UT5210 Passage or Closet

ITEM PART NO. SPECIFY
1
(see chart
below)
2 613F02-9
4 102F198
060F91-8
5
242F50-8
219F80-8
6
103F44-8
103F45-8
7 171F79-8
8
fin
144F33
144F34
301F56-7
605F90
fin
415F15
415F16
415F27-7
605F91
Lever
(specify finish)
Note: Levers are handed.
RH lever: Clockwise rotation. For outside
of RH or RHR locks and inside of LH or
LHR locks.
LH lever: Counter-clockwise rotation.
For outside of LH or LHR locks and inside
of RH or RHR locks.
Knobs
(specify finish)
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 1999-2018, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
DESCRIPTION
Lever or Knob:
plain both sides
Lever Insert (gray)
Lever Shank
Knob Shank
Shank Retainer for
Lever
Knob
Return Spring
Clockwise (RH) Lever
Counter Clockwise (LH) Lever
Return Spring Anchor
Escutcheon (lever Trim)
inside
outside
outside, extended lip
inside, lead lined option M28
Escutcheon (knob Trim)
inside
outside
outside, extended lip
inside, lead lined option M28
plain
plain
UT5200 Parts Manual
ITEM PART NO. SPECIFY
9
222F85 fin
10
496F33 fin
11
138F88-8
12
060F42-8
13
060F33-8
14
249F76-8
15
078F07-8
078F08-8
16
401F08 fin
17
36
236L75M020 fin
480F70 fin
37
Regular
Essex (RH) Essex (LH)
613F10-2 613F11-2
Regular
Global Belmont
383F66 406F33
6
DESCRIPTION
Mounting Screw
Chassis
Chassis Cover
Hub
Hub Spacer
Screw, fixed escutcheon
Grip Retainer
Grip Retainer Ring
Sleeve
ANSI Strike
(see page 25 for options)
Screw Packet for Strike
Tactile Warning
Essex (RH) Essex (LH)
613F14-2 613F15-2
Tactile Warning
Global Belmont
575F58 575F64
