5/8” nylon lock nut (A), 5/8” washer (B) and 1/4” key (D) and tighten to 85-95 ft./lbs.
  • Page 15: Install Blower & Belt Guard

    61” Blower Mount & Drive Installation Install Blower & Belt Guard 1. Loosen the 3/8-16 x 1” bolts (A, Figure 16) on the blower brace. 1. Install the blower assembly onto the mount bar (B). Push on the blower from the outside to obtain a tight fit between the blower housing and mower deck.
  • Page 16: Install Mount Plate

    I. 3/8-16 x 2” Bolt 3/8-16 Flange Nut Install Mount Plate Install Mount Plate (Ferris 1000Z & IS1000Z Series and Derby Colt “T” (Derby Colts) Series) 1. Install the mount plate (C, Figure 18) on the bumper 1. Remove the lower right-hand bolt, washer & nut...
  • Page 17: Assemble Hood & Mount Frame

    2-Bag Hood & Mount Installation Assemble Hood & Mount Frame 1. Install the hood & mount assembly (A, Figure 19) to the mount frame (C) and secure with 3/8-16 x 3/4” bolts (D) and 3/8-16 flange nuts (B). 2. Install the cover latch (G) and reinforcement plate (E) on the mount frame and secure with 5/16-18 x 3/4”...
  • Page 18: Install Hose

    2-Bag Hood & Mount Installation Upper Hose Clamp Hose, 48” or 51” Long C. Lower Hose Clamp D. Hose Adapter Figure 20. Install Hose Install Hose 2. Insert the hose (B, Figure 20) over the hose adapter 1. Before installing, the hose will need to be cut to (D) on the bagger unit and overlap by at least two length.
  • Page 19: Install Mount Plate

    F. 3/8-16 Flange Nuts Install Mount Plate Install Mount Plate (Ferris IS3000Z Series & Derby Stallion ZT2561) (Derby Stallion ZT2561F) 1. Install the mount plate (B, Figure 21) on the bumper 1. Install the mount plate (B, Figure 21) on the bumper using three bar clamps (C), six 3/8-16 x 2-1/2”...
  • Page 20 I. 3/8-16 Nylon Lock Nut Mount Support (1/4” Thick) J. 3/8-16 x 2” Bolt Install Mount Plate Install Mount Plate (Ferris 1000Z & IS1000Z Series and Derby Colt “T” (Derby Colts) Series) 1. Install the mount plate (C, Figure 22) on the bumper 1.
  • Page 21: Assemble Back Plate & Mount Frame

    3-Bag Hood & Mount Installation Assemble Back Plate & Mount Frame 1. Attach the back plate (A, Figure 23) to the mount frame (B) using carriage bolts, flat washers, and nuts. Use two 5/16-18 x 3/4” carriage bolts (D) in the top two holes, and two 5/16-18 x 1-1/4”...
  • Page 22: Install Deflector & Hose

    3-Bag Hood & Mount Installation Deflector Nylon Lock Nut, 5/16-18 C. Washer, 5/16” D. Hose Adapter Bolt, 5/16-18 x 1 Upper Hose Clamp G. Hose, 55” Long H. Lower Hose Clamp Figure 24. Install Deflector & Hose Install Deflector & Hose 1.
  • Page 23: Install Cover

    Hinge Pin Hair Pin Clip Install Exhaust Deflector (Ferris IS3000Z Series only, if not already equipped.) IMPORTANT NOTE: Failure to install the deflector could result in damage to the grass bag or fire. 1. Install the exhaust deflector on the tail pipe so the exhaust is directed away from the collector.
  • Page 24: E-Z Dump Box & Mount Group Part No. 23080 & 48268 Assemble Box

    E-Z Dump Box & Mount Installation Install Box Pivots 1. Using a 25/64” drill, use the lower set of holes as a guide and drill through the aluminum box. 2. Install the pivot brackets (B, Figure 29) on the base pivot mount (A) in the position shown and secure with the carriage bolts and flange nuts.
  • Page 25 E-Z Dump Box & Mount Installation Install the Latch Rod 1. Assemble the ball joint (B, Figure 31) onto the end of the latch rod (A). 2. Assemble the ball joint (B) to the latch plate (C) and secure with the nut. 3.
  • Page 26: Rotate Air Filter

    E-Z Dump Box & Mount Installation Install Inlet 1. Remove the four phillips head screws and inlet clamps located around the inlet opening on the right hand side of the box (see Figure 33). 2. Install the inlet from the inside of the box (see Figure 34).
  • Page 27: Assemble Mount Frame

    E-Z Dump Box & Mount Installation Install the Mount Frame 1. Install the frame uprights (B & C, Figure 36) onto the main frame of the machine. Make sure the pivot tube is located as shown in Figure 36. (The pivot tube will be offset towards the engine.) 2.
  • Page 28: Assemble Box To Mount

    E-Z Dump Box & Mount Installation Install the Dump Box 1. Install the dump box onto the uprights. Install the 5/8” x 3” pins through the pivots, then install the 5/8” washers secure with the hairpins. 2. Tighten all 3/8” bolts on the mount frame uprights and front and rear cross members.
  • Page 29: Install Weight Carrier

    Weight Mount Installation (Ferris 1000Z Series & Derby Colts / 2-Bag Systems) Install Weight Carrier 1. Remove the hairpin clip and clevis pin and remove the deck lift foot pedal. Lift the floor plate. 2. Install the weight carrier (B, Figure 39), mount plates (F &...
  • Page 30: Install Weight Carrier

    Weight Mount Installation (Ferris 1000Z Series & Derby Colts / 3-Bag Systems) Install Weight Carrier 1. Remove the hairpin clip and clevis pin and remove the deck lift foot pedal. Lift the floor plate. 2. Install the weight carrier (E, Figure 40), mount plates (B &...
  • Page 31: Install Weight Carrier

    Weight Mount Installation (Ferris IS1000Z Series / 2-Bag & 3-Bag Systems) Figure 41. Install Weight Carriers Weight E. Weight Carrier-LH 5/16-18 x 2-1/2 Bolts F. Bar Clamp C. Hairpin Clip G. 5/16-18 Nylon Lock Nuts D. Clevis Pin H. Weight Carrier-RH Install Weight Carriers 1.
  • Page 32 Weight Mount Installation (Ferris IS3000Z Series & Derby Stallion ZT2561 / 3-Bag System) Install Weight Mount Rack 3/4” 1. Measure and mark the front main frame tubes to the (1,90cm) dimensions shown in Figure 42. 2. Using a 3/8” drill bit, drill one (1) hole in each of the main frame tubes from the outside surface of the tube.
  • Page 33 Weight Mount Installation (Ferris IS3000ZF & IS3000ZX Series & Derby Stallion ZT2561F / 3-Bag System & E-Z Dump System) Install Weight Mount Rack 5” 1. Measure and mark the front main frame tubes to the (12,7cm) dimensions shown in Figure 45.
  • Page 34: Reattaching Discharge Chute

    Discharge Chute Reattachment MOWING WITHOUT THE BLOWER For operation without the blower, the deflector must be properly installed in the down position and retained by the spring latch (Derby models only). To remove the blower, reverse the installation steps. Reattaching the Discharge Chute See Figure 48.
