  • Page 1 BILGE PUMP SPECIFICATIONS BILGE PUMP SPECIFICATIONS...
  • Page 2 CONTENTS...
  • Page 4 Edition 8/April 2023...

  • Page 5: Table Of Contents

    Stability and buoyancy ..................18 Engine information ....................18 Risk of flooding and stability .................. 19 Risk of fire or explosion..................23 Fire prevention ....................23 Fuel system ......................24 Before fueling ...................... 26 While fueling ....................... 27 Golden Line G420 Owner’s Manual...
  • Page 6 TABLE OF CONTENTS Fire-fighting equipment ..................28 Electrical systems - safety rules ................30 Battery ....................... 31 Man-overboard prevention and recovery ..............32 Means of reboarding..................... 33 Safety equipment ....................34 Safety driving rules ....................36 BOAT IDENTIFICATION ................40 Boat’s identification number................... 40 Builder’s plate ......................
  • Page 7 Components of a boat ..................63 Anchoring, mooring and towing................71 Anchoring ......................71 Mooring ......................72 Towing ....................... 74 Beaching......................76 TECHNICAL INFORMATION ...............77 Technical specifications ..................77 Standard and optional equipment ................79 Golden Line G420 Owner’s Manual...
  • Page 8 TABLE OF CONTENTS Compartment chart ....................81 General arrangement of a boat ................82 Steering console components ................84 General view of a boat ..................86 Electrical schematic diagram .................. 87 SERVICE AND MAINTENANCE ..............88 Cleaning ......................89 Cleaning of tube ....................90 Plastic preservation ....................
  • Page 9 Regular inspections .................... 100 TRAILERING ....................101 Boat towing....................... 102 RESPECTING THE ENVIRONMENT............103 GRAND’S WARRANTY ................104 General ......................104 Warranty period ....................104 Warranty coverage ..................... 105 Warranty exclusions ................... 106 Warranty certificate .................... 107 FOR YOUR NOTES ...................108 Golden Line G420 Owner’s Manual...

  • Page 10: Safety Information

    This Manual provides an overview for the safe operation of your Grand boat and is not intended to teach you how to repair it. Please take time to read it carefully so as to become familiar with your new boat.

  • Page 11: Precautionary Symbols

    Please note that in some countries a boat operating license or other form of authorization may be required. We strongly recommend that your boat is inspected at least once a year by an authorized Grand agent. Golden Line G420 Owner’s Manual...
  • Page 12 Data sheets and specifications given in this manual relate to the boat's characteristics at the time of publishing. Grand reserve the right to introduce changes in specifications and equipment without notice and without obligation. We continually work with our customers to improve quality and to ensure you will be completely satisfied with your Grand boat.

  • Page 13: General Information

    SAFETY GE NERAL INFORMATION Name of craft Manufacture: GRAND MARINE. Model: G420. According to the Recreational Craft Directive 2013/53/EU of the European Parliament and of the Council of 20 November 2013, which is in force, your boat has design category: C, i.e., the craft is designed to operate in the following conditions: Wind (Beaufort scale) up to and including Force 6.

  • Page 14: Maximum Number Of Persons

    SAFETY M AXIMUM NUMBE R OF PERSONS The Maximum number of people (adults + children) authorized to be on board according to design standards ISO 14946 and ISO 12217 is given in the technical data sheet in the “TECHNICAL INFORMATION” section. DO NOT EXCEED THE MAXIMUM RECOMMENDED NUMBER OF PEOPLE.

  • Page 15: Distribution Of Load

    2. THE CRAFT’S HANDLING WILL CHANGE SIGNIFICANTLY DEPENDING ON THE LOAD CARRIED. 3. BE PARTICULARLY CAREFUL WHEN ACCELERATING OR CHANGING DIRECTION. IT MAY BE NECESSARY TO ADJUST LOAD DISTRIBUTION AND TRIM WHEN NAVIGATION CONDITIONS OR THE CRAFT’S DIRECTION THROUGH WAVES CHANGE. Golden Line G420 Owner’s Manual...

  • Page 16: Loading Passengers

    SAFETY LOADING PASSE NGE RS Fig. 1. Recommended seating arrangement for 6 passengers.
  • Page 17 Following an accident and before using the craft again, make sure that it is examined by your dealer or a qualified technician and any defects are repaired. NEGLECTING REGULAR INSPECTIONS AND REPAIRS MAY LEAD TO A SERIOUS INJURY OR DAMAGE AND WILL REDUCE THE LIFE OF YOUR BOAT. Golden Line G420 Owner’s Manual...

  • Page 18: Stability And Buoyancy

    SAFETY STABILITY AN D BUOYAN CY The stability and buoyancy of the craft have been thoroughly assessed by the builder in compliance with the requirements of the Recreational Craft Directive 2013/53/EU. The craft builder guarantees that the boat meets all safety criteria during normal operating conditions. However, the person responsible for operating the craft must always keep in mind that the safety of the craft and crew should be their priority at all times and that conditions on the water can change suddenly with little prior notice.

  • Page 19: Risk Of Flooding And Stability

    WHEN THE BOAT IS ON LAND/DAVIT OR TRAILER, OPEN THE COCKPIT DRAIN PLUGS SO THAT WATER (RAINWATER, FOR INSTANCE) CAN EASILY DRAIN OUT OF THE BOAT THROUGH THE VALVES AND NO DAMAGE TO THE INTERNAL COMPONENTS (E.G. THE BATTERY) WILL OCCUR. Golden Line G420 Owner’s Manual...
  • Page 20 SAFETY HULL DRAINAGE Hull drain plug NEVER OPEN THE HULL DRAIN PLUG WHEN AFLOAT. Fig. 3. Hull drainage. In water at rest In water in motion Out of water Hull drain plug Closed Closed Open To drain the hull unscrew the plug (fig. 3). After removal refit and re-tighten (do not over-tighten) the plug before using the boat.
  • Page 21 The access to the bilge pump is provided through the opening panel of rear locker (fig. 4). Bilge pump Fig. 4. Bilge pump and its location. THE BILGE PUMP SYSTEM IS NOT DESIGNED FOR DAMAGE CONTROL. Golden Line G420 Owner’s Manual...
  • Page 22 SAFETY BILGE PUMP SPECIFICATIONS Capacity 2.3 m /h (with zero head). Power 12 V/2.5 А. Maximum head 2.3 m. Connection 3/4”. Overall dimensions 17.5х9.5х12 (LхWхH) cm. Switching the bilge pump on/off is done manually by using the switch located on the steering console and automatically by a built-in mercury-free float type switch.

  • Page 23: Risk Of Fire Or Explosion

    − Check firefighting equipment at the intervals indicated on each item. Replace any used extinguisher with one of same type and rating − NEVER MODIFY ANY OF THE CRAFT’S SYSTEM UNLESS COMPETENT TO DO SO. Golden Line G420 Owner’s Manual...

  • Page 24: Fuel System

    SAFETY FUE L SYSTEM The fuel system consists of a fuel tank (the volume is given in the technical data sheet), sender and fuel level gauge (optional), filler neck, fuel cap with built-in air vent. Access to the top part of the fuel tanks, as well to the Fuel filler cap connections and fuel sensor is provided through the hatch located on the deck and fixed by the screws.
  • Page 25 Fig. 6. Ventilation openings on the Fig. 7. Ventilation openings on the rear dry storage compartment. bow locker. DO NOT OBSTRUCT OR MODIFY THE VENTILATION SYSTEM AND VENTILATION OPENINGS. KEEP VENTILATION OPENINGS UNOBSTRUCTED AT ALL TIMES. Golden Line G420 Owner’s Manual...

  • Page 26: Before Fueling

    SAFETY BEFO RE FUELING Check the engine manufacturer’s manual for information about the correct type of fuel be used ▪ for proper and long-term trouble-free operation. Turn off the engine. ▪ Turn off the ignition. ▪ Be sure to extinguish any open flames. ▪...

  • Page 27: While Fueling

    80% of its maximum capacity. If fuel is spilt on the hull, use an ordinary, non-abrasive cleaner then wipe with a damp cloth and rinse the area with clean water. NEVER FILL ANY FUEL TANK WHEN ENGINE IS RUNNING. Golden Line G420 Owner’s Manual...

  • Page 28: Fire-Fighting Equipment

    SAFETY FIRE-FIGHTING EQUIPMENT Most fires are caused by electrical problems or careless fueling. In case of fire, we recommend to stop the motor and turn off the battery switch. It is the owner/helmsman’s responsibility to have appropriate fire extinguishers in serviceable condition and readily accessible on board as prescribed by local requirements.
  • Page 29 BEFORE ALL PASSENGERS ARE FORCED TO LEAVE THE BOAT, CHECK THAT EVERYONE IS WEARING A LIFEJACKET. DUE TO THE FACT THAT BURNING FUEL MAY SPREAD OVER THE SURFACE OF THE WATER AND THE RISK OF EXPLOSION, TRY TO SWIM A SAFE DISTANCE AWAY FROM THE BOAT. Golden Line G420 Owner’s Manual...

  • Page 30: Electrical Systems - Safety Rules

    SAFETY ELE CTRICAL SYSTEM S - SAFE TY RULE S Check condition of battery and charging system before departure. ▪ When the electrical system is in use check that individual components are working satisfactorily. ▪ Disconnect and remove the battery when the craft is in winter storage (cold weather areas) or ▪...

  • Page 31: Battery

    1. AVOID SPARKS AND EXPOSED FLAMES NEAR BATTERY. IT MAY EXPLODE. 2. TURN OFF THE ENGINE WHEN INSPECTING OR SERVICING THE BATTERY. 3. NEVER KEEP THE BATTERY CLOSE TO A FUEL TANK, FILLER OR FUEL SYSTEM COMPONENTS. Golden Line G420 Owner’s Manual...

  • Page 32: Man-Overboard Prevention And Recovery

    SAFETY M AN-OVERBOARD PREVE NTION AND RE COVERY Man-overboard prevention. The working deck has an anti slip surface. When the boat is underway, the helmsman and passengers should always occupy designated seating areas, using handles when necessary. Other parts such as seat backs, cleats, windscreen tops and rails can be used as handholds to reduce the risk of falling overboard.

  • Page 33: Means Of Reboarding

    COULD RESULT IN INJURY OR DEATH! Even in neutral, engine's propeller may rotate and may cause injury. If a person is in the water near the boat, immediately switch off the engine to avoid injury from the propeller rotation. Golden Line G420 Owner’s Manual...

  • Page 34: Safety Equipment

    SAFETY SAFETY EQUIPME NT The owner/helmsman is responsible for ensuring that appropriate safety equipment is onboard and is in proper working condition. The type of safety equipment and quantity will depend on the conditions expected and length of trip. The type of safety equipment required will depend on local or national regulations. In most countries, safety equipment of the following type is required: ▪...
  • Page 35 A whistle or non-electric horn. ▪ Mooring lines and fenders. ▪ Extra engine oil. ▪ A tool kit. ▪ A portable AM/FM radio or weather radio. ▪ Cell Phone with waterproof container. ▪ Binoculars. ▪ Golden Line G420 Owner’s Manual...

  • Page 36: Safety Driving Rules

    SAFETY SAFETY DRIVING RULES NOT USE ALCOHOL/DRUGS BEFORE OR WHILE OPERATING YOUR BOAT. ▪ AVOID BOW RIDING AS IT MAY BE ILLEGAL AND IS EXTREMELY DANGEROUS. ▪ KEEP CLEAR SWIMMERS DIVERS: ALWAYS AVOID AREAS WHERE ▪ DIVERS/SWIMMERS ARE PRESENT. KEEP A SHARP LOOKOUT ESPECIALLY WHEN OPERATING NEAR BEACHES AND BRIDGES. ▪...
  • Page 37 THE BOAT IS DESIGNED FOR RECREATIONAL PURPOSED ONLY, NOT FOR COMPETITIONS. Please remember also that the is not designed to jump through the waves. The builder is not responsible for any damage from excessive loads resulting in neglect of the precautions outlined in this manual. Golden Line G420 Owner’s Manual...
  • Page 38 SAFETY SAFETY LABELS...
  • Page 39 SAFETY Golden Line G420 Owner’s Manual...

  • Page 40: Boat Identification

    BOAT IDENTIFICATION 2. BOAT IDENTIFICATION BOAT’S IDE NTIFICATION NUMBE R Every boat has “Watercraft Identification Number” (WIN), which uniquely identifies your boat and is important for safety and identification purposes. The WIN is marked on a non-removable metal plate, which is fixed to the transom area of your boat (fig. 10). Fig.

  • Page 41: Builder's Plate

    HP. 6 - Maximum weight of outboard motor allowed by the builder expressed in kilograms and lbs. 7 – Nominal Pressure of the buoyancy tubes in Bar and Psi. Fig. 11. Builder’s plate. Golden Line G420 Owner’s Manual...
  • Page 42 BOAT IDENTIFICATION Always refer to local regulations for information on additional requirements. *Design category (European Directive 2013/53/EU): Category Navigation "Inshore" "Protected water" Up to and including F6 Up to and including F4 Wind speed (Beaufort scale) Significant height of wave to Up to and including 2m Up to and including 0.3m consider (in meters)

  • Page 43: Location Of The Builder's Plate

    BOAT IDENTIFICATION LO CATION O F THE BUILDER’S PLATE Builder’s plate Fig. 12. Location of the Builder’s plate. Golden Line G420 Owner’s Manual...

  • Page 44: Before Operating Your Craft

    BEFORE OPERATING YOUR CRAFT 3. BEFORE OPERATING YOUR CRAFT CHE CKLIST BEFORE DEPARTURE Using a pressure gauge (not supplied), check inflation pressure in each section of the tube. ▪ Check the tightness of the outboard motor clamps or bolts. ▪ Inspect the steering system: an improperly maintained system may fail, causing sudden loss of ▪...

  • Page 45: Weather

    6. LEARN how to estimate the distance you can cover with a full tank of fuel. Always be sure you have enough fuel to reach your destination or a place of safety. 7. CHECK you have all necessary documentation and licenses. Golden Line G420 Owner’s Manual...

  • Page 46: Rules To Observe When Afloat

    BEFORE OPERATING YOUR CRAFT RULES TO OBSERVE WHEN AFLO AT Be responsible: do not ignore safety rules. ▪ Make sure that you are always in control of your boat. ▪ Always operate your boat with courtesy and respect for others. ▪...

  • Page 47: Operating The Craft

    To inflate the tube chamber, first open the valve cap by turning it about half a turn counter clockwise (fig. 14). The spindle should be in the upper (closed) position. “O” ring and cap seals of the valve can wear out overtime and can be subject to change. Golden Line G420 Owner’s Manual...
  • Page 48 OPERATING THE CRAFT Valve cap Strap Spindle a) The valve is closed b) The valve is open Fig. 14. Design of the inflation valve. When the spindle is in the normal (closed) position, the valve operates as a check valve and opens when air is pumped into the tube.
  • Page 49 Make sure the adaptor makes an air-tight connection with the valve and inflate using foot pump. To inflate the tube, you can also use a small electric boat pump. IF YOU USE A SMALL ELECTRIC PUMP, COMPLETE THE PROCEDURE BY USING THE FOOT PUMP TO REACH THE REQUIRED NOMINAL PRESSURE. Golden Line G420 Owner’s Manual...
  • Page 50 OPERATING THE CRAFT Begin the inflation procedure according to the sequence shown in figure 16. Initially, partially inflate each chamber (approx. 0.1 bar (1.45 psi) then repeat the procedure inflating each chamber to its nominal pressure, 0.15 bar (2.15 psi). The nominal pressure is 0,15 bar (2,15 psi).
  • Page 51 DO NOT USE SOURCES OF HIGH PRESSURE COMPRESSED AIR FOR INFLATING THE TUBE. EXCESSIVE PRESSURE CAN DAMAGE THE GLUE JOINTS AND THE INTERNAL WALLS. Golden Line G420 Owner’s Manual...

  • Page 52: Overpressure Valve (If Fitted)

    OPERATING THE CRAFT O VERPRESSURE VALVE (IF FITTED) Overpressure valves can be fitted to buoyancy tubes as shown in figure 17. It serves to protect the tube from over inflation and excess pressure build up due to solar heat. Without strainer With filter cap Fig.

  • Page 53: Motor Installation

    The engine manufacturer’s dealer or authorized agent should undertake installation of the motor on your boat. The optimum position is with the propeller axis parallel with the water. CORRECT Fig. 18. Optimum trim. Golden Line G420 Owner’s Manual...
  • Page 54 OPERATING THE CRAFT If the motor is tilted too far outwards from the transom, the boat will tend to porpoise. INCORRECT Fig. 19. Trim up. If the motor is tilted too far inwards towards the transom the boat will travel bow down.

  • Page 55: Motor Start&Stop

    AIR SUPPLY. ENSURE ALL AIR INTAKES ARE CLEAR BEFORE FUEL-BURNING EQUIPMENT IS USED. Fig. 21. Motor. Routine maintenance should be carried out in strict conformity with the instructions given in the appropriate motor owner's manual. Golden Line G420 Owner’s Manual...
  • Page 56 OPERATING THE CRAFT ENGINE KILL SWITCH LANYARD Kill switch lanyard Fig. 22. Engine kill switch lanyard. For safety reasons always use the engine kill switch lanyard. The purpose of the engine kill switch lanyard is to turn off the engine if for any reason the helmsman is removed from the steering position.

  • Page 57: Electrics

    Area of switch location. The switch is on the inner side. disconnecting all devices from the battery. Fig. 23. Location of battery isolator switch. THE BATTERY MUST NEVER BE DISCONNECTED FROM THE ENGINE WHEN IT IS RUNNING! Golden Line G420 Owner’s Manual...
  • Page 58 OPERATING THE CRAFT SWITCH PANEL Use the following switches located on the steering console to switch on/off a horn, navigation lights and bilge pump. Navigation Horn Bilge pump lights Fig. 24. Switch panel.
  • Page 59 The ratings of relevant fuses are given below. Be sure to always have a spare set of appropriate fuses on board. Fuse box Circuit Fuse rating, A Horn Navigation lights Bilge pump Double USB socket Fig. 25. Location of the fuse box. Golden Line G420 Owner’s Manual...
  • Page 60 OPERATING THE CRAFT ELECTRICAL HORN The horn serves as a warning to other craft and individuals when setting off, mooring or in other safety related situations. The horn is mounted on the steering console. The horn is switched on/off by means of a switch located on the steering console. To use the horn press and hold the switch.
  • Page 61 BEFORE NAVIGATE AT NIGHT, INSTALL THE NAVIGATION LIGTH MAST. A mount fitting of mast is Red left (port) navigation located on the right side of light on the steering console transom area Fig. 27. Navigation lights. Golden Line G420 Owner’s Manual...
  • Page 62 OPERATING THE CRAFT LIFTING EYES To lift the boat and place it on davits, use the factory fitted lifting eyes only (figs. 28, 29).Use only certified and rated lifting slings, appropriate for your boat and motor weight. Fig. 28. Bow lifting eyes, 2 positions. Fig.

  • Page 63: Components Of A Boat

    BOW LOCKER WITH CUSHION Bow locker We recommend to have all lockers, storage boxes, hatched compartments are closed securely. Fig. 30. Bow locker with cushion. BE CAREFUL WHEN OPENING/CLOSING THE HATCHES. THEIR ACCIDENTAL CLOSING COULD INJURE YOU. Golden Line G420 Owner’s Manual...
  • Page 64 OPERATING THE CRAFT REMOVABLE BOW SUNDECK WITH CUSHION (IF APPLICABLE) Removable sundeck Fig. 31. Removable bow sundeck. NEVER USE BOW SUNDECK WHEN THE BOAT IS UNDERWAY. THERE IS A RISK TO FALL OVERBOARD. ALWAYS STORE REMOVABLE SUNDEC INSIDE THE STORAGE COMPARTMENT IF YOU ARE PLANNING TO CRUISE AT MORE THAN 15 KNOTS.
  • Page 65 Before make a trip, check that all cushions are fastened well. Always remove cushions carefully. Do not pull the cushion to open a snap button. Fig. 32. Rear lockable seat with cushion and seat back. Golden Line G420 Owner’s Manual...
  • Page 66 OPERATING THE CRAFT STAINLSESS STEEL RAILS (IF APPLICABLE) Stainless steel bow rails Fig. 33. Stainless steel bow rails. NEVER USE THE RAILS FOR MOORING. TIE-UP ONLY TO THE CLEATS AND BOW TOWING EYE.
  • Page 67 USE A BIMINI TOP WHEN YOUR BOAT IS NOT IN MOTION. KEEP BIMINI TOP IN STOWED POSITION IF YOU PLANNING TO CRUISE AT MORE THAN 20-25 KNOTS. STORE THE BIMINI TOP IN FOLDED CONDITION IF YOU ARE NOT GOING TO USE IT FOR A LONG TIME. Golden Line G420 Owner’s Manual...
  • Page 68 OPERATING THE CRAFT BIMINI TOP INSTALLATION PROCEDURE A bimini top is supplied pre-assembled. 1. Unpack the Bimini Top. 2. Unfold it, than insert the poles into connectors (fig. 35). Fig. 35. Close view of connectors. 3. Insert the pole eye end into PVC support securing by a thumb screw. 4.
  • Page 69 THE SAFE WORKING LOAD OF THE TOWING MAST IS INDICATED ON A LABEL ATTACHED TO THE MAST. DO NOT USE THE TOWING ARCH TO PULL A BANANA TUBE. Fig. 36. Waterski towing mast. Golden Line G420 Owner’s Manual...
  • Page 70 OPERATING THE CRAFT SEADECK ANTISKID SET (IF APPLICABLE) The following area of your boat (depending on the model) can be enhanced SeaDeck antiskid material: Deck ▪ Bow step plate ▪ Fiberglass step ends ▪ Extremely stain resistant SeaDeck Fig. 37. SeaDeck antiskid product. surface, if needed, can be easily cleaned with soap, hot water, and a Safe and comfortable non-absorbent long life product...

  • Page 71: Anchoring, Mooring And Towing

    Use local landmarks to obtain an approximate fix for the craft’s position and check this regularly. When not in use, ensure the anchor and line are stored in the anchor locker. Golden Line G420 Owner’s Manual...

  • Page 72: Mooring

    OPERATING THE CRAFT MOO RING Use the right, left cleats and bow towing eye for mooring. Left bow cleat Right bow cleat Left rear cleat Fig. 38. Bow cleats. Right rear cleat Fig. 39. Rear cleats.
  • Page 73 THE BREAKING STRENGTH OF LINES SHALL IN GENERAL NOT EXCEED 80% OF THE BREAKING STRENGTH OF THE RESPECTIVE STRONG POINT. BE VERY CAREFUL WHEN MOORING: ARMS AND LEGS MAY BE INJURED IF THEY ARE OUTSIDE THE BOAT. DON’T USE SAFETY HANDS, RAILS, HANDRAILS, STEERING WHEEL FOR MOORING. Golden Line G420 Owner’s Manual...

  • Page 74: Towing

    OPERATING THE CRAFT TOWIN G When towing an inflatable boat behind another craft, always connect the tow line only to the towing eyes. It’s forbidden to use handles, railings, cleats or other equipment which is not designated for towing. If possible, use a double tow line when towing behind another boat. The second line acts as a backup in case one line breaks or comes undone.
  • Page 75 WEATER CONDITIONS WITH NO WAVES. 2. THE BOAT BEING TOWED MUST BE OBSERVED AT ALL TIMES. 3. THE BREAKING STRENGTH OF LINES SHALL IN GENERAL NOT EXCEED 80% OF THE BREAKING STRENGTH OF THE BOW TOWING EYE. Golden Line G420 Owner’s Manual...

  • Page 76: Beaching

    OPERATING THE CRAFT BE ACHING NEVER DRAG THE BOAT OVER A ROUGH SURFACE (ROCKS, STONES, CONCRETE, ETC) AS THE HULL AND TUBE CAN EASILY BE DAMAGED. Fiberglass hull Fig. 41. Fiberglass hull. Regularly check the surface of the fiberglass hull. If the gel coat is damaged, contact your Dealer for repair.

  • Page 77: Technical Information

    Specification Unit Length overall ft/inches 13’9” Length internal ft/inches 9’2” Beam width ft/inches 6’6” Width internal ft/inches 3’3” Chambers Number Tube diameter inches 19” Tube fabric PVC/Hypalon Bare boat weight* Fully loaded weight** 1086 2394 Golden Line G420 Owner’s Manual...
  • Page 78 TECHNICAL DETAILS Loading capacity 1653 Passenger capacity Number Maximum height (light craft) ft/inches 3’7” 0.42 Maximum draft (fully loaded), from hull’s ft/inches 1’4” underside lowest point Engine recommended 36,8 Engine max 44,1 Engine weight max Engine shaft length inches 20’’ (long) Midsection/aft deadrise degrees 20°/17°...

  • Page 79: Standard And Optional Equipment

    Steering console CL-24 with windshield, cup holder and side railings ▪ Mechanical steering system with steering wheel ▪ Rear seat cushion and seatback ▪ Two rear seat handrails, two rear cleats ▪ 2 paddles, foot pump, maintenance kit ▪ Golden Line G420 Owner’s Manual...
  • Page 80 TECHNICAL DETAILS GRAND LUXE FEATURES: Electric package with navigation lights, bilge pump, electric horn, ▪ switches, battery switch and complete wiring Fuel system with 55 l tank and sender ▪ OPTIONAL EQUIPMENT: Bow removable sundeck set with cushions ▪ Stainless steel waterski towing mast ▪...

  • Page 81: Compartment Chart

    TECHNICAL DETAILS COM PARTMENT CHART 4. Fuel tank compartment 1. Bow anchor storage 5. Rear dry storage 2. Bow locker 3. Console storage Fig. 42. Compartment chart. Golden Line G420 Owner’s Manual...

  • Page 82: General Arrangement Of A Boat

    TECHNICAL DETAILS GE NERAL ARRANGEME NT OF A BOAT Fig. 43. General arrangement of a boat.
  • Page 83 9. Bow rail 10. Bow locker with removable cushion 11. Bow step plate 12. Rear seat back with soft cushion 13. Reinforced transom for motor installation 14. Cleat 15. Fiberglass step end 16. Fuel filler cap Golden Line G420 Owner’s Manual...

  • Page 84: Steering Console Components

    TECHNICAL DETAILS STEERIN G CON SOLE CO MPON ENTS Fig. 44. Steering console components (see the list on the next page).
  • Page 85 When your trip is finished, always remove the key from the ignition switch. This will prevent theft or unauthorized use of your boat. * - Please contact your regional Dealer for the installation of required components. Golden Line G420 Owner’s Manual...

  • Page 86: General View Of A Boat

    TECHNICAL DETAILS GE NERAL VIEW OF A BOAT Fig. 45. General view of a boat.

  • Page 87: Electrical Schematic Diagram

    TECHNICAL DETAILS ELE CTRICAL SCHEM ATIC DIAGRAM Fig. 46. Electrical schematic diagram. Golden Line G420 Owner’s Manual...

  • Page 88: Service And Maintenance

    SERVICE AND MAINTENANCE 6. SERVICE AND MAINTENANCE Only high-quality materials suited for marine environments are used in production of our boats. Nevertheless, without a regular and proper maintenance, the moisture and saltiness inherent to this environment can reduce their service life. A dedicated cover for the whole boat is the best protection against UV degradation of gelcoat and fabric of the tube.

  • Page 89: Cleaning

    Use cleaning agents specifically formulated for cleaning inflatable boats and RIBs. A high-pressure washer can be used for cleaning the hull. DON’T USE A HIGH-PRESSURE WASHER FOR TUBE WASHING. Golden Line G420 Owner’s Manual...

  • Page 90: Cleaning Of Tube

    SERVICE AND MAINTENANCE CLEANING OF TUB E An important factor for the long life of tube fabric is regular adequate cleaning. The subsequent cleaning procedure is recommended: Rinse off with clear, tap water (approx. 20 °C). ▪ Use gentle soapy water (pH value neutral to slightly alkaline) to wash the tube by means of a soft ▪...
  • Page 91 Solvent based cleaning agents (e. g. based on ester, ketone, ether, furan or benzol). ▪ Petrol, diesel, kerosene. ▪ Self-made cleaning agents. ▪ Bleaching or oxidizing cleaning agents (e.g. containing hydrogen peroxide, sodium ▪ hypochlorite, chlorine dioxide or sodium dithionite). Golden Line G420 Owner’s Manual...

  • Page 92: Plastic Preservation

    SERVICE AND MAINTENANCE PLASTIC PRE SERVATION Surface quality may degrade by solar exposure, heat, salt deposits, anthropogenic pollution and vehicle exhaust gases. The gelcoat surfaces will last a long time if regularly and properly cared for. Keeping the surface clean and periodic waxing are key points in gelcoat care. In the marine environment, protection of plastic surfaces must be applied more regularly than on your car because the sun is stronger and the horizon is longer than on shore.

  • Page 93: Salt Removal

    Be sure to read the instructions before application. Preferably choose the time to work or position the boat so you can work in the shade, both to keep the surface cool and to keep from going blind. Golden Line G420 Owner’s Manual...
  • Page 94 SERVICE AND MAINTENANCE CLE ANI NG OF T HE UNDE RWATE R PART OF T HE HULL FROM DE POSIT S Cleaning with a high-pressure washer The best means for removing stubborn deposits is a high-pressure washer. However, when using a high-pressure washer, use it carefully so that the jet does not hit the tube.

  • Page 95: Upholstery Care

    Do not use solvents, acetone, whiteners, waxes, silicones and other harsh chemicals ▪ STORAGE If you don’t use the boat, take care to cover all upholstery to protect it from environment hazards. During the storage, be sure about free air circulation around the cushions. Golden Line G420 Owner’s Manual...

  • Page 96: Acrylic Glass Windshield Care

    SERVICE AND MAINTENANCE ACRYLIC GLASS WINDSHIELD CARE Only clean water and soft microfiber, cotton or flannel cloth should be used for acrylic glass windshield cleaning. To remove stubborn stains, use only cleaners formulated specifically for cleaning acrylic surfaces. TO PREVENT SCRATCHES, DAMAGE, TURBIDITY AND OTHER DEFECTS: Do not make dry cleaning ▪...

  • Page 97: Airtightness Of The Inflatable Tube

    Never use high-pressure equipment to inflate your boat. Changes in ambient temperature have a significant influence on air pressure within the tube. ▪ A variation of 1°C results in a variation in pressure of about +/- 4 mb (0,06 psi). Golden Line G420 Owner’s Manual...
  • Page 98 SERVICE AND MAINTENANCE IN CASE OF AN AIR LEAKAGE If a significant drop of pressure has occurred, make a visual check of the tube: o Step 1 - check the inflation/deflation valves and overpressure valves- if there is no contamination and all seals are in good state. o Step 2 - check the major seams.

  • Page 99: Maintenance Of Stainless Steel

    Grease all metal moving parts and connections, including steering. o Properly close the fuel system to avoid any vapour leaks. o If possible, allow air to circulate within the boat, a breathable canvas cover will help. Golden Line G420 Owner’s Manual...

  • Page 100: Regular Inspections

    SERVICE AND MAINTENANCE Winterize the motor, following the manufacturer’s instructions. 1. WHEN THE BOAT IS IN STORAGE MAKE SURE IT IS COVERED. 2. STORE THE BOAT AWAY FROM RODENTS. 3. AVOID SHARP FOLDS IN THE TUBE MATERIAL. RE GULAR INSPE CTIONS Check frequently all navigation lights, horn, VHF radio (if fitted), safety handles, handrails and ▪...

  • Page 101: Trailering

    Lateral bunks should be used just for extra support and stability. boat designed transported with an inflated tube. Fig. 47. Trailer. DO NOT USE A ROLLER TRAILER, AS ROLLERS DO NOT PROVIDE ADEQUATE SUPPORT FOR THE HULL. Golden Line G420 Owner’s Manual...

  • Page 102: Boat Towing

    TRAILERING BOAT TOWING Before towing your boat please refer to the trailer manufacturer’s manual and also note the following: Make sure that the trailer provides adequate support for the keel and bunks that provide large ▪ contact areas for the hull. The boat is properly inflated and the cockpit drain plugs are open.

  • Page 103: Respecting The Environment

    The health of our environment depends on us all acting responsibly to ensure a clean tomorrow. If each of us follows these few simple rules, we can help to keep the Earth's resources intact for future generations. Golden Line G420 Owner’s Manual...

  • Page 104: Grand's Warranty

    This warranty applies to new Grand Inflatable Boats purchased from an Authorised Grand Marine Reseller. By using the Grand Inflatable Boats, the owner and helmsman understands and agree to undertake all instructions in the Grand Owner’s Manual, and agrees to all warranty and liability terms and conditions contained in this warranty. WARRANTY PERIOD Grand warrants Grand branded components from the date of purchase for a period of: 24 consecutive months for normal personal recreational use*.

  • Page 105: Warranty Coverage

    Inflatable tubes. ▪ This warranty is limited to repair, or at Grand option, replacement of parts suffering from any of the defects described above during the warranty period. The judgment of Grand is final concerning the extent of items covered under above warranty.

  • Page 106: Warranty Exclusions

    ▪ requirements, oil and lubrication, replacement of fuses or bulbs, linkage adjustments, filters and spark plugs, tyres, and other consumable items. Damage caused by not following procedures and recommendations in the Grand Owner’s ▪ Manual. Operating the craft beyond the design category.

  • Page 107: Warranty Certificate

    Seller and customer acknowledge by signing that seller handed and customer received hereinbefore boat including standard (optional, if relevant) equipment and manual in English and that the boat is without evident defects. SELLER SIGNATURE: CUSTOMER SIGNATURE: Golden Line G420 Owner’s Manual...

  • Page 108: For Your Notes

    FOR YOUR NOTE S...
