Preface

1.

Introduction

1.1
Preface
We welcome you as a customer of the Karl E. Brinkmann GmbH and congratulate you to the aquisition of this
product. You have chosen a product on highest technical standard.
This manual as well as the specified hardware and software are developments of the Karl E. Brinkmann
GmbH. The Karl E. Brinkmann GmbH have prepared the documentation, hardware and software to the
best of their knowledge, however, no guarantee is given that the specifications will provide the efficiency ai-
med at by the user. Karl E. Brinkmann GmbH reserves itself the right to change/adapt specifications and
technical data without previous notification. Errors and ommissions excepted!
The safety and warning directions in this manual as well as in further documentation must be observed for a safe
operation. The safety and warning directions specified in this manual is not exhaustive.
The pictographs used in this manual have following meaning:
The information contained in the technical documentation, as well as any user-specific advice in spoken and writ-
ten and through tests, are made to best of our knowledge and information about the application. However, they
are considered for information only without responsibility. This also applies to any violation of industrial property
rights of a third-party.
Inspection of our units in view of their suitability for the intended use must be done generally by the user. Inspec-
tions are particulary necessary, if changes are executed, which serve for the further development or adaption of
our products to the applications (hardware, software or download lists). Inspections must be repeated completely,
even if only parts of hardware, software or download lists are modified.
Application and use of our units in the target products is outside of our control and therefore exclusively
in the area of responsibility of the user.
1.2

Product description

KEB develop, produce and sell static frequency inverters worldwide in the industrial power range. The inverters of
the type F5 can be equipped optionally with a EhterCAT slave interface. The F5 EtherCAT operator is integrated
into the FI housing by simple plug-in and fits into all F5-units. Here it concerns to an intelligent interface which
controls the data transfer from EtherCAT to the FI control and reverse.
1.3

List of literature

[1]: ESC10/20 Hardware Data Sheet V1.0 v. 8.3.2005
[2]: CANopen Application Layer and Communication Profile DS301 V4.02
[3]: Application manual of the implemented inverter
[4]: CANopen Device profile drives and motion control DSP402 V2.0
Danger
Warning
Caution
Attention
observe at
all costs
Information
Help
Tip
