Summary of Contents for SMC Networks WIPCAM-PZ
- Page 1 EZ Connect N EZ Connect Vision™ Draft 11n Wireless USB2.0 Adapter IP Camera Manager software IP Camera Manager...
- Page 2 The information provided by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.
-
Page 3: Product Registration
Warranty and Product Registration To register SMC products and to review the detailed warranty statement, please refer to the Support Section of the SMC Website at http://www.smc.com SMC Networks, Inc. 20 Mason Irvine, CA 92618... -
Page 4: Federal Communication Commission Interference Statement
Compliances Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Industry Canada Statement
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the EIRP is not more than required for successful communication. EC Declaration of Conformity SMC contact for these products in Europe is: SMC Networks Spain, S.L. Edificio Conata II,... - Page 6 EU-overensstemmelseserklæring er tilgængelig under det relevante produktafsnit på følgende webadresse: http://www.smc.com. [German] Hiermit erklärt SMC Networks, dass sich dieses Wireless LAN Gerät in Übereinstimmung mit den grundlegenden Anforderungen und den anderen relevanten Vorschriften der Richtlinie 1999/5/EG befindet. Die offizielle EC-Declaration of Conformity finden Sie im Internet unter http://www.smc.com...
- Page 7 Conformity can be found under the corresponding product section on the web http://www.smc.com. [Spanish] Por medio de la presente SMC Networks declara que el Radio LAN device cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
- Page 8 Deklaracja zgodności UE znajduje się w odpowiedniej sekcji produktu w witrynie http://www.smc.com. [Portuguese] A SMC Networks declara que este dispositivo de LAN de Rádio está em conformidade com os requisitos essenciais e com outras provisões relevantes da Directiva 1999/5/CE. A Declaração de Conformidade CE oficial encontra-se na secção correspondente...
- Page 9 Royaume-Uni, Portugal, Grèce, Irelande, Icelande. Des conditions sont appliquées à certains pays pour l’utilisation en extérieur, tels que des licences spécífiques et des canaux d’opération. Veuillez contacter votre autorité locale ou SMC Networks pour plus de détails quant aux restrictions actuelles concernant l’utilisation en extérieur.
- Page 10 Portugal, Spanien, Sverige, Schweiz og Storbritannien. I visse lande gælder der krav vedrørende udendørs betjening af enheden, f.eks. licenskrav og tilladte betjeningskanaler. Kontakt de lokale lovgivende myndigheder eller SMC Networks for at få oplysninger om aktuelle begrænsninger vedrørende udendørs betjening. [Estonian] See seade on 2.4 GHz juhtmeta LAN vastuvõtu-saatejaam, mis on...
- Page 11 Βασίλειο, Πορτογαλία, Ελλάδα, Ιρλανδία, Ισλανδία. Σε ορισμένες χώρες επιβάλλονται απαιτήσεις για χρήση σε εξωτερικό χώρο, όπως απαιτήσεις παραχώρησης άδειας και επιτρεπόμενα κανάλια λειτουργίας. Απευθυνθείτε στην τοπική αρμόδια αρχή ή στην SMC Networks για λεπτομέρειες σχετικά με τους τρέχοντες περιορισμούς για χρήση σε εξωτερικό χώρο.
- Page 12 Unit, Il-Portugal, Il-Greċja, L-Irlanda, L-Islanda. Rekwiżiti għal tħaddim fuq barra, bħal ħtiġijiet ta’ liċenzja u kanali permessi għal tħaddim japplikaw f’ċertu pajjiżi. Jekk jogħġbok ikkuntattja lill-awtorità regolarorja lokali jew SMC Networks għal dettalji dwar restrizzjonijiet attwali dwar l-użu fuq barra. [Hungarian] Ez az eszköz egy 2,4 GHz-es vezeték nélküli LAN adó-vevő,...
- Page 13 Če potrebujete natančne informacije o trenutnih omejitvah uporabe na prostem, se obrnite na lokalni regulativni organ ali družbo SMC Networks. [Slovak] Toto zariadenie je prijímač a vysielač pre bezdrôtové siete v pásme 2,4 GHz a je určené...
- Page 14 Írland, Ísland. Kröfur fyrir notkun utanhúss, svo sem kröfur um leyfi og heimilaðar rásir eiga við í sumum löndum. Hafið samband við reglugerðaryfirvöld á hverjum stað eða SMC Networks til að fá upplýsingar um gildandi takmarkanir á notkun utanhúss. [Norwegian] Denne enheten er en trådløs 2.4 GHz LAN-mottaker som er...
- Page 15 Wichtige Sicherheitshinweise (Germany) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssig- oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. 4.
-
Page 16: Table Of Contents
Table of Contents About this Manual………………………………………………………………………… 16 A. Software Installation………………………………………………………………….. 16 A.1. IP Camera Manager Web version – Installation………………………………. 16 A.2. IP Camera Manager Web version – Uninstall…………………………………. 18 B. Using the IP Camera Manager……………………………………………………… 19 B.1. Starting the Program……………………………………………………………... 19 B.2. -
Page 17: About This Manual
About this Manual This user manual has been designed to help you operate the Web version of IP Camera Manager. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. - Page 18 STEP 3: Click “Install”. STEP 4: The InstallShield Wizard starts to install IP Camera Manager to your computer. The Status bar indicates the installation process. [Note] The installation process may take several minutes to complete, depending on the specifications of your computer system.
-
Page 19: Ip Camera Manager Web Version - Uninstall
A.2. IP Camera Manager Web version – Uninstall STEP 1: Click Start Control Panel Add or Remove Programs. STEP 2: Select IP Camera Manager and click “Remove”. STEP 3: Remove Confirmation. Click “Yes” to remove IP Camera Manager from your system. -
Page 20: Using The Ip Camera Manager
B. Using the IP Camera Manager B.1. Starting the Program Click Start Programs IP Camera manager. On the login window, enter the user’s Account and Password, and then click “OK” to login. [Tip] The other way to start the program is simply double-clicking the IP Camera Manager icon ( ) on the desktop. -
Page 21: The Main Window And Item Feature
B.2. The Main Window and Item Feature When you login to IP Camera Manager, the Main window will display as below: [Note] IP Camera Manager requires the resolution setting up to 1024 x 768. For best view of the application, you are recommended to configure the resolution setting to 1024 x 768 or higher;... - Page 22 Quick Launch Buttons: The five Quick Launch Buttons are located below the Command Bar, providing you with quick launch functions. Button Use to Homepage: Return to the Main window. Live View: Link to the Live View window. Device Setting: Link to the Device Setting window, which allows you to add or remove cameras.
-
Page 23: Accessing The Camera
B.3. Accessing the Camera B.3.1. Add a Camera Before accessing a camera, you have to add the camera to the system through the following steps. STEP 1: Click the Device Setting button ( ) to enter the Device Setting window. On the Device Setting window, click “New”. - Page 24 STEP 4: When search is finished, click “OK”, and the search result will be displayed on the window. Select the desired camera and click “Add”. The information of the STEP 5: selected camera will be displayed on the window. Brand Name: Display the brand name of the camera.
-
Page 25: Edit / Delete A Camera
Preview Window: This window allows you to preview the image of the camera. Click “Preview” to view the image; click “Disconnect” to stop previewing. When completed, click “Save” and then select “OK” to return to the Device Setting window. The added camera will be displayed in the Device List. - Page 26 STEP 2: Delete a camera. To delete the camera, select the desired one and then click “Remove”. When prompted, click “Yes” and then select “OK” to confirm deletion. STEP 3: Edit a camera. To change the configuration of the camera, select the desired one and then click “Modify”.
-
Page 27: View Image Of The Camera
B.3.3. View Image of the Camera Once you have added camera(s) to the system, click the Live View button ( ) and the image of selected camera(s) will be displayed on the Live View window. You can view a maximum of 32 cameras simultaneously. You can select one-camera mode or other modes to display the video from the Live Monitor buttons. - Page 28 patrolling; click the Patrol Off button ( ) to stop patrolling. Click “Calibration” to calibrate the camera. Audio: If the connected camera features audio function, you can use the Audio ON buttons to hear the on-the-spot sound. What’s more, you can deliver your sound to the camera by using the Talk ON button.
-
Page 29: Recording / Playing Video
B.4. Recording / Playing Video B.4.1. Enable / Disable Recording While you are adding/editing the camera, you can enable the recording function for the camera by selecting the Record option. Alternately, you can set all cameras to start/stop recording when you connect multiple cameras. -
Page 30: Playback Of The Recording
B.4.2. Playback of the Recording STEP 1: Click View > Playback. [Tip] You can access the Playback window by clicking the Playback button ( STEP 2: In the Search field, select a camera and assign the period of time to search the video files. -
Page 31: Configuring The Ip Camera Manager
C. Configuring the IP Camera Manager C.1. Configuring the View Setting Click View > Setting to configure the camera view setting. The View Setting window contains three tabs: Group, EMAP, and User Define. C.1.1. Group You can set up a group that contains multiple cameras located in different places, so that you can easily monitor different positions simultaneously by selecting the group. -
Page 32: Edit / Delete Group
STEP 3: Select the desired cameras from the Camera List. STEP 4: When completed, click “Save” and select “OK”. The added group will be displayed in the Group List. C.1.1.2. Edit / Delete Group STEP 1: Click View > Setting > Group tab. STEP 2: Edit the Group. -
Page 33: Emap
C.1.2. EMAP EMAP refer to the geography and device scope of the IP Camera Manager, which visually presents the devices in your security system. It uses a background of the area (e.g. a picture or a map) as the interface for monitoring. C.1.2.1. - Page 34 STEP 3: Select a Picture File from your computer. The selected picture will be displayed in the Preview field. When completed, click “Save” and select “OK”. The add map will be displayed in the EMAP List. STEP 4: In the EMAP List, select the desired item and click “Modify”.
-
Page 35: Edit / Delete Emap
STEP 6: The camera icon will be displayed on selected position of the map. When completed, click “Save” and select “OK”. STEP 7: View from EMAP. Click View > Live View > EMAP. Select the map from the Map Name list. STEP 8: Click the camera icon, the camera window will then pop... - Page 36 STEP 1: Click View > Setting >EMAP tab. STEP 2: Edit the EMAP. In the EMAP List, select the desired one and click “Modify”. The map’s information will be displayed in the EMAP New/Modify field. You can change the map’s information and then click “Save” when completed. STEP 3: Delete the EMAP.
-
Page 37: User Define
C.1.3. User Define You can set up a customized layout of camera view according to your need. C.1.3.1. Set Up Layout Click View > Setting > User STEP 1: Define tab. STEP 2: Click “New” and then enter the Layout Name. STEP 3: Select the desired Layout Style. -
Page 38: Edit / Delete Layout
STEP 4: To assign the position for each camera, select the camera from the Camera List, and then select the desired position number. When completed, click “Save” and select “OK”. The layout will be displayed in the Layout List. C.1.3.2. Edit / Delete Layout STEP 1: Click View >... -
Page 39: Configuring The System
C.2. Configuring the System C.2.1. Set Up the Recording Click System > Recording Setting to configure the recording setting for the system. To assign the destination folder for saving the recorded files, click “Browse” and then select the desired directory. When completed, click “Save” and then select “OK”. [Note] The system will automatically delete the oldest files (10%) when the size of recorded files is up to 90% of the storage space. -
Page 40: Add User
Administrator tab: You can set the administrator password in this tab. To change the administrator password, enter the Original Password, and then enter the new password twice. When completed, click “Save” and then select “OK”. C.2.2.1. Add User... -
Page 41: Edit / Delete User
STEP 1: Click System > Account Setting > User tab, and then click “New”. STEP 2: Enter the user information in the required text boxes. User Account: Enter the account name for the user. User Name: Enter the descriptive name for the user. -
Page 42: Backup System Configuration
can change the user’s information and then click “Save” when completed. STEP 3: Delete the User. In the User List, select the desired one and click “Remove”. The selected user will be removed from the list. [Note] As being a user of the system, you are not allowed to change the system configuration, such as the device setting, account setting, and so on. - Page 43 System Log tab: - Account: Select the log file of the user. If you leave the option blank, the system will search all users' log file. - Function: Select the event type of log file. If you leave the option blank, the system will search all types of function.
- Page 44 - Camera: Select the camera. If you leave the option blank, the system will search all cameras' playback log file. - Account: Select the user. If you leave the option blank, the system will search all users’ playback log file. - Begin Date/Time and End Date/Time: Assign the period of time to search.
- Page 45 - Camera: Select the camera. If you leave the option blank, the system will search all cameras' event log file. - Event Type: Select the event type: All, Record, or Server. - Begin Date/Time and End Date/Time: Assign the period of time to search. When you have set up the required options, click “Search”...
-
Page 46: Event Configuration
C.3. Event Configuration Click Event > Setting to configure the FTP server or SMTP server, so that you can upload images to FTP or send emails that include still images as notification. FTP: Select the Enable FTP option to start the FTP service of the system. When you enable the service, you have to complete the following settings. - Page 47 [Tip] The status of Event Service is indicated by the status icon in the system bar.
-
Page 48: Terminating Operation
D. Terminating Operation When you have finished operating, click File > Logout and select “Yes” to logout the system or click File > Close and select “Yes” to exit the program. - Page 49 IP Camera Manager...
