Vinyl Garden Shed

OWNER'S MANUAL /

Instructions for Assembly '10 Ft WoodBridge'

Size 10 Ft x 3 Ft /3.2 m x 0.8 m (Approx.)

Ver: 3.0

Your Total Solution To Maintenance Free Storage Sheds.

• All Weather Durable PVC

• Won't Dent, Rust, Rot or Mildew

• Tall Walk In Shed

• Never Needs Painting

• 61 Inch Wide Double Doors

• Easy Assembly

• High Wind Tested

• Snow Load Tested 20lbs/sq. foot

• Pad Lock Ready (Lock not included)

• Foundation included,wooden or Cement floor Needed.

Approximate

Size

Area

10 Ft x 3 Ft

25.8 Sq. Ft

2.4 Sq.m

3.2 m x 0.8 m

A Product of

S H E D S

Building Dimensions :

Storage

Volume

Base Dimension

158.9 Cu.Ft

Width

Depth

4.5 Cu.m

Height

Exterior Dimension

Roof Edge to Edge

inch

125 3/8

318.4

127 7/8

32 1/4

81.7

32 5/8

85 1/2

Patent #416.091

Customer

Service Hotline

(800) 483-4674

www.duramaxbp.com

Call us for any missing or damaged parts.

Do not return to the store.

Interior Dimension

Wall to Wall

inch

324.8

123 3/8

313.3

82.9

30.0

76.3

217.1

185.5

Door Opening

inch

154

60 5/8

71 1/2

181.6

Table of Contents

Summary of Contents for DuraMax WoodBridge

Page 1 S H E D S Vinyl Garden Shed Vinyl Garden Shed OWNER’S MANUAL / Patent #416.091 Instructions for Assembly ‘10 Ft WoodBridge’ Size 10 Ft x 3 Ft /3.2 m x 0.8 m (Approx.) Ver: 3.0 Customer Service Hotline (800) 483-4674 www.duramaxbp.com...
Page 2 Duramax Garden Shed Limited Fifteen Year Warranty U.S. Polymer Inc. will send a replacement part free of charge, in the event of material defects and or workmanship for a period of fifteen years from the date of purchase. This warranty is extended only to the original purchaser. A purchase receipt or other proof of date of original purchase will be required before warranty service is rendered.
Page 3 SAFETY & PRECAUTIONS Before You Begin... 1. Check your local building codes regarding footings, location, etc. 2. Select a site that allows enough working space around the shed. 3. Determine building foundation and anchor system. 4. Read and understand the Owner’s manual enclosed in the package. 5.
Page 4 SAFETY & PRECAUTIONS For your own safety, please read and follow these instructions during the shed assembly. 1. Always wear work gloves, long sleeves and eye protection during assembly of the shed. Some pieces of the shed contain sharp edges and can cause injury. 2.
Page 5 IMPORTANT Wear eye protection when using any form of power tools. Do not use voltage power tools in a wet or damp enviornment to avoid electric shock. Do not use any part of the shed as a means of personal support while attaching components during assembly. The shed must be constructed on a solid base foundation.
Page 6: Table Of Contents
Parts List PARTS ACCESSORIES CODE CODE CODE RS1A F01A FDCL B1LA, B1RA, CB1A, CB2A, RS2A B2, B3LA, B3RA CB3XA, CB4A, MJ F02A FDCR RS3E RS5E RS8A B1LA RS9A B1RA RS1A, RS5E RS3E, RS8A, RS9A RS10A B3LA RS14A B3RA CDLA RS2A, RS10A, RS14A CDRA CB1A...
Page 7 Exploded View RS3E RS2A RS10A RS5E RS2A RS1A RS5E RS9A RS2A RS8A RS9A RS1A RS3E RS2A CB3XA CB3XA CB2E B3LA F01A CDLA B3RA F01A CB1A F02A CDRA F02A B1LA B1RA CB2E CB4A CB1A CB4A...
Page 8 A. Foundation & Base frame Parts Needed: Code 1. It is important that these instructions Note are followed step by step. F01A 2. All parts are clearly marked and care should F02A be taken to use the correct one. 3. Don’t install under windy conditions. 4.
Page 9: F01A
F02A F01A B3RA B1RA B3LA F02A B1LA F01A...
Page 10: Cma
B. Wall & Columns Parts Needed: Code CDLA CDRA CB1A CB2E CB3XA CB4A All parts are clearly marked and care Note should be taken to use the correct one. CDRA CDRA Fig.1 CDRA 2&3 B1RA B1RA CDRA Fig.2 B1RA Fig.3...
Page 11: Cca
Check the stamped label on top of Note all panels inside. CDRA CDRA B1RA Fig.1 B1RA Fig.1 Fig.2 2&3 Fig.3 Do not tighten the screw. Note Leave it loose Fig.1...
Page 12: Cb1A
CDRA CB1A CDRA CB1A CB1A Fig.2 Fig.1 CB4A CDRA 2&3 CDRA B1RA CB4A Fig.2 Fig.1 CB4A CB1A B1RA CB4A Fig.3 CB3XA CB3XA CB3XA CB3XA...
Page 13 B3RA Fig.2 Fig.1 2&3 B3RA Fig.3 B3RA Do not tighten the S2 screw. Note Leave it loose. 1&2 CB2E CB2E Fig.2 Fig.1 Fig.1 Fig.2...
Page 14 1&2 CB3XA CB2E CB3XA Fig.2 Fig.1 CB3XA CB3XA CB3XA Fig.3 Fig.1 Fig.2 CB3XA Fig.3 Fig.1 Fig.2 CB3XA CB3XA CB3XA B3LA Fig.4 Fig.3...
Page 15 Fig.1 B3LA 2&3 Fig.3 Fig.2 Do not tighten the S2 screw. Note Leave it loose. CB3XA 1&2 Fig.2 Fig.1 Fig.2 Fig.1 B1LA B1LA 3&4 Fig.4 Fig.3...
Page 16: Cdla
Do not tighten the S2 Note screw. 1&2 CB3XA CB2E 3&4 CB2E CB2E Fig.1 Fig.2 CB2E Fig.3 Fig.4 CDLA Fig.1 CDLA CDLA B1LA Fig.2 B1LA...
Page 17 Note 1&2 CB1A CB2E CB1A CB1A Fig.1 Fig.2 CDLA CB1A Fig.3 After completing the center band Note assembly, fully tighten the four center band fittings (FCB) to the corner column (CCA). CB4A 2&3 CDLA B1LA CB4A Fig.2 Fig.1 CB4A CB1A CB4A Fig.3...
Page 18 C. Roof Structures Parts Needed: Code Code RS1A RS2A FDCL RS3E FDCR RS5E RS8A RS9A RS10A...
Page 19: Cdra
FDCR FDCL CDLA FDCR CDRA Fig.1 FDCL CDRA CDLA Fig.2...
Page 20 Front roof structure assembly RS1A RS1A RS1A RS9A RS1A RS1A RS8A RS8A RS9A RS2A RS1A RS9A RS8A RS8A RS2A RS2A RS9A...
Page 21 Back roof structure assembly RS1A RS1A RS1A RS9A RS1A RS1A RS8A RS8A RS9A RS2A RS1A RS9A RS8A RS8A RS2A RS2A RS9A...
Page 22: Cdra Fig
Note Make Two Sets RS3E RS3E Fig.1 RS3E 1&2 Fig.2 RS1A RS1A RS2A RS1A Front RS2A CDRA Fig.1 RS1A RS2A 3&4 RS1A FDCR RS1A Fig.2 1&2 RS1A CDLA Fig.3 RS1A FDCL Fig.4...
Page 23 RS1A Front Fig.1 1&2 RS1A Fig.2 Fig.3 Back RS1A...
Page 24 RS3E RS1A Fig.1 Fig.2 RS3E 1,2,3&4 RS2A RS3E Fig.3 Fig.4 RS5E RS5E RS5E RS5E RS8A RS8A Fig.1 RS5E RS8A RS5E RS8A RS9A Fig.2...
Page 25 RS5E RS10A RS10A RS10A Fig.1 RS5E RS10A RS5E Fig.2 RS5E RS9A Fig.1 RS5E RS9A Fig.2...
Page 26: Note
D. Roof Panels Note Insert roof plugs into Facia Panel only as indicated. Parts Needed: Code RS14A Front Front Back Back...
Page 27 Apply silicone around the roof plugs Note Use a screw driver to align the Note holes. and the pin holes before fixing the pins. Insert roof plugs into roof panels only as indicated. left RS14A RS5E RS14A RS3E Inside View Outside View Fig.
Page 28 Option-1 Plywood(not included) After completing the assembly of shed place exterior grade CDX 3/4 (19 mm) plywood inside the foundation. Note Option-2 Concrete...
Page 29 E. Door Note Apply silicone around the perimeter of the base ‘U’ channel. Seal the corners, joints and base of door column. This is optional and should be done for heavy rain areas if needed. Base ‘U’ channel Column Base ‘U’ channel Fig.2 Fig.1...
Page 30 Note After completing the panel assembly, apply silicone around the roof plugs. This is optional and should be done for heavy rain areas if needed.
Page 31 F. Ventilation Kit Parts Needed: Code TOOLS YOU WILL NEED Power Drill Dia 3/16” (5mm) drill bit Dia 1/2” (12.5mm) drill bit Note Optional ventilation kits can be installed on any of the wall panels. However, we recomend mounting them on the top of the shed’s back wall. Outside Outside...
Page 32 High wind area installation instructions Note: To ensure that your shed withstands high winds, you will need the following reinforcement. Parts needed (not included) CODE DESCRIPTION Dia. 4.2 x 16mm. (5/32” x 5/8”) Sheet Metal Screw Attach each side panel (SP ) on the bottom to the Base U-channel.
Page 33 Base U-channel Important Warranty Information The ‘DURAMAX’ shed has been tested and passed wind loads of up to 115 mph in a controlled laboratory environment. Natural high wind areas create wind at unpredictable speeds that are very difficult to capture accurately by location. As such we cannot guarantee the performance of the shed in these extreme situations.
Page 34 ADDITIONAL ACCESSORIES AVAILABLE These accessories are required in case of heavy snow or high wind areas. Please choose relevant accessories according to your needs. ANCHOR KIT (Soil) Wire rope with twist augers for sheds installed with foundation (Wood / Metal) on soil. For heavy wind area.
Page 35 U.S. Polymers, Inc. 1057 S. Vail Ave Montebello, CA 90640, United States of America...
