GRAND Golden Line G480
UM14800
Rigid Inflatable Boat
Golden LINE
Models:
G480LF, G480GLF
G480EF, G480GEF
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G480LF and is the answer not in the manual?

Questions and answers

Summary of Contents for Grand G480LF

  • Page 1 GRAND Golden Line G480 UM14800 Rigid Inflatable Boat Golden LINE Models: G480LF, G480GLF G480EF, G480GEF User’s Manual...
  • Page 2 GRAND Golden Line G480 UM14800 INTRODUCTION. "GRAND" inflatable motor boat of the "GOLDEN LINE" series: G480LF, G480EF has been designed under requirements of ISO 6185 "Plastomer and Elastomer Inflatable Boats" and DIN 7870 "Inflatable Boats with Reinforced Shells". PURPOSE. The rigid inflatable motor boat of the "GOLDEN LINE" series relates to the category of pleasure boats and is intended for...
  • Page 3 GRAND Golden Line G480 UM14800 TECNICAL DATA SPECIFICATION Model Unit G480LF/G480GLF/G480EF/G480GEF Length overall 4,55 ft-inches 14'11" Length inside ft-inches 11'2" Width overall 2,10 ft-inches 6'11" Width inside 1,05 ft-inches 3'5" Tube diameter max 0,51 ft-inches 20" Number of chambers Passenger capacity pers.
  • Page 4: Complete Set

    GRAND Golden Line G480 UM14800 COMPLETE SET Model G480LF/G480GLF G480EF/G480GEF Description unit q-ty availability availability 1. Standart feature 1.1 Deep “V” hand-laid fiberglass hull with antiskid surfase pcs. Towing bow eye pcs. 1 front and 2 rear lifting eyes set.
  • Page 5 GRAND Golden Line G480 UM14800 COMPLETE SET Model G480LF/G480GLF G480EF/G480GEF Description unit q-ty availability availability 2. GRAND LUXE feature Battery container pcs. Disconnector and battery wire pcs. Marine boat cable pcs. Marine switches pcs. Fuses pcs.. Bilge pump pcs. Electric accessory socket pcs.
  • Page 6 √ √ √ √ √ — Your "GRAND" boat "GOLDEN LINE" complete set included this items. Note: Perfection of the design and improvment of quality of our products is the fundamental production policy of our company. Therefore, alternations may be made to the complete set (and as the components parts become available).
  • Page 7 GRAND Golden Line G480 UM14800 G480LF...
  • Page 8 GRAND Golden Line G480 UM14800 G480EF...
  • Page 9 GRAND Golden Line G480 UM14800 Pos. Item Fiberglass hull Buoyancy tube nflation / deflation valve St. steel arc Towing bow eye Stern lifting eyes Bow step plate with rope cleat Fuel filler Antiskid deck surface Doublead raised rubbing strake Safety grab handles...
  • Page 10: Steering Console Installation

    GRAND Golden Line G480 UM14800 Fig. 1 PREPARATION FOR EXPLOITATION In order to set the boat in the operation condition perform as follows: unfold the inflatable tube; mount the outboard engine on the transom in accodance with it`s own installation instruction.
  • Page 11 GRAND Golden Line G480 UM14800 SOFT BACK OF STERN LOCKER SEATING MOUNTING ARC MOUNTING In order to install the arc, perform the next: In order to install the stern locker seat-back, perform the next: hinge out the seat of stern locker;...
  • Page 12 GRAND Golden Line G480 UM14800 SUNDECK MOUNTING CONSOLE EQUIPMENT Console equipment included: In order to install the sundeck, perform the next operations: - steering system; - open the bow locker and console front seating: - steering cable; - insert the sundeck floor board into the specified recesses in - steering wheel;...
  • Page 13: Inflation / Deflation Valves Operation

    GRAND Golden Line G480 UM14800 INFLATION / DEFLATION VALVES OPERATION The inflation/deflation valve is intended for: Fig.6 —filling the compartment with air from a standart pump or filling system and maintaining pressure in the tube for prolonged time, —adjustable drop of pressure in compartment.
  • Page 14 GRAND Golden Line G480 UM14800 Wiring diagram CONSOLE NAVIGATION ARCH Fuel meter +12v panel light Speedometer +12v on ignition switch Signal Masthead light (white) Horn Tachometer Port light (red) X1- Connector block +12v on ignition switch Wire legend Starboard light (green)
  • Page 15: Maintenance

    GRAND Golden Line G480 UM14800 MAINTENANCE OPERATING REGULATIONS Dear user, Main conditions of long service life is right and careful service. We thank your for your purchase and do hope that you will Avoid excessive increasing of pressure in the board, have a great fun of it.
  • Page 16 GRAND Golden Line G480 UM14800 Observation of local shipping regulations not accommodate all passengers on the same side of the boat. Arrange the cargo to be carried uniformly inside the boat, all For each particular water area the local shipping regulations items being reliable secured on the bottom of the boat.
  • Page 17 The The "GRAND" Company employees would like to wish you a steersman of the towed boat should be assisted by another pleasant and safe leisure time! crew member to monitor the process of towing.
