Table A-1 Log and Event Manager Parameters

IP address of target SNMP device you wish to monitor.
A collection of managed objects.
Name of variable as defined in the MIB.
Value of index as defined in MIB which is used to access a table.
Formula used to filter information.
Criteria used to generate events when the filter conditions are satisfied.
Name of the event used by the Event Manager to handle the threshold
condition.
Beep – an audible alarm issued by the network management station
Show message box – display a user-defined message in a box on the
network management station's screen. The message box appears on top of
all other windows. When the message box appears, you must click on the
<OK> button to dismiss the message. This action is recommended for
critical events.
Run program – execute any Windows-based application. This action is
ideal for sending a message via email or FAX.
Send message to REPORT – Insert a message into the Report window.
Alarm messages are time stamped and shown in chronological order. This
action is recommended for routine events.
Write into database – Put a message into the event database.
Description Example
192.72.24.05
SMC-MIB
sysDescr
1
(VALUE>100) AND
(TIME<120000)
R>100
CRITICAL
CRITICAL: Hub
overheating
PAGER 408-555-4742
WARNING: SERVER
DISK > 90% full
CAUTION: Excessive
CRC errors on device
