DuraMax Insulated Cabin Owner's Manual/ Instructions For Assembly

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A L L
P U R P O S E
I N S U L A T E D
Insulated Cabin
OWNER'S MANUAL /
Instructions for Assembly
Size 10 Ft x 13 Ft / 3.1 Mtr. x 4.0 Mtr.
Ver. : 2.0
• Strong & Secure Cabin
• Quick & Easy Assembly
• Metal Cladded Insulated Walls
• Wide Door with Lock
• Easily Expandable
Available Kits
• Modular Extension Kits Available
• Window Kits Available
Approximate
Size
Area
10 Ft x 13 Ft
129 Sq. Ft.
12 Sq.Mtr.
3.1 Mtr. x 4.0 Mtr.
C A B I N S
Building Dimensions :
Storage
Volume
Base Dimension
878 Cu.Ft.
Width
Depth
24.9 Cu.Mtr.
Height
Requires two people and takes 4-5 hours for Installation.
Exterior Dimension
Roof Edge to Edge
inch
cm.
inch
159 1/4
404.5
161
120 1/4
305.4
125 1/4
90
(Approx.)
Customer
Service Hotline
(800) 483-4674
www.uspolymersinc.com
Call us for any missing or damaged parts.
Do not return to the store.
Interior Dimension
Wall to Wall
cm.
inch
cm.
409
157 1/8
399
318
118 1/8
300
228.6
208
81 3/4
Door Opening
inch
cm.
37 1/4
95
210
82 3/4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Insulated Cabin and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DuraMax Insulated Cabin

Summary of Contents for DuraMax Insulated Cabin

  • Page 1 P U R P O S E I N S U L A T E D C A B I N S Insulated Cabin OWNER’S MANUAL / Instructions for Assembly Size 10 Ft x 13 Ft / 3.1 Mtr. x 4.0 Mtr.
  • Page 2 Duramax Insulated Shed Limited Seven Year Warranty U.S. Polymer Inc. will send a replacement part free of charge, in the event of material defects and or workmanship for a period of seven years from the date of purchase. This warranty is extended only to the original purchaser. A purchase receipt or other proof of date of original purchase will be required before warranty service is rendered.
  • Page 3 Parts List PROFILES Note: Check all parts prior to installation. CODE DESCRIPTION CODE DESCRIPTION FOUNDA TION ‘U’ CHANNEL WINDOW CUT WALL PANEL FOUNDATION ‘U’ CHANNEL ROOF PANEL RIGHT FOUNDATION ‘U’ CHANNEL ROOF PANEL CENTER F1C, F2C, F3C, F4C, F5C, FOUNDATION ‘U’ CHANNEL F10C ROOF PANEL LEF T F6C, F7C, F8C, F9C...
  • Page 4 Exploded View P2BE RF6C RF7C RF5C RF7C P2BE RF7C RF1C RF7C RF7C RF4C RF2C RF3C RF7C RSJC TC8C TC3C TS2C TC7C TC4C TS1C RSJC RSJC RSJC TC1C RSJC TC6C TS2C TS3C RSJC TC2C TC5C TS3C TS1C DCV4 PC2C BC4C BC2C PC1C BC3C BC1C...

  • Page 5: Table Of Contents

    A. Foundation & Base Assembly Note: It is important that these instructions are followed step by step. All parts are clearly marked and care should Note be taken to use the correct one. Before Assembling Foundation make sure that the floor level should be perfect flat. Parts needed: CODE CODE...

  • Page 6: F1C

    Step - 3 Make Two sets Note Step - 4 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.

  • Page 7: F3C

    Step - 5 Step - 6 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.

  • Page 8: F8C

    Step - 7 Step - 8 F10C F10C IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.

  • Page 9: F11C

    Step - 9 F11C Step - 10 BC4C BC2C LEFT BACK BC3C BC1C BC1C BC3C BC2C FRONT BC4C RIGHT BC2C BC1C Fig. 1 Fig. 2 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 10 Step - 11 Option - 1 After assemble the Base ‘U’ Channel it can be filled with concrete up to the Foundation level. Concrete Option - 2 The Plywood can be placed by this sizes inside the base ‘U’ Channel. The Plywood should be placed after Note completing the Wall Panel Assembly.
  • Page 11 B. Wall Assembly This Insulated Cabin included with one Parts needed: Note Window Panel (W4C) . This can be fix Four CODE position as shown. TC1C TC2C TC3C TC4C BACK LEFT TC5C TC6C TC7C TC8C DCRC DCLC BC1C TS1C TS2C...
  • Page 12 Step - 2 BACK BC1C BC3C Fig. 1 Fig. 2 BC3C RIGHT Step - 3 BC1C BC3C BC1C Fig. 1 Fig. 2 BC3C BACK BC1C RIGHT Fig. 3 Fig. 4 1&2 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 13 Step - 4 BACK Fig. 1 Fig. 2 INSIDE BC1C Fig. 3 Step - 5 BACK BC2C Fig. 1 Fig. 2 BC2C Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.

  • Page 14: W1C

    Step - 6 BACK BC4C Fig. 1 Fig. 2 LEFT BC4C Step - 7 BC4C Fig. 1 Fig. 2 BC4C LEFT Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 15 Step - 8 3&4 TC4C TC3C TC4C TC4C Fig. 1 Fig. 2 1&2 TC3C TC3C BACK Fig. 3 Fig. 4 TC4C BACK Fig. 5 Step - 9 RIGHT Fig. 2 Fig. 1 BC3C BC4C FRONT Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.

  • Page 16: Bc2C

    Step - 10 RIGHT BC2C Fig. 1 Fig. 2 FRONT BC2C Step - 11 BC4C BC2C Fig. 1 Fig. 2 BC4C FRONT BC2C RIGHT 1&2 Fig. 3 Fig. 4 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.

  • Page 17: W1C S11

    Step - 12 TC5C TS1C TC5C TS1C TC6C Step - 13 TS2C TC5C TC5C BACK 3&4 Fig. 1 Fig. 2 TC6C TC6C TC6C TC5C 1&2 Fig. 3 Fig. 4 TC6C RIGHT TC5C Fig. 5 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 18 Step - 14 BC2C Fig. 1 Fig. 2 BC2C FRONT Fig. 3 Step - 15 Fig. 1 Fig. 2 LEFT FRONT Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 19 Step - 16 BC1C Fig. 1 Fig. 2 FRONT BC1C Step - 17 BC1C BC3C Fig. 1 Fig. 2 FRONT BC1C BC3C Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 20 Step - 18 TC7C TS1C TC7C TS1C TC8C Step - 19 TS2C TC7C TC7C BACK 3&4 TC8C Fig. 1 Fig. 2 TC8C TC7C TC8C 1&2 Fig. 3 Fig. 4 TC7C TC8C LEFT Fig. 5 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 21 Step - 20 TC1C TS3C TS3C Step - 21 TC1C Do not fully tight the bolt (S13) now. Note RSJC TS3C RSJC Step - 22 TC2C TS3C Step - 23 TC2C Do not fully tight the bolt (S13) now. Note RSJC IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 22 Step - 24 FRONT Fully tight the bolt (S13) now. Note TC1C 1&2 TC1C TC1C Fig. 2 Fig. 1 FRONT INSIDE Step - 25 FRONT 1&2 Fully tight the bolt (S13) now. Note TC2C TC2C FRONT INSIDE TC2C Fig. 2 Fig.
  • Page 23 Step - 26 TC2C TC1C TC1C TC2C Fig. 1 Fig. 2 FRONT Step - 27 DCRC DCRC BC1C Fig. 1 Fig. 2 DCRC DCRC Fig. 3 IMPORTANT DCLC Fix the plastic screw cover (S19) to the Note bolt edges (S18) from inside the Cabin to prevent injury.
  • Page 24 Step - 28 TC1C BC1C Fig. 1 Fig. 2 TC1C 1&2 BC1C FRONT BC1C Step - 29 TC4C 3&4 TC3C BACK RSJC 3&4 RSJC TC3C 1&2 RSJC RSJC Fig. 2 Fig. 1 RSJC RSJC TC4C LEFT RSJC Fig. 4 Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 25 Step - 30 4&5 RSJC RSJC 4&5 TC3C TC1C TC1C Fig. 1 Fig. 2 TC2C TC4C RSJC TC2C RSJC FRONT Fig. 3 Fig. 4 RSJC Fig. 5 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 26 C. Roof Assembly Parts needed: CODE CODE PC1C RF1C PC2C RF2C P2BE RF3C RF4C DCV4 RF5C RF6C RF7C Step - 1 Note On top ‘U’ channel these 3 holes are Pre-drilled for reference, align the holes and secure. 3&4 1&2 TC5C TC2C TC2C...
  • Page 27 Step - 2 TC5C TC2C RIGHT FRONT Step - 3 Fig. 1 Fig. 2 FRONT RIGHT IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 28 Step - 4 Fig. 1 Fig. 2 FRONT Step - 5 Fig. 1 Fig. 2 Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 29 Step - 6 Dia. 3.0mm. Step - 7 RF7C RF7C RF7C RF7C TC5C TC5C RF7C RF7C RF7C RF7C RF7C RF7C RF7C IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 30 Step - 8 BACK RF7C RF4C RF4C RF4C RF3C RF3C RF3C RF3C Fig. 2 Fig. 1 RF4C RF3C RIGHT Fig. 3 Step - 9 BACK RF7C RF6C RF6C RF5C RF5C RF5C Fig. 2 Fig. 1 RF6C RF5C LEFT Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 31 Step - 10 3&4 RF1C RF2C RF7C RF5C RF5C RF1C RF1C 1&2 Fig. 2 Fig. 1 RF2C RF2C RF1C RF1C FRONT Fig. 4 Fig. 3 Step - 11 TC4C TC3C Fig. 1 1,2&3 TC4C TC4C TC4C BACK Fig. 2 Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 32 Step - 12 1&2 Fig. 1 Fig. 2 BACK Step - 13 Fig. 1 Fig. 2 Fig. 3 BACK IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 33 Step - 14 Fig. 1 Fig. 2 Fig. 3 Step - 15 P2BE P2BE Fig. 2 Fig. 1 BACK Fig. 3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 34 Step - 16 Dia. 3.0mm. PC1C Fig. 1 DCV4 PC1C 1,2,4&5 DCV4 Fig. 3 Fig. 2 BACK PC2C PC1C DCV4 Fig. 4 Fig. 5 Step - 17 1,2,&3 DOOR DOOR Fig.1 1,2,&3 1,2,&3 DOOR DCRC DCRC Fig.2 Fig.3 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 35 Step - 18 Fig.2 Fig.1 Fig.3 Fig.4 Fig.5 Fig.6 Fig.7 Fig.8 Step - 19 DCLC IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 36 D. Window Assembly Step - 2 Step - 1 Rubber Rubber Step - 3 Step - 4 Dia.3.0mm. IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 37 Step - 5 Step - 6 IMPORTANT : USE HAND GLOVES TO PREVENT INJURY.
  • Page 38 U.S. Polymers, Inc. 1057 S. Vail Ave Montebello, CA 90640, United States of America English...
