SMC Networks EliteConnect SMCWHSG14-G User Manual page 94

Item
Use for Pre-Paid Billing
Keypad Hot Key
Billing Profile
Use for Post-Paid Billing
Base on ~
Charge by levels
Level (1~10)
Time Range
Unit Price
Please follow steps below to create accounts using keypad function.
Use for Pre-Paid Billing
Step 1: Click the Billing in the Advanced Setup menu, select enable Pre-Paid, click Apply.
SMCWHSG14-G
Default
The system provides ten user definable hot keys through the use of the
+ Key plus the 1 through 0 keys across the top of the keypad.
+1~+0 It is the combination hot key for keypad application.
- Select the billing profile you want to assign to the
combination hot key.
Define the basic rate of accounts.
Minutes Select the billing unit by clicking in the list box.
Enable Enables or disables the charge by levels function.
1~10 This field displays the level number of charge rate.
0 Enter the number.
- Enter the amount of charge level.
Figure 3-79 Billing Setting Screen
Description
93
