Power and environmental specifications

For indoor use only.
100 VAC to 240 VAC, 50 Hz to 60 Hz
Power supply
(autosensing)
240 VA
Maximum VA
Maximum 2000 m (6562 ft) above
Operating altitude
sea level
0 °C to 50 °C, 70% relative humidity
Operating
temperature
up to 35 °C
Derate 3% relative humidity, 35 °C to 50 °C
25 °C to 65 °C
Storage temperature
1 or 2
Pollution degree
30.3 W maximum
DC source output
±200 VDC maximum
±1.515 A at ±20 VDC
±101 mA at ±200 VDC
Region maximums: 10 A at 5 V
Pulse region 4*
Maximum pulse width: 1 ms
Maximum duty cycle: 2.2%
Measurement category O
Measurement
input
Voltage: 200 VDC maximum HI to LO,
250 VDC LO to ground
Current: 101 mA at 200 V;
1.515 A at 20 V
Impedance: Variable
*See full specifications for other pulse regions
Carefully consider and configure the appropriate output-
off state, source levels, and compliance levels before
connecting the instrument to a device that can deliver
energy. Failure to consider the output-off state, source
levels, and compliance levels may result in damage to the
instrument or to the device under test.
