Summary of Contents for Grand Golden Line G240

  • Page 2 CONTENTS...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Safety information ..........................10 Introduction ...............................10 Precautionary symbols ..........................11 General information ..........................13 Maximum number of persons ......................... 14 Maximum loading capacity ........................14 Engine information ........................... 15 Risk of flooding and stability ........................16 Bilge pumps and bailing .......................... 16 Stability and buoyancy ..........................
  • Page 6 TABLE OF CONTENTS Man-overboard prevention and recovery .................. 27 Means of reboarding ........................28 Safety equipment .......................... 29 Safety driving rules ........................31 Boat identification .........................32 Boat’s Identification number ......................32 Builder’s plate ..........................33 Before operating your craft ....................35 Weather ............................
  • Page 7 TABLE OF CONTENTS Motor installation ............................. 47 Fueling ............................... 49 Before fueling............................49 While fueling............................. 50 Engine start&stop ............................. 51 Anchoring and mooring.......................... 67 Anchoring ..............................67 Mooring..............................68 Launching and recovering the boat from the water ................71 Beaching ..............................
  • Page 8 Maintenance of stainless steel....................90 Winterizing and storage....................... 90 Regular inspections ........................92 Trailering ..........................93 Lifting the boat ..........................93 Boat towing ............................ 94 Show respect for the environment ..................95 Grand’s warranty ........................... 96 General ............................96 Warranty period ..........................96...
  • Page 9 TABLE OF CONTENTS Warranty coverage ..........................97 Warranty exclusions ..........................98 Warranty certificate ..........................99 For your notes ............................100 Golden Line G420 Owner’s Manual...

  • Page 10: Safety Information

    This Manual provides an overview for the safe operation of your Grand boat. Please take time to read it carefully so as to become familiar with your new boat. Make sure that you fully understand the controls and instructions before operating the boat.

  • Page 11: Precautionary Symbols

    SAFETY PRECAUTIONARY SYMBOLS The following precautionary symbols are used throughout this Manual: Denotes that an extreme intrinsic hazard exists which would result in a high probability of death or serious injury if proper precautions are not taken. Denotes that a hazard exists which can result in injury or death if proper precautions are not taken.
  • Page 12 Data sheets and specifications given in this manual relate to the boat's characteristics at the time of publishing. Grand reserve the right to introduce changes in specifications and equipment without notice and without obligation. We continually work with our customers to improve quality and to ensure you will be completely satisfied with your Grand boat.

  • Page 13: General Information

    SAFETY GENERAL INFORMATION Name of craft Manufacture: GRAND MARINE. Model: G420. According to the Recreational Craft Directive 2013/53/EU of the European Parliament and of the Council of 20 November 2013, which is in force, your boat has design category: C, i.e., the craft is designed to operate in the following conditions: Wind (Beaufort scale) up to and including Force 6.

  • Page 14: Maximum Number Of Persons

    SAFETY MAXIMUM NUMBER OF PERSONS The Maximum number of people (adults + children) authorized to be on board according to design standards ISO 14946 and ISO 12217 is given in the technical data sheet in the “TECHNICAL INFORMATION” section. DO NOT EXCEED THE MAXIMUM RECOMMENDED NUMBER OF PEOPLE. REGARDLESS OF THE NUMBER OF PEOPLE ON BOARD, THE TOTAL WEIGHT OF PEOPLE AND EQUIPMENT MUST NEVER EXCEED THE MAXIMUM RECOMMENDED LOAD.

  • Page 15: Engine Information

    SAFETY WHEN LOADING THE CRAFT, NEVER EXCEED THE MAXIMUM RECOMMENDED LOAD. ALWAYS LOAD THE CRAFT CAREFULLY AND DISTRIBUTE LOADS APPROPRIATELY TO MAINTAIN DESIGN TRIM (APPROXIMATELY LEVEL). AVOID PLACING HEAVY WEIGHTS HIGH UP. ENGINE INFORMATION Information about recommended engine capacities, maximum engine capacities, maximum engine weights for each model are given in the technical data sheet of “TECHNICAL INFORMATION”...

  • Page 16: Risk Of Flooding And Stability

    SAFETY RISK OF FLOODING AND STABILITY BILGE PUMPS AND BAILING The craft is equipped with an automatic bilge pump and drain pipe. THE BILGE PUMP SYSTEM IS NOT DESIGNED FOR DAMAGE CONTROL. CHECK BILGE PUMPS REGULARLY TO MAKE SURE THEY ARE WORKING. CLEAR DEBRIS FROM PUMP INLETS.

  • Page 17: Distribution Of Load

    SAFETY The craft manufacturer guarantees that the boat meets all safety criteria during normal operating conditions. However, the person responsible for operating the craft must always keep in mind that the safety of the craft and crew should be their priority at all times and that conditions on the water can change suddenly with little prior notice.
  • Page 18 SAFETY In case of an accident, do not panic and reassure passengers.  Be aware that your boat, even if damaged, may provide the best shelter and facilitate your rescue. Never leave the boat whilst it remains afloat. Remember that an inflatable boat, even when full of water, is virtually unsinkable.

  • Page 19: Risk Of Fire Or Explosion

    SAFETY RISK OF FIRE OR EXPLOSION Pay particular attention to the fact that a fuel tank and electrical devices are installed on your boat. This means that there is a risk of explosion or fire caused, for example, by a spark. Be careful and check systems regularly with a view to identifying leaks or corrosion in the fuel tank and possible damage to the electrical wiring.
  • Page 20 SAFETY NEVER OBSTRUCT ACCESS TO PORTABLE EXTINGUISHER. NEVER MODIFY ANY OF THE CRAFT’S SYSTEM UNLESS COMPETENT TO DO SO. NEVER FILL ANY FUEL TANK WHEN ENGINE IS RUNNING. NEVER SMOKE WHILE HANDLING FUEL. AVOID CONTACT OF FLAMMABLE MATERIALS WITH HOT ENGINE PARTS.
  • Page 21 SAFETY NEVER DELIBERATELY OR INADVERTENTLY BLOCK VENTILATION OF FIXED PETROL TANK AND BATTERY COMPARTMENTS. NEVER STORE PETROL CONTAINERS OR EQUIPMENT CONTAINING PETROL IN ANY AREA NOT DESIGNATED FOR THE SPECIFIC STORAGE OF PETROL. CHECK FOR FUEL AND GAS VAPOURS OR FUEL LEAKS AT REGULAR INTERVALS AND BEFORE STARTING THE ENGINE.
  • Page 22 SAFETY VENTILATION OF PETROL TANK COMPARTMENT Petrol tank compartment has a natural ventilation system. The fuel tank compartment is ventilated by the natural flow of air through ventilation openings (figs. 1 and 2) to and from the atmosphere. These openings are located at the bow locker and rear dry storage compartments. Fig.
  • Page 23 SAFETY ALL EQUIPMENT THAT BURNS FUEL WILL REQUIRE AN AIR SUPPLY. ENSURE ALL AIR INTAKES ARE CLEAR BEFORE FUEL-BURNING EQUIPMENT IS USED. BEFORE FUELING YOUR BOAT ENSURE ANY STATIC ELECTRICITY IS DISCHARGED BY TOUCHING AN UNPAINTED METAL SURFACE WITH THE FILLER NOZZLE. REMEMBER THAT A STATIC SPARK WILL IGNITE FUMES, CAUSING A FLASH FIRE.
  • Page 24 SAFETY NEVER USE A FLAME TO CHECK FOR LEAKS. IF A FUEL LEAK OR FUMES ARE DETECTED, DO NOT START THE ENGINE. ENSURE ALL CREW LEAVE THE BOAT AND HAVE A QUALIFIED PERSON REPAIR THE FAULT AS SOON AS POSSIBLE. BATTERY 1.

  • Page 25: Fire-Fighting Equipment

    SAFETY FIRE-FIGHTING EQUIPMENT It is the owner/operator’s responsibility to have appropriate fire extinguishers in serviceable condition and readily accessible on board as prescribed by local requirements. At least one portable extinguisher type 34 B shall be present on board. The storage compartment of a portable fire extinguisher is marked by the following symbol: This boat, when in service, shall be equipped with portable fire extinguisher of the following...
  • Page 26 SAFETY NEVER WORK ON THE ELECTRICAL INSTALLATION WHILE THE SYSTEM IS ENERGIZED. NEVER MODIFY THE CRAFT’S ELECTRICAL SYSTEM; INSTALLATION AND MAINTENANCE SHOULD ONLY BE PERFORMED BY A QUALIFIED MARINE ELECTRICAL TECHNICIAN. NEVER ALTER OR MODIFY THE RATED CURRENT AMPERAGE OF OVERCURRENT PROTECTIVE DEVICES.

  • Page 27: Engine Starting

    SAFETY ENGINE STARTING Make sure that the motor is not in gear before attempting to start. MAN-OVERBOARD PREVENTION AND RECOVERY Man-overboard prevention. The working deck has an anti slip surface. When the boat is underway, the operator and passengers should always occupy designated seating areas, using handles when necessary.

  • Page 28: Means Of Reboarding

    SAFETY MEANS OF REBOARDING Due to low freeboard, there are no specific devices to re-board. Because of low freeboard, fiberglass step ends can be used for re-boarding. When using safety handles caution must be paid to prevent the boat from capsizing. Make sure the engine switched off and propeller is not rotating.

  • Page 29: Safety Equipment

    SAFETY SAFETY EQUIPMENT The owner/operator is responsible for ensuring that appropriate safety equipment is onboard and is in proper working condition. The type of safety equipment and quantity will depend on the conditions expected and length of trip. The type of safety equipment required will depend on local or national regulations. In most countries, safety equipment of the following type is required: ...
  • Page 30 SAFETY In addition to the required safety equipment, we recommend tools as listed below. You can also ask your Dealer for any additional recommendations or advice based on local requirements. RECOMMENDED EQUIPMENT  An anchor with at least 25 meters of line. ...

  • Page 31: Safety Driving Rules

    SAFETY SAFETY DRIVING RULES DO NOT EXCEED THE AUTHORIZED NUMBER OF PERSONS OR MAXIMUM WEIGHT  FOR THE CRAFT.  MAKE SURE YOUR PASSENGERS REMAIN SEATED ON SEATS OR ON THE FLOOR. AVOID SITTING ON TUBES.  AVOID BOW RIDING AS IT MAY BE ILLEGAL AND IS EXTREMELY DANGEROUS. DO NOT MAKE SHARP TURNS AT HIGH SPEEDS: YOU COULD BE EJECTED FROM ...

  • Page 32: Boat Identification

    BOAT IDENTIFICATION 2. BOAT IDENTIFICATION BOAT’S IDENTIFICATION NUMBER Every boat has “Watercraft Identification Number” (WIN), which uniquely identifies your boat and is important for safety and identification purposes. The WIN is marked on a non-removable metal plate, which is fixed to the transom area of your boat (fig. 3). Fig.

  • Page 33: Builder's Plate

    BOAT IDENTIFICATION BUILDER’S PLATE The builder's plate (fig. 4), which is fixed to the craft, provides information about the Builder including builder’s name, registered trade or trade mark plus contact name and address, CE marking, craft design category, maximum recommended load excluding the weight of the contents of the fixed tanks when full, number of persons recommended by the builder for which the craft was designed.
  • Page 34 BOAT IDENTIFICATION Always refer to local regulations for information on additional requirements. *Design category (European directive 2013/53/EU): Category Navigation "Inshore" "Protected water" Wind speed (Beaufort scale) Up to and including F6 Up to and including F4 Significant height of wave to Up to and including 2m Up to and including 0.3m consider (in meters)

  • Page 35: Before Operating Your Craft

    BEFORE OPERATING YOUR CRAFT 3. BEFORE OPERATING YOUR CRAFT WEATHER Before starting any trip, check the local weather forecast. Depending on location and seasonal conditions, the weather can sometimes change very quickly. If the weather suddenly changes and conditions become rough: ...

  • Page 36: General

    BEFORE OPERATING YOUR CRAFT GENERAL 1. OBTAIN INFORMATION on local regulations and hazards related to marine activities and boat operation. 2. CHECK weather forecast, local currents, tides and wind conditions. 3. ADVISE someone on land when you expect to be back. 4.

  • Page 37: Checking The Boat And Equipment

    BEFORE OPERATING YOUR CRAFT CHECKING THE BOAT AND EQUIPMENT  Using a pressure gauge, check inflation pressure in each section of the tube (gauge not supplied).  Check the tightness of the outboard motor clamps or bolts.  Remove the cockpit drain plug and check it is working correctly. ...

  • Page 38: Rules To Observe When Afloat

    BEFORE OPERATING YOUR CRAFT  Make sure that each passenger is seated or has a seat available. Inform all passengers regarding the necessity to hold on to safety handles or lines.  Be sure that the boat is equipped with at minimum 2 x boat length of suitable towing line. RULES TO OBSERVE WHEN AFLOAT Be responsible: do not ignore safety rules.
  • Page 39 BEFORE OPERATING YOUR CRAFT 1. DO NOT USE ALCOHOL / DRUGS BEFORE OR WHILE OPERATING YOUR BOAT. 2. DO NOT EXCEED THE AUTHORIZED NUMBER OF PERSONS OR BOAT’S MAXIMUM WEIGHT. 3. MAKE SURE YOUR PASSENGERS REMAIN SEATED ON SEATS OR ON THE FLOOR. AVOID SITTING ON TUBES.
  • Page 40 BEFORE OPERATING YOUR CRAFT D. NEVER KEEP A BATTERY CLOSE TO A FUEL TANK, FILLER OR FUEL SYSTEM COMPONENTS. 1. MAKE SURE THAT THE INFLATABLE TUBE DOES NOT COME INTO CONTACT WITH SHARP OBJECTS, AGGRESSIVE LIQUIDS OR CHEMICALS. 2. INSPECT THE STEERING SYSTEM: AN IMPROPERLY MAINTAINED SYSTEM MAY FAIL, CAUSING SUDDEN LOSS OF CONTROL.

  • Page 41: Operating The Craft

    OPERATING THE CRAFT 4. OPERATING THE CRAFT TUBE INFLATION Inflation valve. A boat is equipped with a valve as shown in figure 5. Fig 5. Inflation valve. To inflate the tube chamber, first open the valve cap by turning it about half a turn counter clockwise (fig.
  • Page 42 OPERATING THE CRAFT Valve cap Strap Spindle a) The valve is closed b) The valve is open Fig. 6. Design of the inflation valve. When the spindle is in the normal (closed) position, the valve operates as a check valve and opens when air is pumped into the tube.
  • Page 43 OPERATING THE CRAFT To inflate the tube chambers, use the foot pump (fig.7) supplied. Fig. 7. Foot pump Fig. 8. Special adapter Insert the end of the hose into the inflation valve using one of the adapters supplied (fig. 8). Make sure the adaptor makes an air-tight connection with the valve and inflate using foot pump.
  • Page 44 OPERATING THE CRAFT Begin the inflation procedure according to the sequence shown in figure 9. Initially, partially inflate each chamber (approx. 0.1 bar (1.45 psi) then repeat the procedure inflating each chamber to its nominal pressure, 0.15 bar (2.15 psi). The nominal pressure is 0,15 bar (2,15 psi).
  • Page 45 OPERATING THE CRAFT Valve caps protect the valves from accidental opening, provide a secondary seal and protect the valves from contamination. The valves require little maintenance. Keep them clean using a standard household cleaner. Remember that changes in ambient temperature will change the inflation pressure within the tube.

  • Page 46: Overpressure Valve (If Fitted)

    OPERATING THE CRAFT OVERPRESSURE VALVE (IF FITTED) Overpressure valves can be fitted to buoyancy tubes as shown in figures 10. It serves to protect the tube from over inflation and excess pressure build up due to solar heat. Without strainer With filter cap Fig.

  • Page 47: Motor Installation

    OPERATING THE CRAFT MOTOR INSTALLATION Information about motor trim is given for reference purposes only. The engine manufacturer’s dealer or authorized agent should undertake installation of the motor on your boat. The optimum position is with the propeller axis parallel with the water. Fig.
  • Page 48 OPERATING THE CRAFT If the motor is tilted too far outwards from the transom, the boat will tend to porpoise. Fig. 12. Trim up. If the motor is tilted too far inwards towards the transom the boat will travel bow down. Fig.13.

  • Page 49: Fueling

    OPERATING THE CRAFT FUELING The fuel system consists of a fuel tank (the volume is given in the technical data sheet), sender and fuel level gauge (on the steering console), filler neck and fuel cap. Fuel cap Fig. 14. The location of the fuel cap on the rear deck. BEFORE FUELING.

  • Page 50: While Fueling

    OPERATING THE CRAFT WHILE FUELING  Keep hose nozzle in contact with the filler pipe to provide a ground against static sparks.  Fill the tank slowly to avoid danger of spillage.  Do not overfill the tank. Leave some room for the fuel to expand. In hot conditions fill the tank to about 80% of its maximum capacity.

  • Page 51: Engine Start&Stop

    OPERATING THE CRAFT USING POOR QUALITY OR UNSUITABLE FUEL CAN RESULT IN DAMAGE TO YOUR ENGINE! IT IS PREFERABLE NOT TO STORE UNUSED FUEL FOR LONG PERIODS IN THE FUEL TANK AND FUEL SYSTEM AS THIS CAN RESULT IN DAMAGE TO FUEL LINES, PUMPS AND FILTERS. ENGINE START&STOP Refer to the engine manufacturer’s manual for correct procedures before using the engine.
  • Page 52 OPERATING THE CRAFT ENGINE KILL SWITCH LANYARD Kill switch lanyard Fig. 15. Engine kill switch lanyard. For safety reasons always use the engine kill switch lanyard. The purpose of the engine kill switch lanyard is to turn off the engine if for any reason the operator is removed from the steering position.
  • Page 53 OPERATING THE CRAFT BATTERY ISOLATOR SWITCH The battery isolator switch is designed to isolate the battery from the boat’s electrical circuit. It is used when the boat is in long-term storage to prevent the battery becoming drained, during maintenance (this should be done by qualified electrical technician. See also “Electrical systems” in the section “Safety rules”) and in emergency cases.
  • Page 54 OPERATING THE CRAFT SWITCH PANEL Use the following switches located on the steering console to switch on/off a horn, navigation lights and bilge pump. Navigation Horn Bilge pump lights Fig. 17. Switch panel.
  • Page 55 OPERATING THE CRAFT FUSE BOARD The fuse board is located on the left inboard side of steering console (under the seat). To change a fuse, unlock and open fuse board transparent cover. Pull out a blown fuse and replace it with a new one. Close the fuse board cover. A rating of relevant fuses are given below.
  • Page 56 OPERATING THE CRAFT AUTOMATIC BILGE PUMP The automatic bilge pump serves to pump water out of the bilge area of the boat. Test knob for checking operation Outlet Inlet channels Fig. 19. Bilge pump. The bilge pump is located inside the rear compartment next to the hull drain plug.
  • Page 57 OPERATING THE CRAFT Pump specifications: Capacity 1.9 m /h (with zero head). Power 13.6 V/1.5 А. Maximum head 2.44 m. Connection 3/4”. Overall dimensions 14х8х10 (LхWхH) cm Switching the bilge pump on and off is done manually by using the switch located on the steering console and automatically by a built-in mercury-free float type switch.
  • Page 58 OPERATING THE CRAFT ELECTRICAL HORN The horn serves as a warning to other craft and individuals when setting off, mooring or in other safety related situations. The horn is mounted on the steering console or on the navigation arch (if fitted). The horn is switched on/off by means of a switch located on the steering console.
  • Page 59 OPERATING THE CRAFT NAVIGATION LIGHTS Navigation lights are designed to indicate the craft's relative position, the nature of its movement or it’s location at night. The side lights are a green light on the starboard side and a red light on the port side.
  • Page 60 OPERATING THE CRAFT HULL DRAINAGE NEVER OPEN THE HULL DRAIN PLUG WHEN AFLOAT. To drain the hull remove the plug (fig. 22). Hull drain plug Fig. 22. The hull drain plug is located on the transom. After removal refit and re-tighten (do not over-tighten) the plug before using the boat.
  • Page 61 OPERATING THE CRAFT COCKPIT DRAINAGE WHEN THE BOAT IS NOT IN USE, OPEN THE COCKPIT DRAIN VALVES SO THAT WATER (RAINWATER, FOR INSTANCE) CAN EASILY DRAIN OUT OF THE BOAT AND NO DAMAGE TO THE INTERNAL COMPONENTS (E.G THE BATTERY) WILL OCCUR. The boat is equipped with two cockpit drain valves located at the transom.
  • Page 62 OPERATING THE CRAFT LIFTING EYES The boat is fitted with lifting eyes at the bow and rear (fig. 24, 25). Use these eyes to lift the boat. Fig.24. Bow lifting eyes, 2 positions. Fig. 25. Rear lifting eyes, 2 positions.
  • Page 63 OPERATING THE CRAFT REMOVABLE SUNDECK WITH CUSHION (IF APPLICABLE) Removable sundeck Fig. 26. Removable sundeck. ALWAYS STORE REMOVABLE SUNDEC INSIDE THE STORAGE COMPARTMENT IF YOU ARE PLANNING TO CRUISE AT MORE THAN 15 KNOTS. Golden Line G420 Owner’s Manual...
  • Page 64 OPERATING THE CRAFT STAINLSESS STEEL RAILS (IF APPLICABLE) Stainless steel bow rails Fig. 27. Stainless steel bow rails. NEVER USE THE RAILS FOR MOORING. TIE-UP ONLY TO THE CLEATS.
  • Page 65 OPERATING THE CRAFT OVERALL COVER (IF APPLICABLE) Fig. 28. Overall cover. Golden Line G420 Owner’s Manual...
  • Page 66 OPERATING THE CRAFT CONSOLE COVER (IF APPLICABLE) Fig. 29. Console cover. DOUBLE SEAT COVER (IF APPLICABLE) KEEL PROTECTOR (IF APPLICABLE)

  • Page 67: Anchoring And Mooring

    OPERATING THE CRAFT ANCHORING AND MOORING ANCHORING Please make sure your craft is equipped with an appropriate anchor and line. If you are not sure, ask your Dealer who will be happy to advise. Setting-up a secure anchorage requires knowledge and practice so it is important that properly trained persons undertake this procedure.

  • Page 68: Mooring

    OPERATING THE CRAFT MOORING Use the bow and rear cleats for mooring. Left bow cleat Right bow cleat Left rear cleat Fig. 30. Bow cleats. Right rear cleat Fig. 31. Rear cleats.
  • Page 69 OPERATING THE CRAFT When the boat is moored or parked the cockpit drain valves should remain open. This will ensure rain water does not accumulate in the boat. Breaking strength, kN Bow cleat Rear cleat THE BREAKING STRENGTH OF LINES SHALL IN GENERAL NOT EXCEED 80% OF THE BREAKING STRENGTH OF THE RESPECTIVE STRONG POINT.
  • Page 70 OPERATING THE CRAFT WATERSKI TOWING MAST (IF APPLICABLE). Always observe safe driving procedures when towing a water skier. For information about waterski towing procedures contact your local power boat school or yacht club. Water towing mast THE SAFE WORKING LOAD OF THE TOWING MAST IS INDICATED ON A LABEL ATTACHED TO THE MAST.

  • Page 71: Launching And Recovering The Boat From The Water

    OPERATING THE CRAFT LAUNCHING AND RECOVERING THE BOAT FROM THE WATER Fiberglass hull Fig. 33. Fiberglass hull. NEVER DRAG THE BOAT OVER A ROUGH SURFACE (ROCKS, STONES, CONCRETE, ETC) AS THE HULL AND TUBE CAN EASILY BE DAMAGED. Regularly check the surface of the fiberglass hull. If the gel coat is damaged, contact your Dealer for repair.

  • Page 72: Beaching

    OPERATING THE CRAFT BEACHING When approaching a beach or waters edge proceed slowly and with extreme caution. Avoid hazards below the water surface such as rocks. Hazards can damage the hull, tube, motor, or propeller. Do not power the boat onto land as serious damage to the hull and tube may result. Do not drag the boat across rough or abrasive surfaces (rocks, concrete etc.).
  • Page 73 OPERATING THE CRAFT Fasten the towed boat securely and observe it continuously. Avoid towing a tender over long distances. Do not use a tow line with signs of damage or wear. Check tow lines for wear and damage prior to use.

  • Page 74: Technical Information

    TECHNICAL DETAILS 5. TECHNICAL INFORMATION TECHNICAL SPECIFICATIONS See the table below for technical specifications of the G420. Model G420 G420H Specification Unit Length overall ft/inches 13’ 9” 13’ 9” Length internal ft/inches 9’ 2” 9’ 2” Beam width ft/inches 6’ 6” 6’...
  • Page 75 TECHNICAL DETAILS Loading capacity 1653 1653 Passenger capacity Number Maximum height (light craft) ft/inches 1’ 9” 1’ 9” 0.42 0.42 Maximum draft (fully loaded), from hull’s ft/inches 1’ 4” 1’ 4” underside lowest point Engine recommended 36,8 36,8 Engine max Engine weight max 264,5 264,5...

  • Page 76: Standard And Optional Equipment

    TECHNICAL DETAILS STANDARD AND OPTIONAL EQUIPMENT STANDARD EQUIPMENT:  Deep “V” hand-laid fiberglass hull.  Bow locker with anchor compartment and hatch.  Hull drain plug.  Towing bow eye, 2 front and 2 rear lifting eyes.  2 rear pull-up cleats. Cockpit drain system with one-way drain valve.
  • Page 77 TECHNICAL DETAILS STANDARD EQUIPMENT FOR GRAND LUXE VERSION:  Battery container, battery isolator switch and cable.  Main boat wiring, including 3 marine switches with fuses.  Navigation lights, electric horn.  Automatic bilge pump with drain pipe.  Electric accessory socket (phone charge plug).

  • Page 78: Compartment Chart

    TECHNICAL DETAILS COMPARTMENT CHART 4. Fuel tank compartment 1. Bow anchor storage 5. Rear dry storage 2. Bow locker 3. Console storage Fig. 35. Compartment chart.

  • Page 79: General Arrangement Of A Boat

    TECHNICAL DETAILS GENERAL ARRANGEMENT OF A BOAT Fig. 36. General arrangement of a boat. Golden Line G420 Owner’s Manual...
  • Page 80 TECHNICAL DETAILS General arrangement of a boat (see fig. 36 on the previous page): Fiberglass hull 2. Multi-chamber buoyancy tube (G420 – PVC tube, G420H – Hypalon tube) 3. Fender guard 4. Anti-slip deck surface 5. Steering console 6. Steering wheel 7.

  • Page 81: Steering Console Components

    TECHNICAL DETAILS STEERING CONSOLE COMPONENTS The ignition key (fig. 37) is located to the right on the steering wheel. When your trip is finished, always remove the key from the ignition switch. This will prevent theft or unauthorized use of your boat. Fig.
  • Page 82 TECHNICAL DETAILS Fig. 38. Steering console components (see the list on the next page).
  • Page 83 TECHNICAL DETAILS Steering console components (see fig. 38 on the previous page): Steering system Double USB socket 5v (8) Steering cable Tachometer (optional*) (7) Steering wheel (2) Switches (9): Windshield (3) − Horn − Navigation lights Left handrail (4) − Bilge pump Throttle lever (5) (optional*) Trim indicator (optional*) Speedometer (optional*) (6)

  • Page 84: General View Of A Boat

    TECHNICAL DETAILS GENERAL VIEW OF A BOAT Fig. 39. General view of a boat.

  • Page 85: Loading Passengers

    TECHNICAL DETAILS LOADING PASSENGERS Fig.40. Recommended seating arrangement. Golden Line G420 Owner’s Manual...

  • Page 86: Electrical Schematic Diagram

    TECHNICAL DETAILS ELECTRICAL SCHEMATIC DIAGRAM Fig. 41. Electrical schematic diagram.

  • Page 87: Service And Maintenance

    SERVICE AND MAINTENANCE 6. SERVICE AND MAINTENANCE CLEANING  Regularly clean your boat and make sure this is done before winterizing.  For cleaning use household cleaner (non abrasive) and fresh water only!  At all times keep the inflatable tube, vinyl and other boat parts free of any chemical components such as: o Gasoline, grease, oil and any other oily product.

  • Page 88: Airtightness Of The Inflatable Tube

    SERVICE AND MAINTENANCE 1. TO AVOID DAMAGE TO YOUR BOAT NEVER USE ANY OTHER THAN SPECIFIED CHEMICALS, CLEANING LIQUIDS OR AGENTS. 2. NEVER USE HIGH PRESSURE CLEANING EQUIPMENT ON YOUR BOAT AS IT MAY CAUSE DAMAGE. AIRTIGHTNESS OF THE INFLATABLE TUBE The tube is considered to be airtight if it retains the recommended inflation pressure for 8 hours.
  • Page 89 SERVICE AND MAINTENANCE  If you discover a significant reduction in pressure, but do not see any obvious sources of leakage: o Step 1: check the inflation/deflation valves and overpressure valves. o Step 2: check the major seams. o Step 3: check the tube material from top to bottom. Contact your Dealer for advice if necessary.

  • Page 90: Maintenance Of Stainless Steel

    SERVICE AND MAINTENANCE MAINTENANCE OF STAINLESS STEEL  We use only top quality stainless steels, which are resistant to corrosion. However, this may not be permanent and maintenance is sometimes required so: o Avoid contamination and scoring to the surface. o Frequently wash with fresh water.
  • Page 91 SERVICE AND MAINTENANCE 1. WHEN THE BOAT IS IN STORAGE MAKE SURE IT IS COVERED. 2. STORE THE BOAT AWAY FROM RODENTS. 3. AVOID SHARP FOLDS IN THE TUBE MATERIAL. Golden Line G420 Owner’s Manual...

  • Page 92: Regular Inspections

    SERVICE AND MAINTENANCE REGULAR INSPECTIONS  Check frequently all navigation lights, horn, VHF radio (if fitted), safety handles, handrails and all other safety related equipment.  Check frequently the tightness of various screws, bolts and nuts, with particular attention to those holding the engine onto the transom.

  • Page 93: Trailering

    TRAILERING 7. TRAILERING Make sure the trailer is set up correctly so that it supports the boat properly. This makes towing safer, and loading and unloading easier. Make certain the boat is properly secured at front and rear of the trailer as incorrect trailering can cause serious traffic accidents and is one of the major causes of boat damage.

  • Page 94: Boat Towing

    TRAILERING BOAT TOWING Before towing your boat please refer to the trailer manufacturer’s manual and also note the following:  The size and carrying capacity of the trailer should be suitable for the size and weight of your boat including the engine. Do not use a trailer that is too big or too small for your boat. ...

  • Page 95: Show Respect For The Environment

    ENVIRONMENT 8. SHOW RESPECT FOR THE ENVIRONMENT REMEMBER THAT RESPONSIBLE BOATING BEGINS WITH YOU! Respect your environment by applying the following basic rules: • AVOID CREATING EXCESSIVE WASH. • KEEP OUT OF DESIGNATED SWIMMING AREAS. • RESPECT ALL ANIMAL LIFE. •...

  • Page 96: Grand's Warranty

    This warranty applies to new Grand Inflatable Boats purchased from an Authorised Grand Marine Reseller. By using the Grand Inflatable Boats, the owner and operator understands and agree to undertake all instructions in the Grand Owner’s Manual, and agrees to all warranty and liability terms and conditions contained in this warranty. WARRANTY PERIOD Grand warrants Grand branded components from the date of purchase for a period of: ...

  • Page 97: Warranty Coverage

     Inflatable tubes. This warranty is limited to repair, or at Grand option, replacement of parts suffering from any of the defects described above during the warranty period. The judgment of Grand is final concerning the extent of items covered under above warranty.

  • Page 98: Warranty Exclusions

     Damage caused by not following procedures and recommendations in the Grand Owner’s Manual.  Operating the craft beyond the design category.

  • Page 99: Warranty Certificate

    WARRANTY WARRANTY CERTIFICATE Name of Customer: __________________________________ Address: ___________________________________________ City: ______________ Post code: _______________________ E-mail_____________ Phone number: ___________________ WIN (Serial number):__________________________________ Signature: __________________________________________ Dealer address: _____________________________________ City: ______________ Post code: _______________________ Date of purchase: ____________________________________ Seller and customer acknowledge by signing that seller handed and customer received hereinbefore boat including standard (optional, if relevant) equipment and manual in English and that the boat is without evident defects.

  • Page 100: For Your Notes

    FOR YOUR NOTES...
