HIKVISION DS-2CZ2114P User Manual

HIKVISION DS-2CZ2114P User Manual

Color zoom camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Color Zoom Camera
User Manual
V2.2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2CZ2114P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION DS-2CZ2114P

Summary of Contents for HIKVISION DS-2CZ2114P

  • Page 1 Color Zoom Camera User Manual V2.2.0...
  • Page 2 Color Zoom Camera· User Manual Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to DS-2CZ2114P(N), DS-2CZ2132P(N), DS-2CZ2152P(N), DS-2CZ2152P-IRA, DS-2CZ2182P(N), DS-2CZ2192P(N), DS-2CZ2182P-WD, DS-2CZ2192P-WD zoom Cameras.

  • Page 3: Regulatory Information

    Color Zoom Camera· User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 Color Zoom Camera· User Manual 2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 5 Color Zoom Camera· User Manual Safety Warnings and Cautions Please pay attention to the following warnings and cautions: Hazardous Voltage may be present: Special measures and precautions must be taken when using this device. Some potentials (voltages) on the device may present a hazard to the user. This device should only be used by Employees from our company with knowledge and training in working with these types of devices that contain live circuits.
  • Page 6 Color Zoom Camera· User Manual attached is also connected to properly wired grounded receptacles and are approved medical devices. Power Connect and Disconnect: The AC power supply cord is the main disconnect device to mains (AC power).The socket outlet shall be installed near the equipment and shall be readily accessible.
  • Page 7 Color Zoom Camera· User Manual Perchlorate Material: Special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is required by California Code of Regulations, Title 22, Division 4.5, Chapter 33: Best Management Practices for Perchlorate Materials. This device includes a battery which contains perchlorate material. Taiwan battery recycling: Please recycle batteries.
  • Page 8 Color Zoom Camera· User Manual Lead Content: Please recycle this device in a responsible manner. Refer to local environmental regulations for proper recycling; do not dispose of device in unsorted municipal waste.

  • Page 9: Safety Instruction

    Color Zoom Camera· User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 10 Color Zoom Camera· User Manual responsibility for problems caused by unauthorized repair or maintenance.) To reduce the risk of fire or electrical shock, do not expose this  product to rain or moisture. This installation should be made by a qualified service person ...
  • Page 11 Color Zoom Camera· User Manual The sensor may be burned out by a laser beam, so when any  laser equipment is being used, make sure that the surface of the sensor will not be exposed to the laser beam. Do not place the camera in extremely hot or cold temperatures ...

  • Page 12: Table Of Contents

    Color Zoom Camera· User Manual Table of Contents 1 Introduction ................1 1.1 Product Features ............1 1.2 Function Summary ........... 2 1.3 Application ............... 5 2 Hardware Overview ............6 2.1 Lens................. 6 2.1 Side Panel ..............6 2.2 Connections ............. 8 2.2.1 Rear Panel Definition ........
  • Page 13 Appendix................40 Table 1 DS-2CZ2132P(N) ..........40 Table 2 DS-2CZ2152P(N) ..........43 Table 3 DS-2CZ2152P(N)-IRA........46 Table 4 DS-2CZ2182P(N) ..........49 Table 5 DS-2CZ2192P(N) ..........52 Table 6 DS-2CZ2182P(N)-WD ........55 Table 7 DS-2CZ2192P(N)-WD ........58 Table 8 DS-2CZ2114P(N) ..........61...

  • Page 14: Introduction

    Color Zoom Camera· User Manual 1 Introduction 1.1 Product Features DS-2CZ2114P(N), DS-2CZ2132P(N), DS-2CZ2152P(N), DS-2CZ2152P-IRA, DS-2CZ2182P(N), DS-2CZ2192P(N), DS-2CZ2182P-WD, DS-2CZ2192P-WD series are high performance cameras which adopt advanced print circuit board design technology, possess of high resolutio n, lower distortion, and lower noise features. They are extremely suitable for surveillance system and image process system.

  • Page 15: Function Summary

    Color Zoom Camera· User Manual 3D-Digital Noise Reduction (3D-DNR).  Electronic image stabilization (EIS).  DS-2CZ2182/2192P-WD camera models support Wide  Dynamic Range. 1.2 Function Summary Motion Detection: In the user-defined motion detection surveillance area, the moving object can be detected and trigger alarm.
  • Page 16 Color Zoom Camera· User Manual DAY/NIGHT Auto Switch: The cameras deliver color images during the day. And as light diminishes at night, the cameras switch to night mode and deliver black and white images with high quality. AGC: AGC is a control circuit that automatically changes the gain of a receiver or other piece of equipment, so that the desired output signal remains essentially.
  • Page 17 Color Zoom Camera· User Manual front to make it clear, but this causes the over-exposure of the background where the light is strong. Figure 1-2 BLC OFF and BLC ON WDR (Wide Dynamic Range): The wide dynamic range (WDR) function helps the camera provide clear images even under back light circumstances.

  • Page 18: Application

    Color Zoom Camera· User Manual 1.3 Application The product is applicable to the large-sized monitoring scenes, such as large warehouse, surrounding area of residential district, dock, plaza, school, station, park, etc.

  • Page 19: Hardware Overview

    Color Zoom Camera· User Manual 2 Hardware Overview 2.1 Lens The lens is integrated in the camera. The focal length of the 2132 camera is 3.9-85.8mm, the focal length of 2114 camera is 4.7-84.6mm, the focal length of 2152 camera is 3.84-88.4mm, the focal length of 2182 camera is 3.4-102mm and the focal length of 2192 camera is 3.3-119mm.
  • Page 20 Color Zoom Camera· User Manual Figure 2-2 DS-2CZ215(8)(9)2P(N)-(WD) Side Panel Figure 2-3 DS-2CZ2152P-IRA Side Panel...

  • Page 21: Connections

    Color Zoom Camera· User Manual 2.3 Connections 2.3.1 Rear Panel Definition Figure 2-4 DS-2CZ2132P(N), DS-2CZ2152P(N), DS-2CZ2182P(N), DS-2CZ2912P(N) Rear Panel Definition...
  • Page 22 Color Zoom Camera· User Manual Figure 2-5 DS-2CZ2152P-IRA wiring definition Table 2-1 DS-2CZ2152P-IRA Interfaces Description Name Description GND Interface Power 12V DC Power Supply Zoom and Focus control interfaces Video Video Output Interfaces Output RS-485 D+,D- Control Signal Input...

  • Page 23: I/O Interfaces Description

    Color Zoom Camera· User Manual 2.3.2 I/O Interfaces Description The interfaces description of DS-2CZ21X2P(N) are as follows: Table 2-2 DS-2CZ21X2P(N) interfaces description Pin No. Name Description ZOOM (Wire Control Interface) Lens Zoom Adjustment (Wire Control Interface) Common Interface for the Pins No.
  • Page 24 Color Zoom Camera· User Manual RS-485 External Control Signal Input D+/RS-485 GND Interface Note: The working voltage of Z interface is +3V ~ +12V or -3V ~ -12V. The working voltage of F interface is +3V to +12V or - 3V to -12V.

  • Page 25: Power Supply

    Color Zoom Camera· User Manual The data bit is 8bit.  The stop bit is 1bit.  The parity bit is none.  Day/Night in, GND, Alarm output, Alarm output Com You can use the 4-IN interface to trigger the switching between ...
  • Page 26 Color Zoom Camera· User Manual securely. If the wall is not strong enough, the camera may fall and cause serious damage. There are two mounting methods for box camera: wall mounting and ceiling mounting. You can choose one method on your demand. We take ceiling mounting for example to introduce the mounting steps.
  • Page 27 Color Zoom Camera· User Manual Figure 2-6 Installing the Camera...

  • Page 28: Menu Functions

    Color Zoom Camera· User Manual 3 Menu Functions The menu functions of the DS-2CZ21X2P/N are introduced in this chapter. The first part is the instruction of the menu buttons, the second part is the instruction of the menu configuration of all the items.

  • Page 29: Osd Menu Configuration

    Color Zoom Camera· User Manual Menu button: Pressing the MENU button for 2 seconds, you can enter the menu mode. The main menu displays on the screen. Menu mode: T/W button: You can use these buttons to move the cursor up/down.

  • Page 30: Main Menu Overview

    Color Zoom Camera· User Manual MAIN MENU CAM ID IRIS BLC/WDR BLC… SHUTTER AUTO ATW2 FOCUS AF. . . AUTO… VIDEO SET . . . SPEC IAL . . . EXIT QUIT Figure 3-2 Main Menu 3.2.1 Main Menu Overview Table 3-1 Main Menu The Main Menu Menus...
  • Page 31 Color Zoom Camera· User Manual BLC/WDR BLC… SHUTTER The SHUTTER value can be set to AUTO, AUTOx2, AUTOx4, AUTOx6, AUTOx8, AUTOx12, AUTOx16, AUTOx24, AUTOx32, AUTOx48, AUTOx64, AUTOx96, AUTOx128, AUTOx256, 1/50, 1/120, 1/250, 1/500, 1/1K, 1/2K, 1/4K, 1/10K or the value is not adjustable. The AGC value can be set to LOW, HIGH, OFF or the value is not adjustable.

  • Page 32: Cam Id Setting (Camera Id)

    Color Zoom Camera· User Manual Menus Options GAMMA 0.45/1 MASK ON. . ./OFF Motion Detection: ON. . ./OFF ZOOMRATE 1/2/3/4/5 EZOOM OFF/x2/x4/x6/x8/x10/x12/x14/x16 ZOOMDISP ON/OFF ZCFMOD MODE1/MODE2 RS-485 PROTOCOL/BAUDRATE/ADDRESS PRESET PRESETND/ZOOM SET Return 3.2.2 CAM ID Setting (Camera ID) Steps: 1. Move the cursor to CAM ID, press the left/right buttons to select one number or disable this function.

  • Page 33: Iris Setting

    Color Zoom Camera· User Manual 3.2.3 IRIS Setting The iris mode can be set to Manual. . . , ALC (auto) and ELC (Electronic). Manual. . . mode:  Purpose: You can adjust the Iris manually to adjust the brightness level of the camera.

  • Page 34: Blc/Wdr Setting (Back Light Compensation/Wide Dynamic Range)

    Color Zoom Camera· User Manual MANUAL IRIS LEVEL - - -| - - - - 29 Figure 3-3 Manual Iris 3.2.4 BLC/WDR Setting (Back Light Compensation/Wide Dynamic Range) BLC (Back Light Compensation)  Purpose: When there is a bright backlight and the subjects before the backlight is too dark, you can enable the BLC (Back Light Compensation) function.
  • Page 35 Color Zoom Camera· User Manual 4. If you want to save the settings, move the cursor to EXIT, press the left/right buttons to choose SAVE, press the menu button to save the settings. TYPE OFF/RIGHT/LEFT/DOWN/UP/CENTER Figure 3-4 BLC WDR (Wide Dynamic Range) ...

  • Page 36: Shutter Setting

    Color Zoom Camera· User Manual 2. Move the cursor to LEVEL, press the left/right buttons to adjust the level value. The value is larger, the exposing effect is more obvious. 3. Move the cursor to CONTRAST, press the left/right buttons to adjust the level value.

  • Page 37: Agc Setting (Auto Gain Control)

    Color Zoom Camera· User Manual AUTOx96, AUTOx128, AUTOx256, 1/50, 1/120, 1/250, 1/500, 1/1K, 1/2K, 1/4K, 1/10K. AUTO, AUTOx2, AUTOx4, AUTOx6, AUTOx8, AUTOx12,  AUTOx16, AUTOx24, AUTOx32, AUTOx48, AUTOx64, AUTOx96, AUTOx128, AUTOx256 values are called slow shutter values. When the IRIS value is ELC, the SHUTTER value is not ...

  • Page 38: Wb Setting (White Balance)

    Color Zoom Camera· User Manual  If the speed of the moving objects is normal, you can choose NORM.  If the speed of the moving objects is high, you can choose FAST and FASTER. When the IRIS value is ALC and the SHUTTER value is 1/50, ...
  • Page 39 Color Zoom Camera· User Manual The color temperature range of the ATW2 mode is from 1800K to 15000K. ATC: Select ATC mode, the camera retains color balance  automatically according to the current color temperature. If the lighting environment is changed, you have to readjust the settings accordingly.

  • Page 40: Focus Setting

    Color Zoom Camera· User Manual Figure 3-6 Manual White Balance 3.2.8 FOCUS Setting The FOCUS mode can be set to AF. . . , MANUAL and ONE AF. AF. . .: This is the auto focus setting. If you choose the AF… ...

  • Page 41: D/N Setting (Day/Night)

    Color Zoom Camera· User Manual MODE NORM/INTERVAL SENSE MID/LOW/HIGH NEAR LIM1M, 1.5M, 3M, 6M,10CM,30CM,INF Figure 3-7 Focus Mode Settings ONE AF: If you choose ONE AF mode, the lens w ill be focused  automatically once. You have to manually adjust the focus, when the scene changes.
  • Page 42 Color Zoom Camera· User Manual NIGHT mode can increase the sensitivity in low light  conditions. The camera delivers black and white image. AUTO mode, the day mode and the night mode can switch  automatically. Steps: 3. After moving the cursor to D/N, choose the AUTO… mode. 4.

  • Page 43: Video Parameters Setting

    Color Zoom Camera· User Manual 3.2.10 VIDEO Parameters Setting Steps: 1. Move the cursor to the VIDEO SET… . 2. Press menu button to enter the submenu as shown in Figure 3. In the submenu, the adjustable features are DNR, MIRROR, EXPOSURE, DEFINITION, CONTRAST, CHROMA, POS/NEG, EIS and SUPPRESS.
  • Page 44 Color Zoom Camera· User Manual DNR (Digital No ise Reduction) function can reduce the noise in the image. The reduce value can be set to 1, 2, 3, 4, 5 and OFF. MIRROR  If you turn the MIRROR function on, the image will be flipped. It is like the image in the mirror.

  • Page 45: Special Functions Setting

    Color Zoom Camera· User Manual You can take advantage of this function to reduce the color under the night mode. The value ranges from 0 to 3. 3.2.11 SPECIAL Functions Setting Steps: 1. Move the cursor to the SPECIAL. 2. Press menu button to enter the submenu as shown in Figure 3-10.
  • Page 46 Color Zoom Camera· User Manual MASK (Privacy Mask)  Steps: 1. Move the cursor to MASK, press the left/right buttons to select ON… . 2. Press the menu button to enter the submenu. 3. Move the cursor to MASK NO. to choose a mask number. There are up to 8 privacy masks you can configure.
  • Page 47 Color Zoom Camera· User Manual 9. In the main menu, move the cursor to EXIT, press the left/right buttons to select SAVE, DEL or QUIT 10. Press the menu button to exit the menu. MASK MASK NO. - - -| - - - - - 03 ON/OFF OFF/ON MASK SET...
  • Page 48 Color Zoom Camera· User Manual 2). Press the menu button to select LOC. 3). Press the up/down/left/right buttons to set the position of the motion detection area on the screen. 4). Press the menu button to select SIZE. 5). Press the up/down/left/right buttons to set the size of the area.
  • Page 49 Color Zoom Camera· User Manual Figure 3-12 Motion Detection ZOOMRATE  You can adjust this feature to change the speed of zoom. The value ranges from 1 to 5. The value is larger, the speed is higher. EZOOM  The EZOOM can be set to OFF, x2, x4, x6, x8, x10, x12, x14 and x16.
  • Page 50 Color Zoom Camera· User Manual Before you use the RS-485 interface to send control signal to the camera, you have to configure the RS-485 parameters first. PROTOCOL: The control protocol is PELCO-D. It is not adjustable. BAUDRATE: The baudrate can be set to 1200, 2400, 4800, 9600, 19200 and 38400.

  • Page 51: Exit

    Color Zoom Camera· User Manual 4. Press the up/down buttons to zoom in and zoom out. 5. press the menu button to turn the ◆ symbol to ◇. 6. Move the cursor to EXIT, press the left/right buttons to select SAVE, DEL or QUIT.
  • Page 52 Color Zoom Camera· User Manual  DEFAULT: When you select DEFAULT, all the settings will be initialized to factory settings before exit the menu.  QUIT: When you select QUIT, all the modifications will be canceled before exit the menu. 2.

  • Page 53: Appendix

    Color Zoom Camera· User Manual Appendix Table 1 DS-2CZ2132P(N) Specification DS-2CZ2132P(N) Model Parameter 22X CCD Day&Night Zoom Camera Camera Image Sensor 1/4" SONY Interline Transfer Super HAD-II CCD Signal System PAL/NTSC PAL: 752(H)x582(V) Effective Pixels NTSC: 768(H)x494(V) 0.2Lux @ (F1.6,AGC ON), 0.0008Lux @ Min.
  • Page 54 Color Zoom Camera· User Manual Focal Length 3.9-85.8mm,22X Zoom Speed Approx 3s (Optical Wide-Tele) Angle of View 49.6° -2.40° (Wide-Tele) Min. Working 10-1500mm(Wide-Tele) Distance Aperture Range F1.6-F3.7 Menu Camera ID Off/On (0-254) Iris Mode ALC / Manual / ELC Auto Gain Low/High/Off ATW1 / ATW2 / ATC / Manual Auto White Balance...
  • Page 55 Color Zoom Camera· User Manual Zoom speed Optical Zoom OFF, x2, x4, x6, x8, x10, x12, x14, x16 Zoom Display ON/OFF Model1/Model2 RS-485 Address/Protocol/Baud Rate Preset 0 - 254 General -10° C - 60° C (14° F - 140° F) Operating Conditions Humidity 90% or less(non-condensing) Power Supply...

  • Page 56: Table 2 Ds-2Cz2152P(N)

    Color Zoom Camera· User Manual Table 2 DS-2CZ2152P(N) Specification DS-2CZ2152P(N) Parameter Model 23X CCD Day&Night Zoom Camera Camera Image Sensor 1/4" SONY Interline Transfer Super HAD-II CCD Signal System PAL/NTSC PAL: 752(H)x582(V) Effective Pixels NTSC: 768(H)x494(V) Color: 0.2Lux @ (F1.6,AGC ON), 0.0008Lux @ (F1.6,AGC ON, sensitivity ×...
  • Page 57 Color Zoom Camera· User Manual S/N Ratio More than 50dB Lens Focal Length 3.84-88.4mm,23X Zoom Speed Approx 3s (Optical Wide-Tele) Angle of View 50.2-2.36° (Wide-Tele) Min. Working 10-1500mm(Wide-Tele) Distance Aperture Range F1.6-F4.5 Menu Camera ID Off/On (0-254) Iris Mode ALC / Manual / ELC Auto Gain Low/High/Off Auto White Balance...
  • Page 58 Color Zoom Camera· User Manual stabilization, Back Light Compensation Zoom speed Optical Zoom OFF, x2, x4, x6, x8, x10, x12, x14, x16 Zoom Display ON/OFF Model1/Model2 RS-485 Address/Protocol/Baud Rate Preset 0 - 254 General -10° C - 60° C (14° F - 140° F) Operating Conditions Humidity 90% or less(non-condensing) Power Supply...
  • Page 59 Color Zoom Camera· User Manual Table 3 DS-2CZ2152P-IRA Specification DS-2CZ2152P-IRA Parameter Model 23X CCD Day&Night Zoom Camera Camera Image Sensor 1/4" SONY Interline Transfer Super HAD-II CCD Signal System Effective Pixels 752(H)x582(V) Color: 0.2Lux @ (F1.6,AGC ON), 0.0008Lux @ (F1.6,AGC ON, sensitivity × 256) Min.
  • Page 60 Color Zoom Camera· User Manual Zoom Speed Approx 3s (Optical Wide-Tele) Angle of View 50.2-2.36° (Wide-Tele) Min. Working Distance 10-1500mm(Wide-Tele) Aperture Range F1.6-F4.5 Menu Camera ID Off/On (0-254) Iris Mode ALC / Manual / ELC Auto Gain Low/High/Off Auto White Balance ATW1 / ATW2 / ATC / Manual Focus Mode AF/ONE AF/Manual...
  • Page 61 Color Zoom Camera· User Manual Zoom Display ON/OFF Model1/Model2 RS-485 Address/Protocol/Baud Rate Preset 0 - 254 General -10° C - 60° C (14° F - 140° F) Operating Conditions Humidity 90% or less(non-condensing) Power Supply 12 V DC ± 10% Power Consumption Max.

  • Page 62: Table 4 Ds-2Cz2182P(N)

    Color Zoom Camera· User Manual Table 4 DS-2CZ2182P(N) Specification DS-2CZ2182P(N) Model Parameter 30X CCD ICR Zoom Camera Camera Image Sensor 1/4" SONY Interline Transfer Super HAD-II CCD Signal System PAL/NTSC PAL: 752 (H) × 582 (V) Effective Pixels NTSC: 768 (H) × 494 (V) Color: 0.2Lux @ (F1.6, AGC ON), 0.0008 Lux @ (F1.6, AGC ON, sensitivity ×...
  • Page 63 Color Zoom Camera· User Manual Lens Focal Length 3.4-102 mm, 30X Zoom Speed Approx. 5 s (Optical, Wide-tele) Angle of View 55.8 - 2.0 ° (Wide-tele) Min. Working 10 - 1500mm (Wide-tele) Distance Aperture Range F1.4 – F3.7 Menu Camera ID Off/On (0 - 254) Iris Mode Auto/Manual/Electronic...
  • Page 64 Color Zoom Camera· User Manual Zoom speed Level 1-5 adjustable Digital Zoom Off, ×2, ×4, ×6, ×8, ×10, ×12, ×14, ×16 Zoom Display On/Off ZCF Control Mode 1/Mode 2 Mode RS-485 Protocol/Baud Rate/Address Preset 0 - 254 General -10° C - 60° C (14° F - 140° F) Operating Conditions Humidity 90% or less(non-condensing)

  • Page 65: Table 5 Ds-2Cz2192P(N)

    Color Zoom Camera· User Manual Table 5 DS-2CZ2192P(N) Specification DS-2CZ2192P(N) Model Parameter 36X CCD ICR Zoom Camera Camera Image Sensor 1/4" SONY Interline Transfer Super HAD-II CCD Signal System PAL/NTSC PAL: 752 (H) × 582 (V) Effective Pixels NTSC: 768 (H) × 494 (V) Color: 0.2Lux @ (F1.6, AGC ON), 0.0008 Lux @ (F1.6, AGC ON, sensitivity ×...
  • Page 66 Color Zoom Camera· User Manual Focal Length 3.3 - 119 mm, 36X Zoom Speed Approx. 6 s (Optical, Wide-tele) Angle of View 57.1 - 1.7 ° (Wide-tele) Min. Working 10 - 1500mm (Wide-tele) Distance Aperture Range F1.4 - F4.2 Menu Camera ID Off/On (0 - 254) Iris Mode...
  • Page 67 Color Zoom Camera· User Manual Digital Zoom Off, ×2, ×4, ×6, ×8, ×10, ×12, ×14, ×16 Zoom Display On/Off ZCF Control Mode 1/Mode 2 Mode RS-485 Protocol/Baud Rate/Address Preset 0 - 254 General -10° C - 60° C (14° F - 140° F) Operating Conditions Humidity 90% or less(non-condensing)
  • Page 68 Color Zoom Camera· User Manual Table 6 DS-2CZ2182P-WD Specification DS-2CZ2182P-WD Model Parameter 30X CCD ICR Zoom Camera Camera Image Sensor 1/4" SONY Interline Transfer Super HAD-II CCD Signal System Effective Pixels 752 (H) × 582 (V) Color: 0.2Lux @ (F1.6, AGC ON), 0.0008 Lux @ (F1.6, AGC ON, sensitivity ×...
  • Page 69 Color Zoom Camera· User Manual Angle of View 56.4 - 2.0 ° (Wide-tele) Min. Working 10 - 1500mm (Wide-tele) Distance Aperture Range F1.4 – F3.7 Menu Camera ID Off/On (0 - 254) Iris Mode Auto/Manual/Electronic Auto Gain Off/Low/High Auto White ATW1/ATW2 /ATC/Manual Balance Focus Mode...
  • Page 70 Color Zoom Camera· User Manual ZCF Control Mode 1/Mode 2 Mode RS-485 Protocol/Baud Rate/Address Preset 0 - 254 General -10° C - 60° C (14° F - 140° F) Operating Conditions Humidity 90% or less(non-condensing) Power Supply 12 VDC ± 10% Power Max.
  • Page 71 Color Zoom Camera· User Manual Table 7 DS-2CZ2192P-WD Specification DS-2CZ2192P-WD Model Parameter 36X CCD ICR Zoom Camera Camera 1/4" SONY vertical double density interline Image Sensor Signal System Effective Pixels 752 (H) × 582 (V) Color: 0.2Lux @ (F1.6, AGC ON), 0.0008 Lux @ (F1.6, AGC ON, sensitivity ×...
  • Page 72 Color Zoom Camera· User Manual Zoom Speed Approx. 6 s (Optical, Wide-tele) Angle of View 57.1 - 1.7 ° (Wide-tele) Min. Working Distance 10 - 1500mm (Wide-tele) Aperture Range F1.6 - F4.5 Menu Camera ID Off/On (0 - 254) Iris Mode Auto/Manual/Electronic Auto Gain Off/Low/High...
  • Page 73 Color Zoom Camera· User Manual ZCF Control Mode Mode 1/Mode 2 RS-485 Protocol/Baud Rate/Address Preset 0 - 254 Defect Pixel Correction General -10° C - 60° C (14° F - 140° F) Operating Conditions Humidity 90% or less(non-condensing) Power Supply 12 VDC ±...

  • Page 74: Table 8 Ds-2Cz2114P(N)

    Color Zoom Camera· User Manual Table 8 DS-2CZ2114P(N) Specification DS-2CZ2114P(N) Model Parameter 18X CCD ICR Zoom Camera Camera Image Sensor 1/3" SONY Interline Transfer EXview HAD-II CCD Signal System PAL/NTSC PAL: 976 (H) × 582 (V) Effective Pixels NTSC: 976 (H) × 494 (V) Color: 0.1Lux @ (F1.6, AGC ON), 0.0008 Lux @...
  • Page 75 Color Zoom Camera· User Manual Lens Focal Length 4.55 – 81.9 mm, 18x Zoom Speed Approx. 4 s (Optical, Wide-tele) Angle of View 55.62 – 3.35 ° (Wide-tele) Min. Working 10 - 1500mm (Wide-tele) Distance Aperture Range F1.6 – F2.7 Menu Camera ID Off/On (0 - 254)
  • Page 76 Color Zoom Camera· User Manual Digital Zoom Off, ×2, ×4, ×6, ×8, ×10, ×12, ×14, ×16 Zoom Display On/Off ZCF Control Mode Mode 1/Mode 2 RS-485 Protocol/Baud Rate/Address Preset 0 - 254 Defect Pixel Correction General -10 ° C - 60 ° C (14 ° F - 140 ° F) Operating Conditions Humidity 90% or less (non-condensing) Power Supply...
