2 SPECIFICATION
2.1 Technical specifications Combi AC0 / ACE0
Inverter for traction AC asynchronous 3-phase motors plus chopper for DC series
pump motors.
Regenerative braking functions.
Digital control based upon microcontroller
Voltage:..................................................................................................24, 36, 48V
Inverter maximum current (24V, 36V):........................................ 220A (RMS) for 2'
Inverter maximum current (36V, 48V):........................................ 180A (RMS) for 2'
Continuous output current (24V, 36V): ..............................105A (RMS) continuous
Continuous output current (36V, 48V): ................................90A (RMS) continuous
Inverter operating frequency:...........................................................................8kHz
Dc chopper Maximum current (24V,36V)(1): ......................................... 270A for 2'
Dc chopper Maximum current (36V, 48V)(1): .........................................220A for 2'
Chopper Operating frequency(1): ..................................................................16kHz
External temperature working range:..................................................-40°C ÷ 40°C
Maximum heatsink temperature (start of the thermal cutback)........................ 85°C
4
Note(1): The DC chopper specifications are related to Combi AC0
2.2 Technical specifications Combi AC0 Power / ACE0 Power
Inverter for traction AC asynchronous 3-phase motors plus chopper for DC series
pump motors.
Regenerative braking functions.
Digital control based upon microcontroller
Voltage:..................................................................................................24, 36, 48V
Inverter maximum current (24V, 36V):........................................ 320A (RMS) for 2'
Inverter maximum current (36V, 48V):........................................ 280A (RMS) for 2'
Continuous output current (24V, 36V): ..............................130A (RMS) continuous
Continuous output current (36V, 48V): ..............................110A (RMS) continuous
Inverter operating frequency:...........................................................................8kHz
Dc chopper Maximum current (24V,36V)(1): ......................................... 270A for 2'
Dc chopper Maximum current (36V, 48V)(1): .........................................220A for 2'
Chopper Operating frequency(1): ..................................................................16kHz
External temperature working range:..................................................-40°C ÷ 40°C
Maximum heatsink temperature (start of the thermal cutback)........................ 85°C
4
Note(1): The DC chopper specifications are related to Combi AC0
Page - 6/79
AF6ZP0AL - COMBIAC0 & ACE0 - User Manual
