5.
Press the
button of the PlainView 2 Switch once. After a 3-second pause, the
system will sound one chirp to confirm column one selection (see the Installer-
Programmable Features section).
6.
Press the
button of the PlainView 2 Switch five times (you will hear a chirp
each time you press the button) to select row five. After a 2-second pause, you
will hear either one or two chirps.
1 1 c c h h i i r r p p
Indicates that the system has properly learned 0 MPH or; if the system was
programmed at more than 0 MPH, 1 chirp indicates that there was a fault
reading the speed sense input (check the connection on the BLACK/GRAY wire,
then repeat steps 1 - 5).
2 2 c c h h i i r r p p s s
Confirms the speed has been set.
programmable features
BlackJax 5 comes from the factory with its features preprogrammed as noted in bold
letters in the following tables. Some features can be programmed by the installer or
the user, others can only be programmed by the installer. There are two tables provid-
ed which define the user-programmable and installer-programmable features.
using the CliffordWizard Pro installation software
Cliffnet Wizard Pro provides access to all available system features and some that are
not available when manually programming with the Valet switch. Cliffnet Wizard Pro is
compatible with Microsoft Windows 95/98/2000/ME/XP/NT so most programming
operations can be accomplished by pointing and clicking with a mouse. This eliminates
the need for programming grids and lengthy programming sequences. For a complete
guide to system programming using the Cliffnet Wizard Pro refer to the Cliffnet Wizard
help menu. Otherwise, refer to the tables provided in the following sections.
programming the user-selectable features using the
PlainView 2 switch
1.
Write down the column (across) number and row (down) number of the
feature(s) you wish to program.
2.
Turn the ignition to the "ON" position or start the engine.
3.
Enter the factory preset valet/programming code of "2" by pressing the
button twice, and then pressing the
16
button once.
www.directed.com
