Elements of a Trap Message
Element
enterprise
agent-addr
generic-trap
specific-trap
time-stamp
variable-bindings

The [generic] Section

The first section of the TRAP.INI file is the [generic] section. It defines the number of generic traps available and
identifies the events each trap triggers. Entries for this section use the following format:
n=Active_Flag,Event_Name,Message
The following table describes each item:
Parameter
n=
Active_Flag
Event_Name
Message
Example: Sample entry for [generic] section
[generic]
0=1,Trap,Cold Start!!
1=1,Trap,Warm Start
2=1,Trap,Link Down
3=1,Trap,Link Up
B-12
IEW

Table B-11 Elements of a Trap Message

In a generic trap, this is the object identifier of the device that generates the trap (sysObjectID). In a
specific trap, this field contains an identifier used to differentiate the definition domain of the trap.
The network address of the device that issues the trap. If IP protocol is used, the agent-addr is the IP
address of the device.
An integer value that identifies the type of trap. Allowable values:
0 to 5 Identifies common conditions that occur in IP network operations; i.e., indicates that the trap
is a device generic trap.
6 Indicates that the trap is a device-specific trap.
An integer that identifies different device conditions; defined by the device vendor.
The sysUpTime variable. This is the time period from the initialization of the device to the moment
the trap is issued. This time period is expressed in hundredths of a second.
A list of MIB variables with values related to a particular event.

Table B-12 Parameters of the [generic] Section

Number of generic traps. Value ranges from 0 to 5
Select either 0 or 1, where 1=active; 0=disabled (not processed)
The name of the event you wish to trigger
The message displayed on the message box
Description
Description
