Assa Abloy UT5200 Series Parts And Service Manual page 28

Cross Reference for Lockset Parts
(Parts cross reference does not include parts for product and cylinder options.)
ITEM PART NO. DESCRIPTION
144F30-8 Spindle
22
156F36-8 Spindle
201F18-8 Spindle
335F98-8 Spindle
606F02-8 Spindle
019F13-7 Spindle Drive Pin
23
019F11-7 Spindle Spring Seat
24
144F29-8 Plug Driver
25
144F88-8 Plug Driver and Spindle Assembly
606F32-8 Plug Driver
606F01-8 Plug Driver
584F81-8 Plug Driver Assembly Follower
26
156F83-7 Pin
27
168F81-8 Plug Driver Assembly
28
29 286F50-7 Pin
251F19-8 Retaining Ring
30
131F27-8 Coupling
31
194F22-8 Bushing
32
107F93-8 Spring
33
019F15-2 Shank Sleeve
34
398F43-8 Emergency Key
35
236L75M020 ANSI Strike
36
480F70 Screw Packet for Strike
37
